ABB TPU5 Indoor Current Transformers (CT) MV Medium Voltage
ABB TPU5 Indoor Current Transformers (CT) 13.8kV 17.5kV
MV Medium Voltage CT's Current Transformers from ABB
TPU5 Indoor Current Transformers MV
ABB TPU5 Indoor Current Transformers for MV Medium Voltage Power
Highest Voltage for Transformer 13.8kV - 17.5kV
Power Frequency Test Voltage 1 Min 34kV to 42kV
Lightning Impulse Test Voltage upto 95kV
Rated Primary Current 10-3200Amps
Rated Short-Time Thermal Current 2 up to 100kA 1s
Reconnectable (Primary 400-800Amps) Primary or Secondary
Rated Primary Voltages 13.8kV 17.5kV
Rated Primary Currents Amps 10, 15, 20, 25, 30, 40, 50, 60, 75, 100, 150, 200, 300, 400, 500, 600, 750, 1000, 1250, 1500, 2000, 2500, 3000 and 3200Amps
Transformer Standards IEC, VDDE, ANSI, BS, GOST and CSN
Indoor CT MV Transformers IP40 Protection
ABB TPU5 indoor current transformers (CT's) for MV medium voltage power applications are cast in epoxy resin and designed for insulation voltages up to 13.8kV 17.5kV. The 13.8kV 17.5kV indoor medium voltage current transformers have the same dimensions as the 11kV-12kV range of indoor transformers. ABB indoor current transformers can be ordered with "ribs on top" to extend the creepage distance on transformers for specific medium voltage panel applications.
ABB TPU5 MV medium voltage current transformers are designed as single-turn or multi-turn versions, with one transformer ratio or with double ratio having the possibility to be reconnectable on the primary or secondary medium voltage MV power supply side.
The number of secondary windings (from 1 to 6 - maximum 12 secondary terminals - 2 rows), depends on the combination of the technical parameters (such as accuracy class, burden, short-circuit current, overcurrent factor) and the actual current transformer size.
ABB TPU indoor current transformers (CT's) can be provided with a medium voltage indication system.
The secondary windings on ABB TPU MV current transformers are used for measurement or protection purposes or for testing transformer winding. One terminal of each secondary winding used and one terminal of short-circuited and not used winding have to be earthed during the medium voltage transformer operation. The secondary transformer windings are lead out into a cast-type secondary terminal box with plastic cover. The terminal cover is sealable - terminals are provided with M5 screws for the termination and with entry holes for direct earthing (secondary terminal first row).
MV Medium Voltage Indoor Transformers - ABB indoor transformers should be mounted in dry indoor conditions where the ambient air is not significantly polluted by dust, smoke, corrosive gases, vapours or salt. ABB indoor transformers are designed for standard ambient indoor temperatures between -5 degrees Celsius to +40 degrees Celsius. ABB indoor transformers may be used in higher or lower temperatures.
DC testing has been accepted for many years as the standard field method for performing high-voltage tests on cable insulation systems. Whenever DC testing is performed, full consideration should be given to the fact that steady-state direct voltage creates within the insulation systems an electrical field determined by the geometry and conductance of the insulation, whereas under service conditions, alternating voltage creates an electric field determined chiefly by the geometry and dielectric constant (or capacitance) of the insulation.
Under ideal, homogeneously uniform insulation conditions, the mathematical formulas governing the steady-state stress distribution within the cable insulation are of the same form for DC and for AC, resulting incomparable relative values; however, should the cable insulation contain defects in which either the conductivity or the dielectric constant assume values significantly different from those in the bulk of the insulation,the electric stress distribution obtained with direct voltage will no longer correspond to that obtained with alternating voltage.
7SJ62 Multifunction Over Current Protection Relayashwini reliserv
The SIPROTEC 4 7SJ62 relays can be used for line protection of high and medium voltage networks with earthed (grounded), low-resistance earthed, isolated or compensated neutral point. With regard to motor protection, the SIPROTEC 4 7SJ62 is suitable for asynchronous machines of all sizes. The relay performs all functions of backup protection supplementary to transformer differential protection. 7SJ62 is featuring the "flexible protection functions". Up to 20 protection functions can be added according to individual requirements. Thus, for example, a rate-of-frequency-change protection or reverse power protection can be implemented.
