HTML5 and CSS3 have arrived. Are you ready to start adopting these technologies in your web projects? Jump start your understanding of the new rich standards and arm yourself with essential techniques for making the most of HTML5 and CSS3 today. In this half-day workshop, you will learn everything you need to know to effectively start leveraging HTML5 and CSS3 in ASP.NET applications. Learn how HTML5 and CSS3 are removing limits from web design. Discover tools and techniques for adopting HTML5 and CSS3 while still supporting older browsers. Leave with the essential knowledge needed to embrace HTML5 and CSS3 in your next ASP.NET project!
5. “Perhaps Adobe should focus more on creating great HTML5 tools for the future, and less on criticizing Apple for leaving the past behind.” -Steve Jobs April, 2010
23. Because some browsers run on many different operating systems, there can be a tendency to use a 'least common denominator' approach to implementing HTML5. By using more of the underlying operating system, and taking advantage of the power of the whole PC, IE9 enables developers to do more with HTML5. “ ” -Dean Hachamovitch General Manager, IE Team
30. Modernizr Shiv’r + Inspector Simple way to check feature support Conditional JS and CSS .multiplebgs div p { /* properties for browsers that support multiple backgrounds */ } .no-multiplebgs div p { /* optional fallback properties for browsers that don't */ } if (Modernizr.canvas) { //Canvas supported } if (Modernizer.cssColumns){ //Columns supported } //Etc... *Don’t use with IE HTML5shiv. One or the other.
38. semantic data data-* Valid approach to storing data in HTML <!--Store values in data-* attributes--> <div id="mydiv" data-key="26" data-name="My product name"> This product is an extremely popular choice. </div> <!--Access values with JavaScript--> //Using DOM's getAttribute() property varkey = mydiv.getAttribute("data-key") //returns "26" //OR Using JavaScript's dataset property**var key = mydiv.dataset.key //returns "26" support: IE9, FF3.5, Safari, Chrome, Opera
39. video tag: <video /> <!-- Single video --> <video src="mymovie.mp4" width="320" height="240"></video> <!-- Multiple encoded versions --> <video width="320" height="240" controls> <source src="mymovie.ogv" type='video/ogg; codecs="theora, vorbis"'> <source src="mymovie.mp4" type='video/mp4; codecs="avc1.42E01E, mp4a.40.2"'> </video> support: IE9, FF3.6, Safari, Chrome, Opera
40. video for all browsers Multiple encodings Graceful degradation <video width="320" height="240" controls> <source src="mymovie.ogv"> <source src="mymovie.mp4"> <object data="videoplayer.swf"> <param name="flashvars" value="mymovie.mp4"> HTML5 and Flash video not supported </object> </video>
42. input types* tag: time, date, search, email, etc. Web Forms 2.0 HTML5 Forms <form> <input type="email" autofocus="autofocus" placeholder="Enter your email" /> </form> support: Safari, FF4*, Chrome, Opera
43. browser autofocus Improved usability Supported in Safari, Chrome, Opera (so far) <form name="f"> <input id="q" autofocus> <!--Technique to support older browsers--> <script> if (!("autofocus" in document.createElement("input"))) { document.getElementById("q").focus(); } </script> <input type="submit" value="Go"> </form>
44. geolocation opt-in user feature to share physical position navigator.geolocation.getCurrentPosition(callback); function callback(position){ varlat = position.coords.latitude; varlng = position.coords.longitude; varacc = position.coords.accuracy; } support: IE9, Safari, FF3.5, Chrome, Opera
45. local storage sessionStorage = per window localStorage = per browser <script> sessionStorage.setItem('value', this.value); localStorage.setItem('value', this.value); sessionStorage.getItem(‘value’); sessionStorage.clear(); localStorage.clear(); </script> 5 MB limit support: IE9, FF3.5, Safari, Chrome, Opera
