Building automation systems can include alarm capabilities that notify people through various methods when alarms are detected. Security systems can be integrated and use sensors to detect intrusion, movement, door/window contact, glass breaking, and more. Fire alarm systems are interconnected to shut down air handling, close smoke doors, start fans for pressurization and smoke extraction, and notify public address systems when fires are detected. Biometric technologies can be used for access control management and convenience.

1. Mohammed Zaid Shaikh
+971502249193

3. o Many building automation
systems have alarm capabilities.
If an alarm is detected, it can be
programmed to notify someone.
Notification can be through a
computer, pager, cellular phone, or audible alarm.
o Fire detection and alarm systems as per NFPA72 and AHJ
requirements, and in accordance with project and design
guidelines.
o Main/repeater fire alarm control panel, smoke/heat
detectors, visual/audible strobes and manual call points
are integral components of the system.

4. o Security systems can be interlocked to a building
automation system.
o If occupancy sensors are present, they can also be used as
burglar alarms
o Fire and smoke alarm systems can be hard-wired to
override building automation.

5. o The following functional systems
are interconnected to the
Fire Alarm System:
o Shutting down of Air Handling Units of the affected areas
o Closing of smoke check doors for segregation of affected
areas from non-affected areas
o Start-up of pressurization fans
o Start-up of smoke extraction fans (mechanical smoke
control)
o Public Address System
o Grounding of all elevators

6. o With Home Automation, the consumer can select and
watch cameras live from an Internet source to their home or
business.
o Security systems can include motion sensors
o This category also includes control and distribution of
security cameras.
o Detection of possible intrusion
o Sensors of detection of movement
o sensors of magnetic contact of door/window
o sensors of glass breaking
o sensors of pressure changes
o Simulation of presence.
o Detection of fire, gas leaks, water leaks
o Medical alert.
o Tele-assistance.
o Precise and safe closing of blinds.

7. o Proximity system can be installed on building
perimeters, fences, and walls
o Uses an electromagnetic field generator powering one
wire, with another sensing wire running parallel to it
o The sensing wire is connected to a signal processor that
analyses:
o Amplitude change (mass of intruder),
o Rate change (movement of intruder),
o Preset disturbance time (time the intruder is in
the pattern).

8. o CCTV (cctv stands for closed circuit television)
o All kinds of businesses stand to benefit from
installing these camera systems in their stores
and office buildings
o Must be integrated with alarm systems and
additional security elements

9. o Kept hidden, without the
reach and knowledge of
the offender
o Cost effective
o Triggered easily even by a
child in case of emergency
o Used with a combination
of CCTV devices
o Checked from time to
time even if they are not
in use for long

10. o Make readings without
button press
o Sabotage absorbent
o Completely waterproof
o Resistant to electrical
shock
o Transmit data to
computer via a USB cable
o Low battery consumption
o Battery can be changed
by users

11. o Bio-metric technology
o Manage access
control systems
o Easy and convenient
access
o Very reasonable prices

12. o Biometric security (identification) systems identify a
human from a measurement of a physical
characteristic or behavioral trait to determine or
verify an identity.
o There are several different types of biometric
security technologies:
o Facial Recognition
o Fingerprint Recognition
o Hand Geometry
o Iris Recognition
o Voice Recognition

13. o Application in almost every
H.R department of a firm
o The assorted services of this
range:
o Proximity Card Based
o Biometric based solutions
o Remote locations at one
centralized place
o Attendance & leave
management
o Productivity and Time loss
management
o Movement reports
o Personal information of the
employes
o Flexible formats for report
generation

14. o Single Unit Video Intercom
System is perfect to be used in
residential houses and homes
o works as follows:
o Visitors press the music key of
outdoor phone
o On holding the indoor phone it
displays the image of the lobby
o Indoor user intercommunicate
with visitors
o After confirming the visitor, on
pressing "Unlock" the electric lock
of the lobby is opened

15. o Easy to carry,
o Highly sensitive and
o Easy to operate
o Not suitable with safe
inspection equipment

16. Queries..??
