This document provides information about Aero-Flex, a manufacturer and distributor of rigid piping assemblies and flexible metal hoses. Some key details include: Aero-Flex operates out of a 10,000 square foot facility and specializes in stainless alloys. They maintain various quality certifications including AS9100, ISO 9001, and PED 97/23/EC. All materials are inspected upon receipt and stored separately with control numbers. Processes like cleaning, welding, inspection, and packaging are controlled by documented work instructions. Documentation and traceability are maintained for all components and assemblies. Aero-Flex aims to balance being small and reactive and large enough to be competitive in the industries they serve.

1. Manufacturer, Fabricator and Distributor
of Rigid Piping Assemblies and Flexible Metal Hoses
to the Turbine Power , Oil & Gas Exploration and Aerospace.

2. Aerospace Power Gen/Oil & Gas
Our Products are used Globally
Always Compliant with Local, State, Federal and DEFAR requirements

3. Aerospace
Flex Hoses Rigid Tubes Machine Parts
Machine Facility AS9100 Certified with High Volume Capacity

4. Power Generation
ASME/ASTM Fittings ASME 31.1 Power Piping Turbine Flex Hoses

5. Our Facility and Systems
DataBase Management Inventory Inspection & Control ControlledWork Stations
SegregatedTest Areas IT and Data Base Servers Clean and A/C Facility

6. 6”, 8” & 12” Prepared for
CW I Review,
Pressure testing
Weld Pickling
and
Pipe Passivation.
Followed by final cleaning
FOD , Inspection and capping
B31.1 Power Piping
&
B31.3 Process Piping

7. Aero-Flex Quality
AS9100 Rev C and PED 97/24/EC

8. Aero-Flex maintains its PED
Compliance and Certification of
European Union 97/23/EC through
the British Standards Institute.
BSI acts as our Notified Body for all
Cat I and CAT II Assemblies as well
as consultant for all materials and
Required Documentation.
PED TAG

9. Additional Aero-Flex Quality
CWI’s on Staff and on the Floor EVERYWELD CWI INSPECTED
Crating/Wood Third Party Inspections

10. DUAL CERTIFICATION OF WELDERS
ASME IX AND AWS D17.1

11. WELD MAP AND TECHNIQUES

12. TEST LABORATORY X-RAY TECHNIQUES

13. Their Way Aero-Flex Way
Why some assemblies fail and ours doesn’t!

14. The Aero-Flex Way using Independent Third
Party (NADCAP) Analysis and Validation

16. Thermocouple and Cold Argon Purge for thin .010” weld

17. New WeldsTechniques
and material concerns
are studied and the
working parameters
are Engineered before
the weld are released.
Weld Macrographs preformed for joint details

18. Prior to a weld being preformed at Aero-Flex we first:
Evaluation of the weld and materials to be joined!
Review NDT and if Third party resources are required!
Review equipment resources & current personnel training!
Develop test welds and working procedures !
Once we are confident we have engineered the weld:
We will Develop and institute the weld requirements by
Issuing a Weld Technique Sheet (attached at right)!
A Weld Technique Sheet is always referenced in the working
production floor router providing documented controls for all
welders and welds preformed at Aero-Flex!
WELD TECNIQUUE
Control AF- 4QF021

19. Aero-Flex Prepares and Packages all piping and materials
with Controlled Documentation, Sealed and Secured.
All components are Inspected for cleanliness and
contamination prior to capping.
Packages and crates are in
Compliance with the Federal
And International Standards
For Export : ISPM 15, all crates
and packages are Stamped for
International compliance.
Domestic and
International Shipping
“Certified Export Crates/Wood”

20. All assemblies are shipped with
individual documentation, project
documentation and required NDT
information. All Documentation is
available for Uploading to
customers online portals and
transportation centers.
FAI’s
supplied per AS 9102
Documentation and
Project Close Out
Full Traceability and Documentation
on all Components and Systems

21. 1) Aero-Flex is in a 10,000 SqFt facility, Primarily a Stainless Alloy shop with limited carbon.
2) We operate under our QMS: AS9100 Rev C. , ISO 9001, PED 97/23/EC.
All Materials are Purchase Order specified and all materials are inspected at receiving for full MTR
documentation, code compliant dimensions and cleanliness, then accepted by inventory.
Inventory stored on separate and organized racks; all inventory items have control numbers.
All Aero-Flex personnel are trained on the QMS and cross trained in various job functions.
QC, CWI & Floor Personnel and Managers have extensive experience and education in their
respective fields and preform regular Process Review Audits.
3) Aero-Flex develops its software and database systems for its manufacturing controls and process
functions for various operations. Aero-Flex maintains and manages its own computers servers and
systems through our internal IT Department. Accounting is done on a Quick Books based accounting
package with independent quarterly reviews.
4) All materials are cleaned before and after processing. All piping is acid washed, welds are
pickled and passivated, followed by cleanliness & FOD inspection and then capped.
ID visual inspection of all materials and piping is preformed on all assemblies.
5) Dimensional Controls are preformed on all assemblies with accurate & appropriate calibrated tools.
6) All Packaging, Shipping and Documentation is controlled and supervised with approved work instructions.
7) Aero-Flex is a private held company and has the financial stability to grow and expand as necessary.
8) EHS, Aero-Flex maintains a clean and safe facility and works with our local and state agencies to
maintain full compliance to Environmental and Health Regulations. See Attached Compliance Letter
In Summary “Expectations from the Supplier”
for your consideration

22. …Small enough to be highly
reactive while Growing Strong.
Large enough to be
very competitive…