46. messaging send cross-document (and domain) local messages //Sender (http://example.com) varo = $('iframe')[0]; o.contentWindow.postMessage('Hello world','http://b.example.org/'); //Receiver (http://b.example.org) window.addEventListener('message', receiver, false); function receiver(e) { if (e.origin == 'http://example.com') alert(e.data); } support: IE8, FF3.5, Safari, Chrome, Opera
51. offline tag: <html manifest="html5demo.manifest"> MIME type: text/cache-manifest CACHE MANIFEST # Files you want cached for your app to work offline myLogo.jpg //Interacting with cache window.applicationCache.update(); alert(window.applicationCache.status); support: FF3.5, Safari, Chrome,Opera 10.6
52. web sockets api: WebSocket ws = new WebSocket("ws://localhost:8282/test”); ws.onopen = WSonOpen; ws.onmessage = WSonMessage; ws.onclose = WSonClose; ws.onerror = WSonError; function WSonMessage(event) { $(“#myDiv”).html(event.data); }; support: IE9**, Safari 5, Chrome, FF4*, Opera 11*
53. web sql api: openDatabase db= openDatabase("html5demos", "1.0", "HTML 5 Database API example", 200000); if (db) { db.transaction(function(tx) { tx.executeSql("CREATE TABLE IF NOT EXISTS tweets (id REAL UNIQUE, text TEXT, created_atTEXT, screen_name TEXT, mention BOOLEAN)", [], callback); }); } db.transaction(function (tx) { tx.executeSql('SELECT * FROM tweets WHERE mention = ? AND id > ? ORDER BY id DESC', [mention, latest], callbackFunc);}); “This specification has reached an impasse: all interested implementors have used the same SQL backend (Sqlite), but we need multiple independent implementations to proceed along a standardisation path.” –W3C support: Safari, Chrome, Opera
54. indexedDB JavaScript API for indexed local storage var request = window.indexedDB.open("CandyDB", "My candy store database"); request.onsuccess= function(event) { vardb = event.result; if (db.version != "1") { // User's first visit, initialize database. ... } } support: IE9*, FF4, (Chrome)
55. web workers background threads for JavaScript var worker = new Worker('worker.js'); worker.onmessage= function (event) { $('#result').innerHTML= event.data; }; //Worker communicates via postMessage([value]); support: FF3.5, Safari, Chrome,Opera
59. leveling the playing field CSS Reset Browsers ship with built-in styles – zero them out! Enable newer features in older browsers http://html5reset.org http://html5boilerplate.com
62. Web Font Providers Solve the licensing problem Host the TTF/OTF font files Provide easy-to-use code http://code.google.com/webfonts http://webfonts.fonts.com http://typekit.com/libraries
63. rounded corners Easy corner control Expect GD for older browsers (IE) -moz-border-radius: 5px 5px 5px 5px; //Optionally ”explicit” -webkit-border-radius: 5px; border-radius: 5px; //Can also control specific corners border-bottom-left-radius:0px; border-bottom-right-radius:0px;
64. drop shadows Exactly like it sounds box-shadow: <hShift> <vShift> <size> <color>; -moz-box-shadow: 2px 2px2px #333; -webkit-box-shadow: 2px 2px2px #333; box-shadow: 2px 2px2px #333;
66. Backgrounds More options, more power multiple backgrounds resize backgrounds background clipping /*Background size*/ -webkit-background-size: 137px 50px; -o-background-size: 137px 50px; background-size: 137px 50px; /*Multiple Backgrounds*/ background: url(top.gif) top left no-repeat, url(bottom.gif) bottom left no-repeat, url(middle.gif) left repeat-y; /*Background origin*/ background-origin: border; /*Other options: padding or content*/
67. Gradients Not CSS3! But useful and desirable Can be “shived” to support all browsers
