This document provides an overview of service-oriented architecture (SOA) and business process management (BPM). It defines key SOA concepts like loose coupling, services, and service composition. It describes the drivers for adopting SOA like flexibility and cost reduction. The document outlines the typical components of a SOA architecture like the enterprise service bus and BPM suite. It distinguishes between service types and discusses how BPM integrates with SOA through standards like BPEL. Finally, it notes that BPM can be viewed as both a management practice and software solution that often leverages SOA principles.

1. 1

2. By : Mostafa Arab
2

3.  Why SOA ?
 What is Service?
 Drivers for services
 What is SOA
 Loose Coupling
 Service Types
 Service Composition
 Process Services
 SOA Building Blocks
 ESB
 BPM
 BPMS life cycle
 BPMS Architecture
 BPMS Integration
 BPM & SOA?
 EA & BPM & SOA
Agenda
3

4. Why SOA
 Organizations need to adapt and respond rapidly to customer demands,
put new products and services in the market before competitors do :
Need to be agile
 SOA makes it easier to bridge this gap : by creating a more flexible architecture
 Lower cost for changes
 Lower side effects after changes
4

5.  SOA is about Services
 So What is Service?
What is Service
 service is something useful a provider does for a consumer
 an economic term to describe the goods and services that
 organizations and people produce
 sell to one another
 buy from each other
 Can be simple or complex
5

6.  Without Service
What is Service
6

7.  With Service
What is Service
7

8. What is Service
8

9.  Flexibility
Drivers for services
 Services are small building blocks with a limited and clear set of capabilities
 easier to support the changing requirements
 preventing domino effects for changes in software
 Standardization
 Services are frequently provided using open standards
 hiding the underlying technical complexity and details
 more vendor-independent
 Open standards such as REST, SOAP, WSDL, WS-*, XML
9

10.  Cost reduction
Drivers for services
 Reusing a service is cheaper than building, maintaining, and hosting duplicate
functionality
 Shorter time to market
 By reusing services, functionality can be realized faster, thus diminishing the time
to market
 Increase in quality
 Because more consumers use a service, it is better tested
 There is no data duplication, so the data quality increases as well.
10

11. What is SOA
 SOA is an architecture approach for defining, linking, and integrating reusable
business services that
 have clear boundaries
 and are self-contained with their own functionalities
(http:/www.ibm.com/developerworks/webservices/tutorials/ws-soa-ibmcertified/ws-soa-ibmcertified.html/)
 SOA fits best for
 Centralized business functions used by multiple entities
 Integration with partners
 The existence of old technologies that are still working
11

12. What is SOA
 What factors contribute to SOA's most popular capability: business agility enablement?
 Loose coupling
 Enables real-time business capabilities because it removes the hard connections that impede the
ability to change
 Reuse ( (استفاده مجدد
 Makes processes more consistent because they depend on the same reused components
 Decreases the impact of change because it's done in a central location and reflects on all concerned
parties
 Helps decrease the cost of integration because the component has already been integrated
 Lets you publish once but consume many times
 Extensibility ( (توسعه پذیری
 Makes SOA solutions available to all sizes of organizations
 Makes it easier to add or change partners
12

13. What is SOA
Loose Coupling
 Coupling can be "low" (also "loose" and "weak") or "high" (also "tight" and "strong")
 Loose coupling is an approach to interconnecting the components in a system or
network so that those components depend on each other to the least extent practicable
 Coupling refers to the degree of direct knowledge that one element has of another
 The goal of a loose coupling architecture is to reduce the risk that a change made
within one element will create unanticipated changes within other elements
13

14. What is SOA
Loose Coupling
14

15. What is SOA
15
 Reuse

16. What is SOA
Service Types
 Service composition means the creation of new services from combining existing
services
 services can be divided into
 Elementary services: The smallest possible components that qualify as services. For
example, a service that can be used for zip code lookups
 Composite services: Services that result from combining two or more other services into
one service that provides more value. Composite services are executed in a single
transaction and their execution time is relatively short. An example is a service to book a
hotel and flight together
 Process services: Longer running services that can take a couple of hours, days, or even
more to complete and span multiple transactions. An example is a service for ordering a
book online. The entire process (order, pay, ship, deliver) involves multiple transactions
and takes a couple of hours at least
16