ABB Power Products - Medium & High Voltage Transformers
Cast Resin Trasformers
ABB Power Products
ABB TDC voltage transformer for medium voltage systems has all parts of its primary winding, including terminals, insulated from the earth at a level corresponding to its rated insulation level . Indoor dry type, cast resin insulated medium voltage (MV) transformer for measuring and protection with up to 2 secondary windings.
Cast Resin Transformers are constructed with their HV high voltage windings encapsulated in resin and are an excellent alternative to traditional oil immersed transformers. Cast resin transformers encase the windings in epoxy resin : these HV high voltage cast resin transformers simplify installation since they are dry, without cooling oil, and so require no fire-proof vault for indoor installations. The epoxy resin protects the high voltage transformer windings from dust and corrosive atmospheres.
ABB TDC Voltage Transformer
ABB MV Medium Voltage Transformers - Voltage Transformer Features
Indoor dry type, cast resin insulated transformers for medium voltages (MV). ABB transformers are suitable for measuring and protection of MV medium voltages with up to 2 secondary windings. ABB offers a full range of medium voltage (MV) and high voltage (HV) transformer products and solutions for ANSI, IEC and other local standards. ABB is a major transformer manufacturer throughout the world and offers both liquid-filled and dry-type transfomers for medium and high voltage power distribution, measurement and protection.
T&D distribute ABB fuses, vacuum contactors, surge arresters, capacitors, plugs and sockets for LV, MV and HV electrical distribution and cable systems.
São 10 Apostilas de desenvolvimento profissional voltado a construção civil. São cursos das áreas de, pedreiro, gesseiro, eletricista, carpinteiro, armador, pintor, bombeiro hidráulico, segurança do trabalho que os ajudarão a expandir conhecimentos de forma técnica e profissional.
ABB TPU5 Indoor Current Transformers (CT) MV Medium Voltage
ABB TPU5 Indoor Current Transformers (CT) 13.8kV 17.5kV
MV Medium Voltage CT's Current Transformers from ABB
TPU5 Indoor Current Transformers MV
ABB TPU5 Indoor Current Transformers for MV Medium Voltage Power
Highest Voltage for Transformer 13.8kV - 17.5kV
Power Frequency Test Voltage 1 Min 34kV to 42kV
Lightning Impulse Test Voltage upto 95kV
Rated Primary Current 10-3200Amps
Rated Short-Time Thermal Current 2 up to 100kA 1s
Reconnectable (Primary 400-800Amps) Primary or Secondary
Rated Primary Voltages 13.8kV 17.5kV
Rated Primary Currents Amps 10, 15, 20, 25, 30, 40, 50, 60, 75, 100, 150, 200, 300, 400, 500, 600, 750, 1000, 1250, 1500, 2000, 2500, 3000 and 3200Amps
Transformer Standards IEC, VDDE, ANSI, BS, GOST and CSN
Indoor CT MV Transformers IP40 Protection
ABB TPU5 indoor current transformers (CT's) for MV medium voltage power applications are cast in epoxy resin and designed for insulation voltages up to 13.8kV 17.5kV. The 13.8kV 17.5kV indoor medium voltage current transformers have the same dimensions as the 11kV-12kV range of indoor transformers. ABB indoor current transformers can be ordered with "ribs on top" to extend the creepage distance on transformers for specific medium voltage panel applications.
ABB TPU5 MV medium voltage current transformers are designed as single-turn or multi-turn versions, with one transformer ratio or with double ratio having the possibility to be reconnectable on the primary or secondary medium voltage MV power supply side.
The number of secondary windings (from 1 to 6 - maximum 12 secondary terminals - 2 rows), depends on the combination of the technical parameters (such as accuracy class, burden, short-circuit current, overcurrent factor) and the actual current transformer size.
ABB TPU indoor current transformers (CT's) can be provided with a medium voltage indication system.
The secondary windings on ABB TPU MV current transformers are used for measurement or protection purposes or for testing transformer winding. One terminal of each secondary winding used and one terminal of short-circuited and not used winding have to be earthed during the medium voltage transformer operation. The secondary transformer windings are lead out into a cast-type secondary terminal box with plastic cover. The terminal cover is sealable - terminals are provided with M5 screws for the termination and with entry holes for direct earthing (secondary terminal first row).
MV Medium Voltage Indoor Transformers - ABB indoor transformers should be mounted in dry indoor conditions where the ambient air is not significantly polluted by dust, smoke, corrosive gases, vapours or salt. ABB indoor transformers are designed for standard ambient indoor temperatures between -5 degrees Celsius to +40 degrees Celsius. ABB indoor transformers may be used in higher or lower temperatures.