68. LESS for CSS Use LESS to write less CSS Variables, operations, mix-ins, nested rules /*Variables*/ @primaryColor: #383939; background-color: @primaryColor; /*Mix-ins!!*/ .roundedCorners (@radius: 12px) { -moz-border-radius: @radius; -webkit-border-radius: @radius; border-radius: @radius; } #page { background-color: @primaryColor; .roundedCorners; }
69. animating with CSS Animate by setting CSS properties Works when JS is disabled #id_of_element { -webkit-transition: all 1s ease-in-out; -moz-transition: all 1s ease-in-out; -o-transition: all 1s ease-in-out; transition: all 1s ease-in-out; }
76. media queries Target styles to specific devices… And features! /*These two rules do the same thing*/ @media all and (min-width:500px) { … } @media (min-width:500px) { … } /*Multiple conditions*/ @media screen and (min-width: 600px) and (max-width: 900px) { .class { background: #333; } }
84. The consumer should be able to decide which technologies they want to use, but a multi-platform world is definitely where the world is headed. -ShantanuNarayen April, 2010
85. The future of the web is HTML5. -Dean Hachamovitch April, 2010
86. Your Feedback is Important Please fill out a session evaluation form drop it off at the conference registration desk. Thank you! telerikwatch.com @toddanglin anglin@telerik.com
88. CSS3 Resources LESS CSS “framework” + tutorial http://designshack.co.uk/articles/css/using-less-js-to-simplify-your-css3 LESS T4 Template from Phil Haack http://haacked.com/archive/2009/12/02/t4-template-for-less-css.aspx LESS VS CSS code highlighting http://visualstudiogallery.msdn.microsoft.com/en-us/dd5635b0-3c70-484f-abcb-cbdcabaa9923
89. Slide Title Please use this template for your slides Please DO NOT change the format of this template Please DO NOT use special formatting such as shadowing for code or images, or shadows behind boxes, etc. Please DO NOT use layers or slides because the text is unreadable when printed as handouts for students. Please send completed slides to erik@devconnections.com Filename for slides should be: lastname_conference_sessionnum_sessiontitle.ppt Please zip all files before sending them. Include sample code for the attendee disk in a subfolder.
Editor's Notes
Going off-template for better instructional effectiveness
http://www.apple.com/hotnews/thoughts-on-flash/
Talk about the major “platforms” for the web. Introduce the players.
Looking for people to identify that Flash, Silverlight, and HTML5 are all competing to deliver the rich web
Ian Hickson of Google, Inc. is the editor of HTML5Fun facts:- It takes about 10 years to build a nuclear power plant (http://wiki.answers.com/Q/How_long_does_it_take_to_build_a_Nuclear_Power_Station)- Deposit $10/day for 12 years @ 8% = $73,000 (http://calcnexus.com/savings-calculator.php)
he HTML5 specification will not be considered finished before there are at least two complete implementations of the specification.http://www.w3.org/TR/html5-diff/#backwards-compatibleThe Living Standard: http://www.whatwg.org/specs/web-apps/current-work/multipage/
Mozilla’s take on IE9: http://people.mozilla.com/~prouget/ie9/ie9_vs_fx4.htmlTesting older IE: http://spoon.net/ie6(News on MSFT take down of testable browsers: http://blog.thomascsherman.com/2010/11/spoon-net-forced-to-pull-internet-explorer/)Another old IE option: http://www.my-debugbar.com/wiki/IETester/HomePageOfficial MSFT option for testing old IE: http://www.microsoft.com/downloads/en/details.aspx?FamilyID=21eabb90-958f-4b64-b5f1-73d0a413c8ef&displaylang=en
http://code.google.com/p/ie7-js/Testing IE:http://spoon.net/browsers/Three choices: Hack it – Force features with JS shivsSupport it – Provide gracefully degraded experienceKill it – Provide message indicating no or limited support
http://www.javascriptkit.com/dhtmltutors/customattributes.shtmlhttp://html5doctor.com/html5-custom-data-attributes/Two methods of access:- Via Attributes (http://api.jquery.com/category/attributes/)Via “dataset” (plug-in required today: http://www.orangesoda.net/jquery.dataset.html)
