"API calls are either successful or they fail" – at least that’s the concept current web protocols are based upon. But in the real world, it isn’t always that simple. There are use cases where a 3rd party system returns something that can’t be defined as a clear error, but returning a simple http status code of 200 OK without any additional information is also wrong. For those cases, every api provide has their own way of communicating to the client what has gone wrong in the backend. This is why we need to find a common way to communicate errors and especially those edge cases.

1. Call for a better error handling in APIs

2. André Cedik · Developer Advocate
shipcloud.io · andre@shipcloud.io
shipcloud GmbH · Mittelweg 162 20148 Hamburg

3. API v2
• Incoporate learnings from more than 5 years
• Easier integration in existing shop- / ERP-software
• I18n
• Returning translated strings
• White label
• Design first approach using OpenAPI

4. But most of all ...

5. ... better error communication!

6. shipcloud error communication

7. History of errors

8. Mariner 1
• Veered off course, because
unscheduled maneuver
• Steering unpossible
• Missing hyphen in the code
allowed transmission of
incorrect guidance signals
• Engineers hit self destruct
button
• $18 million error

9. ESA Ariane 5
Flight 501
• Reused software from
Ariane 4
• Ariane 5 had faster engines
• Software tried to push a
64-bit float into a signed 16-
bit integer
• Engineers hit self destruct
button at 37 sec. into its
maiden launch
• $8 billion error

10. NASA Mars
Climate Orbiter
• Failed conversion from
imperial units to metric
• Send the orbiter too close
to Mars‘ surface
• $125 million error

11. Y2K Bug
• Year numbers where saved with 2
digits (98,99,00,01)
• No one knew what will happen
when the year 2000 sets in
• Since ‘00‘ also meant 1900
• $500 billion error

12. Pentium-FDIV-Bug
• In 1994 Math Prof. Thomas R.
Nicely reported the bug
• Processor might return incorrect
binary floating point results when
dividing a number
• Intel attributed error to missing
entries in the lookup table
• Tried to downplay the bug
• Had to replace processors
• $475 million error

13. Miscommunication

14. Mokusatsu - The World‘s Most Tragic
Translation
• Allied leaders called for Japan’s
unconditional surrender
• Japanese government said
nothing while considering their
options
• PM Kantaro Suzuki was
pressured for comment
• said only one word "mokusatsu“
• Mistranslation leads to the
dropping of the atomic bomb

15. Hawaii Missle Strike
• In Jan. 2018 citizens of Hawaii were
warned of an inbound ballistic
missile strike
• Turned out to be a false alert
• Recording over phone „EXERCISE“
• Message with „THIS IS NOT A
DRILL“
• Same UI used for drill and real
alerts
• No safeguards were in place
• It took 38 minutes to retract the
alert, because there was no
response protocol for a false alert

16. Error handling in APIs
Tools used at the moment

17. "Building fault-tolerant software
boils down to detecting errors
and doing something when
errors are detected"
Joe Armstrong, inventor of Erlang

18. http response status codes
• Informational 1xx
• Successful 2xx
• 200 OK
• Redirection 3xx
• 301 Moved Permanently
• Client Error 4xx
• Server Error 5xx

19. http response status codes 4xx & 5xx
• 400 Bad Request
• 402 Payment Required
• 403 Forbidden
• 404 Not Found
• 500 Internal Server Error
• 502 Bad Gateway
• 504 Gateway Timeout

20. Error handling in the body
• Good:
• Return complex structures
• Get more specific about an error
• Convey multiple errors
• Bad:
• Everyone has their own way of doing it
• Therefore developers have to understand „the way“

21. Error handling in APIs
The bad

22. shipcloud error communication

23. Sabre Dev Studio – error attribute
• „error“ is always a string
• Sometimes all Uppercase -
> seems to be like an error
code

24. Sabre Dev Studio – error attribute
• „error“ is always a string
• Sometimes all Uppercase -
> seems to be like an error
code
• Sometimes it looks like an
error trace

25. Sabre Dev Studio – code attribute
• Sometimes it looks like a
http response status code
• Sometimes like an internal
code
• Same code used more than
once
• different error text
• 102
• 111
• 404
• 500
• 700101
• 050002
• 060016
• 700202

26. Sabre Dev Studio – code attribute

27. Pitney Bowes
• Each validated field has its own
error code

28. Pitney Bowes
• Each validated field has its own
error code
• "XXX is invalid, unsupported or
missing“
• So what is it now?!?