ABB Power Products - Medium & High Voltage Transformers
Cast Resin Transformers
ABB Power Products
ABB TJC is a single phase voltage transformer which is intended to have one end of its primary winding directly earthed. Indoor dry type, cast resin insulated medium voltage transformer for measuring and protection with up to 2 secondary windings. With or without fuses. Most electrical standards available. Reconnectable MV medium voltage versions available.
Cast Resin Transformers are constructed with their HV high voltage windings encapsulated in resin and are an excellent alternative to traditional oil immersed transformers. Cast resin transformers encase the windings in epoxy resin : these HV high voltage cast resin transformers simplify installation since they are dry, without cooling oil, and so require no fire-proof vault for indoor installations. The epoxy resin protects the high voltage transformer windings from dust and corrosive atmospheres.
ABB TJC Single Phase Voltage Transformer
ABB MV Medium Voltage Transformers - Voltage Transformer Features
Indoor dry type, cast resin insulated transformers for medium voltages (MV). ABB transformers are suitable for measuring and protection of MV medium voltages with up to 2 secondary windings. ABB offers a full range of medium voltage (MV) and high voltage (HV) transformer products and solutions for ANSI, IEC and other local standards. ABB is a major transformer manufacturer throughout the world and offers both liquid-filled and dry-type transfomers for medium and high voltage power distribution, measurement and protection.
T&D distribute ABB fuses, vacuum contactors, surge arresters, capacitors, plugs and sockets for LV, MV and HV electrical distribution and cable systems.
ABB TPU6 Indoor Current Transformers (CT) MV Medium Voltage
ABB TPU6 Indoor Current Transformers (CT) 24kV 25kV
MV Medium Voltage CT's Current Transformers from ABB
TPU6 Indoor Current Transformers MV
ABB TPU6 Indoor Current Transformers for MV Medium Voltage Power
Highest Voltage for Transformer 24kV 25kV
Power Frequency Test Voltage 1 Min 50kV to 55kV
Lightning Impulse Test Voltage upto 125kV
Rated Primary Current 10-3200Amps
Rated Short-Time Thermal Current 2 up to 100kA 1s
Reconnectable (Primary 400-800Amps) Primary or Secondary
Rated Primary Voltages 24kV 25kV
Rated Primary Currents Amps 10, 15, 20, 25, 30, 40, 50, 60, 75, 100, 150, 200, 300, 400, 500, 600, 750, 1000, 1250, 1500, 2000, 2500, 3000 and 3200Amps
Transformer Standards IEC, VDDE, ANSI, BS, GOST and CSN
Indoor CT MV Transformers IP40 Protection
ABB TPU6 indoor current transformers (CT's) for MV medium voltage power applications are cast in epoxy resin and designed for insulation voltages up to 24-25kV. The 24-25kV indoor medium voltage current transformers have the same dimensions as the 24-25kV range of indoor transformers. ABB indoor current transformers can be ordered with "ribs on top" to extend the creepage distance on transformers for specific medium voltage panel applications.
ABB TPU6 MV medium voltage current transformers are designed as single-turn or multi-turn versions, with one transformer ratio or with double ratio having the possibility to be reconnectable on the primary or secondary medium voltage MV power supply side.
The number of secondary windings (from 1 to 6 - maximum 12 secondary terminals - 2 rows), depends on the combination of the technical parameters (such as accuracy class, burden, short-circuit current, overcurrent factor) and the actual current transformer size.
ABB TPU indoor current transformers (CT's) can be provided with a medium voltage indication system.
The secondary windings on ABB TPU MV current transformers are used for measurement or protection purposes or for testing transformer winding. One terminal of each secondary winding used and one terminal of short-circuited and not used winding have to be earthed during the medium voltage transformer operation. The secondary transformer windings are lead out into a cast-type secondary terminal box with plastic cover. The terminal cover is sealable - terminals are provided with M5 screws for the termination and with entry holes for direct earthing (secondary terminal first row).
MV Medium Voltage Indoor Transformers - ABB indoor transformers should be mounted in dry indoor conditions where the ambient air is not significantly polluted by dust, smoke, corrosive gases, vapours or salt. ABB indoor transformers are designed for standard ambient indoor temperatures between -5 degrees Celsius to +40 degrees Celsius. ABB indoor transformers may be used in higher or lower temperatures.