http://diveintohtml5.org/video.html
Chrome H.264 from MSFT:http://arstechnica.com/microsoft/news/2011/02/microsoft-offers-h264-plugin-for-chrome-queries-google-on-webm.arshttp://blogs.msdn.com/b/ie/archive/2011/02/01/html5-and-web-video-questions-for-the-industry-from-the-community.aspxChrome’s pull of H.264: http://arstechnica.com/web/news/2011/01/googles-dropping-h264-from-chrome-a-step-backward-for-openness.ars/
WebM support via a plug-in: http://tools.google.com/dlpage/webmmfTechCrunch on WebM: http://techcrunch.com/2011/01/14/webm-plugins/
http://www.whatwg.org/specs/web-apps/current-work/multipage/states-of-the-type-attribute.html#states-of-the-type-attributehttp://www.html5laboratory.com/s/simple-html5-contact-form.htmlWeb Forms 2 (old spec – now Forms in HTML5): http://dev.w3.org/html5/web-forms-2/http://www.whatwg.org/specs/web-apps/current-work/multipage/forms.html#formsDefined input types: http://www.whatwg.org/specs/web-apps/current-work/multipage/the-input-element.html#the-input-elementCross browser input types: http://net.tutsplus.com/tutorials/html-css-techniques/how-to-build-cross-browser-html5-forms/Cross browser forms 2.0: https://github.com/westonruter/webforms2
http://diveintohtml5.org/forms.html
http://diveintohtml5.org/geolocation.htmlSpec: http://dev.w3.org/geo/api/spec-source.htmlOnly lat, long, acc are guranteed. Other values might be available, including altitude, altitudeAccuracy, heading, speedCan force maximum age for cached geolocation objectsCan handle errors and make repeat location calls using navigatior.geolocation.watchPosition(successCallback, errorCallback, {maximumAge:time})Google Maps API v3 Reference: http://code.google.com/apis/maps/documentation/javascript/basics.html(Free to use on all apps that are free to consumers – no API keys needed)
http://upload.wikimedia.org/wikipedia/en/d/d0/Chrome_Logo.svgComparison articles:Great comparison: http://dev.opera.com/articles/view/svg-or-canvas-choosing-between-the-two/http://blogs.sitepoint.com/2010/07/06/canvas-vs-svg-how-to-choose/ (IDEA: progressive enhancement techniques — for example, IE8 and earlier versions show a table of data whereas supported browsers show an animated pie chart.)SVG Bridge for all browsers:http://raphaeljs.com/CANVAS Bridge for IE: http://code.google.com/p/explorercanvas/(Pointless canvas example: http://paulirish.com/2010/high-res-browser-icons/)SVG is DOM-based. All elements exist in DOM. Thus, you can attach event handlers. CON: Many objects can hurt perf.CANVAS is PIXEL-based. All elements rendered quickly, but not part of DOM. CON: Harder to interact.
http://html5demos.com/offlineapphttp://diveintohtml5.org/offline.htmlhttp://html5doctor.com/go-offline-with-application-cache/ (Good practical tips)Inspect appcache in Chrome: chrome://appcache-internals/Stephen Walther on using ASP.NET to serve Cache manifest: http://stephenwalther.com/blog/archive/2011/01/26/creating-html5-offline-web-applications-with-asp-net.aspxFix IIS Express manifest type: http://www.danielroot.info/2010/07/how-microsofty-writes-ipad-apps.htmlC:\\Users\\{YOU}\\Documents\\IISExpress\\config\\applicationHost.configComment out the .manifest mime type (sorry ClickOnce!)Add the following line: <mimeMapfileExtension=".manifest" mimeType="text/cache-manifest" />Can also override in IIS7+ config (integrated pipeline):<system.webServer> <staticContent> <mimeMapfileExtension=".manifest" mimeType="text/cache-manifest" /> </staticContent> </system.webServer>Application Cache API: http://www.w3.org/TR/html5/offline.html#application-cache-api