29. Google Maps Geocoding API
• Has a „status“ attribute
• OK, ZERO_RESULTS, OVER_DAILY_LIMIT, OVER_QUERY_LIMIT,
REQUEST_DENIED, INVALID_REQUEST, UNKNOWN_ERROR
• INVALID_REQUEST = 400 Bad Request
• OVER_QUERY_LIMIT = 200 OK

30. Google Drive API v3

31. Klarna

32. API Football

33. Error handling in APIs
The good parts

34. squarespace

35. Facebook GraphAPI

36. Facebook Marketing API

37. Facebook Marketing API

38. Banks API

39. Figo.io

40. What we can do better

41. What‘s the problem?
• „API calls either fail or are successful“ – Phil Sturgeon
• „Soft errors“
• Not an exception type „crash“
• More like a warning

43. application/problem+json
• RFC 7807
• Pros
• Own content type
• Predefined set of attributes
• Extensible
• Cons
• Not encapsulated
• Mixing with other content
• Multi error handling just for
one error type
HTTP/1.1 403 Forbidden
Content-Type: application/problem+json
Content-Language: en
{
"type": "https://example.com/probs/out-of-credit",
"title": "You do not have enough credit.",
"detail": "Your current balance is 30, but that costs 50.",
"instance": "/account/12345/msgs/abc",
"balance": 30,
"accounts": ["/account/12345",
"/account/67890"]
}

44. Warning header
• RFC 7234
• Pros
• You could handle „soft
errors“
• Multiple warning header for
multiple different errors
• Cons
• Complex data can‘t be
returned
• It‘s just a string
HTTP/1.1 200 OK
Date: Sat, 25 Aug 2012 23:34:45 GMT
Warning: 112 - "network down" "Sat, 25 Aug 2012 23:34:45
GMT"

45. application/health+json
• Internet Draft inadarei-api-
health-check
• Pros
• „status“ attribute („pass“,
„warn“, „error“)
• Cons
• Specific to health of an api
• Overhead content
HTTP/1.1 200 OK
Content-Type: application/health+json
{
"status": "pass",
"version": "1",
"releaseId": "1.2.2",
"notes": [""],
"output": "",
"serviceId": "f03e522f-1f44-4062-9b55-9587f91c9c41",
"description": "health of authz service",
"checks": {
"cassandra:responseTime": [
{
"componentId": "dfd6cf2b-1b6e-4412-a0b8-f6f7797a60d2",
"componentType": "datastore",
"observedValue": 250,
"observedUnit": "ms",
"status": "pass",
"affectedEndpoints" : [
"/users/{userId}",
"/customers/{customerId}/status",
"/shopping/{anything}"
],
"time": "2018-01-17T03:36:48Z",
"output": ""
}

46. application/vnd.api+json
• JSON:API standard
• Pros
• Errors array to handle
multiple errors
• JSON pointers to show devs
where an error has occurred
• Cons
• Everything is in errors object
• „soft errors“ not possible

47. Best current practice
• HTTP status code
• Error object
• Easy referencing of errors
• „Code“
• „Subcode“
• Request IDs in the body
• for easier request identification in support cases
• Human readable message
• In multiple languages

48. "An excellent error message is
precise and lets the user know
about the nature of the error so
that they can figure their way
out of it."
Guy Levin, RestCase

49. Future of error handling in
APIs
A proposal

50. A proposal – to be discussed

51. A proposal – to be discussed
• Responses in a new format
• „data“ holds everything
we‘d normally have in the
root
• „errors“ and „warnings“
give information about
what happened
• „errors“ and „warnings“
follow the RFC 7807
pattern

52. A proposal – to be discussed
• „data“ is empty since no
resource was created
• Warnings possible if api
supports this use case

53. Questions?
Open Discussion
@andrecedik

54. Sources
• Atlas Agena with Mariner 1: NASA,
https://commons.wikimedia.org/wiki/File:Atlas_Agena_with_Mariner_1.jpg
• Ariane 5: DLR German Aerospace Center,
https://www.flickr.com/photos/48213136@N06/8958839420
• Mars Climate Orbiter: NASA/JPL/Corby Waste,
https://commons.wikimedia.org/wiki/File:Mars_Climate_Orbiter_2.jpg
• Bug de l'an 2000: https://commons.wikimedia.org/wiki/File:Bug_de_l%27an_2000.jpg
• Pentium: Konstantin Lanzet,
https://commons.wikimedia.org/wiki/File:KL_Intel_Pentium_A80501.jpg
• Hawaii Missle Alert SMS: https://twitter.com/tulsigabbard/status/952243723525677056