17.  service composition
What is SOA
Service Composition
 Aggregation: Combining two or more services into larger ones is fairly straightforward
(for example invoke the service operation A, then service operation B, then service
operation C). Service aggregation involves short-running services
 Orchestration: Combining several services into a flow or process that is more complex in
nature and contains decision logic and different execution paths. Orchestration involves a
central component such as a BPM platform that manages the orchestration of services.
Service orchestration involves longer-running services
17

18. What is SOA
Process Services
 Process services are services that use other services to execute their flow, like
composite services
 The difference between process services and composite services
 Duration: Process services are long-running processes that can take hours, days, weeks,
or even longer, while composite services are short-lived services that take at most a couple
of minutes to complete
 Transactions: Process services can span multiple steps, or transactions; composite
services are executed within a single transaction.
 State: Due to their complexity and duration, process services are required to maintain
state between the different service operations that are invoked
18

19. What is SOA
Process -Service
19

20. SOA building blocks
20

21.  Enterprise Service Bus
 Component that exposes the services to consumers and can also contain the implementation of
composite services ( Aggregated )
 Business Process Management
 Component to design, monitor, change, host and execute business processes
 Business rules
 Component to host, create, and monitor business rules
 Registry and repository
 The registry and repository are used to describe services and events and important metadata and
artifacts for consumers to improve use of services
 ……
SOA Building Blocks
21

22. SOA building blocks
 services can be combined into larger Services by using
 Enterprise Service Bus
Aggregated into composite services in a straightforward fashion
 Business Process Management
Strictly orchestrated into process services using Business Process Management (BPM) tooling
 Case Management
Flexibly combined into process services using Case Management tooling
22

23. SOA building blocks
ESB
 Common functionalities that an ESB should include are
 Validation: The ESB can validate the incoming requests and/or the outgoing responses to the
specified interface.
 Composite services: Elementary services can be aggregated into composite services using an ESB.
 Routing: Services are hidden behind the ESB and not directly visible to consumers. When a
request from a service consumer is received, the ESB routes it to the correct service provider
 Transformation: An ESB exposes services in a data format and protocol that is suited for service
consumers. It provides transformation of protocols and data between service consumers and service
providers
23

24. SOA building blocks
ESB
24

25. SOA building blocks
ESB
25

26. SOA building blocks
BPM & BPEL
 BPM deals with the management and improvement of your business processes
 BPEL (Business Process Execution Language) is an XML-based language that allowsWeb
services in a service-oriented architecture (SOA) to interconnect and share data
 BPEL provides a relatively easy and straightforward way to compose several Web services
into new composite services called business processes
26

27. SOA building blocks
BPMS life cycle
27

28. BPMS Architecture
28
Design &
Simulation
Services
Monitoring
Services
Process
Registry
Rules
Engine
Orchestration
(Workflow)
Engine
Integration
Services
Content / Data
Repositories

29.  BPM application will seldom access just one source of information
 Need to link the Orchestration Engine with other sources of data and services
 May require variety of integration techniques:
 EAI (Enterprise application integration)
 message brokers with Common Object Request Broker Architecture and COM+
 using common databases and data standards implemented with the Extensible Markup Language (XML)
 Middleware
 message queueing
 …
 ESB
 BPM to BPM
BPMS Architecture
BPMS Integration
29

30. BPMS Architecture
30
Before BPMS After BPMS
CRM
Financial
Systems

31. BPM & SOA?
 Business process management (BPM) is a management science that focuses on improving corporate
performance by managing and optimizing a company's business processes.(The Ultimate Guide to
Business Process Management: Everything You Need to Know and How to Apply It to Your
Organization, Theodore Panagacos)
 BPMS is BPM Suite (Software or System)
 BPMS is the identification of the software that handles the management of business processes
31

32. BPM & SOA?
 If we use BPM as a management science :
 There is no need to use SOA or any integration methods
 If we use it as a software (or suite) :
 We should use SOA or other integration method to integrate
it with other softwares but SOA is more suitable and flexible
32

33. EA & BPM & SOA
33

34. با تشکر
34

35. References
1. SOA Made Simple
Lonneke Dikmans , Ronald van Luttikhuizen
Copyright © 2012 Packt Publishing
2. http://www.ibm.com/developerworks/webservices/tutorials/ws-soa-ibmcertified/
ws-soa-ibmcertified.html
3. http://en.wikipedia.org/wiki/Coupling_(computer_programming)
