1. 同轴封装 PIN 探测器组件
Coaxial PIN Photodiode Module
1. 特点（FEATURES）：
 High responsivity，Low return loss
高响应度，低回波损耗
 Low dark current, Low capacitance
低暗电流，小电容
 Planar incident structure
平面结构
 Coaxial Package, Laser Welding, High reliability
and Long operation life
同轴式小型封装，高可靠性，长寿命
2. 应用（APPLICATIONS）：
 Analog Optical Receiver
广电网模拟光接收机
 Optical Transmitter or Date Signal
数字网数字信号光发射机
 For CDMA，CATV
可用于 CDMA,CATV
3. Absolute Maximum ratings(极限额定值)（Tc=25℃）：
参数 符号 参数值 单位
Parameter Symbol Ratings Unit
饱和功率
Ps 10.0 mW
Saturation power
工作电流
If 10.0 mA
Forward current
反向电压
Vr 30 V
Reverser voltage
工作温度
Top -40～+85 ℃
Operating temperature
储存温度
Tstg -40～+125 ℃
Storage temperature
4. Optica and Electrical Characteristics(光电参数)（Tc=25℃）：
参数 符号 最小值 典型值 最大值 单位 测试条件
Parameter Symbol Min. Type Max. Unit Test condition
工作波长
Operating λ 900 1310 1650 nm
Wavelength
响应度
R
0.85 0.9 A/W Vr=5V，λ=1310nm
Responsivity
0.90 0.95 A/W Vr=5V，λ=1550nm
暗电流
Id 0.3 0.5 nA Vr=5V
Dark Current
Shenzhen YiGuDian Technology Co., Ltd.
A908, Zhantao Building, Mingzhi Road, Longhua District, Shenzhen, China-518000.

2. Tel: +86 13755985765 Fax: +86 755 23352115 E-mail: sales_2@yigudian.com http://www.yigudian.com

3. 结电容
C 0.3 0.5 pF Vr=5V
Capacitance
上升、下降时间
Tr/Tf 0.3 ns Vr=5V,10～90%Rise time/Fall time
带宽
Bw 3.0 GHz Vr=5V
Bandwidth
二阶失真 Composite
CSO -70 dB
Second Order Beat
三阶失真 Composite
CTB -80 dB
Third Order Beat
工作电压 Operating
V -5 V
Voltage
光反射损耗 Optical
ORL 45 dB λ=1310nm
Return Loss
5. Pin ASSIGNMENT(管脚图)：
6.Mechanical dimension（封装形式）
 尾纤式（Pigtail Package）：
Shenzhen YiGuDian Technology Co., Ltd.
A908, Zhantao Building, Mingzhi Road, Longhua District, Shenzhen, China-518000.
Tel: +86 13755985765 Fax: +86 755 23352115 E-mail: sales_2@yigudian.com http://www.yigudian.com

4.  插拔式系列：
Receptacle Package series:
备注：1. 尾纤长度及各固定卡形式由客户确定。
2. 以上产品的结构、尺寸、光电参数及工艺技术要求均可按客户要求设计、制作。
Add：Order information
 GPD-XXX-XXX-XCoaxial InGaAs Photodiode Module：
-X X X -X X X -X
Package
Connector
Sleeve Type
Photosensitive Pin-defi ROHS Special requirements
Surface nition CertificationPigtail Recetacle Pigtail Recetacle
P:Pigtail FA:FC/APC A:FC-1 1:Short 40:φ40um A:A Type R:Pass I：Filter slice A:Without ceramic sleeve
R:Receptacle SA:SC/APC B:FC-2 2:Hot 55:φ55um B:B Type Default:No Pass M：Multi B:Built-in ceramic sleeve
LA:LC/APC C:FC-3 3:Long 75:φ75um C:C Type N：Non coating
F:FC/PC D:SC Default: 3H:φ100um Others
S:SC/PC E:ST Receptacle 1K:φ1000um
T:ST/PC others
N:NO
Semiconductor lasers and detectors are Static sensitive components
Are vulnerable to Electrostatic discharge(ESD) and surge over
Current(EOS) damage! Please contact with Static sensitive