Example code for .NET WebSockets:http://www.undisciplinedbytes.com/2010/06/html-5-c-web-sockets-server-and-asp-net-client-implementation/Online demo: http://websocket.org/echo.htmlOpera on Sockets:http://my.opera.com/core/blog/websocketsSockets disabled by default in FF and Opera: http://annevankesteren.nl/2010/12/websocket-protocol-vulnerabilityEnabling sockets in Opera 11: opera:config#UserPrefs|EnableWebSocketsEnabling sockets in FF4: about:config -> network.websocket.override-security-block;trueIE9 can do WebSockets via a prototype Silverlight hack: http://html5labs.interoperabilitybridges.com/prototypes/available-for-download/websocketsLimits: http://html5labs.interoperabilitybridges.com/media/2311/readme.htmSockets vs. traditional polling performance: http://soa.sys-con.com/node/13154733rd party sockets solution for older browsers:
WebSql is not proceeding: http://dev.w3.org/html5/webdatabase/State of web local storage: http://rethink.unspace.ca/2010/5/10/the-state-of-html5-local-data-storageReplacement Tech is IndexedDB:http://dvcs.w3.org/hg/IndexedDB/raw-file/tip/Overview.htmlSyncing back to a server database: http://stackoverflow.com/questions/1744522/best-way-to-synchronize-local-html5-db-storage-with-a-serverPersistenceJS:https://github.com/zefhemel/persistencejsGoogle Web Stroage Portability Layer: http://google-opensource.blogspot.com/2009/05/web-storage-portability-layer-common.html
Kills Google Gearshttp://www.w3.org/TR/IndexedDB/https://developer.mozilla.org/en/IndexedDBhttp://www.html5rocks.com/tutorials/indexeddb/todo/Good comparison by Mozilla to formerWebDatabase approach: http://hacks.mozilla.org/2010/06/comparing-indexeddb-and-webdatabase/
http://en.wikipedia.org/wiki/Cascading_Style_SheetsIE Mac: Shipped in March 20009 style sheet languages proposed in early 90sLanguages:1996:JavaScript Style Sheets (JSSS) – Netscape1994: Cascading HTML Style Sheets (CHSS)1994: Stream-based Style Sheet Proposal (SSP)
New CSS3 featuresCSS3 principlesShow example of CSS3 in actionList of all CSS properties:http://meiert.com/en/indices/css-properties/http://www.w3.org/Style/CSS/current-workhttp://www.w3.org/TR/2010/WD-css-2010-20101202/#css3
Microsoft Extensions: http://blogs.msdn.com/b/ie/archive/2008/09/08/microsoft-css-vendor-extensions.aspxVendor specific prefixes: http://reference.sitepoint.com/css/vendorspecific
@font-face was first proposed for CSS2 and has been implemented in Internet Explorer since version 5IE relied on proprietary Embedded Open Type (.eot)Old school solutions involved things like sIFR (http://www.mikeindustries.com/blog/sifr/)Modern browsers finally support TTF and OTFResources:http://www.css3.info/preview/web-fonts-with-font-face/http://www.alistapart.com/articles/cssatten
Making fonts compatible with IE requires some work-around:http://randsco.com/index.php/2009/07/04/p680
Fix “bleeding” in Webkit with: -webkit-background-clip: padding-box;http://tumble.sneak.co.nz/post/928998513/fixing-the-background-bleed
Great tutorial:http://designshack.co.uk/articles/css/using-less-js-to-simplify-your-css3LESS site: http://lesscss.org/Enable .less with IIS Express:C:\\Program Files (x86)\\IIS Express>appcmd set config /section:staticContent /+[fileExtension='.less',mimeType='text/css']
General discussion of best practices: http://dev.opera.com/articles/view/designing-and-developing-mobile-web-site/ (a bit old, from 2007, but some good concepts)
http://matt.might.net/articles/how-to-native-iphone-ipad-apps-in-javascript/http://html5boilerplate.com/docs/#the-markuphttp://developer.apple.com/library/safari/#documentation/AppleApplications/Reference/SafariHTMLRef/Articles/MetaTags.html#//apple_ref/doc/uid/TP40008193Discussion of viewport and older mobile meta tags: http://davidbcalhoun.com/tag/handheldfriendly
http://www.webdesignerwall.com/tutorials/css3-media-queries/http://www.w3.org/TR/css3-mediaqueries/Code for targeting iPhone: http://perishablepress.com/press/2010/10/20/target-iphone-and-ipad-with-css3-media-queries/
