Millenium Range from ABB
Global brand ABB has outdone themselves with the new Millennium series of switches and sockets that offer a new dimension of functionality and aesthetics while being environmentally friendly. The Millennium collection is the first metal range to incorporate the KNX system, the most intelligent way of managing spaces and optimizing performance in terms of energy savings.
The Millennium light signals are based on LED technology, leading to a saving in energy consumption and extending their usage life. The optimization of Millennium™s design, production and distribution process allows the impact in the environment to be reduced substantially. What™s more, the new Millenium series also comes in recyclable packaging that reduces raw material consumption.
Besides the made-in-Spain design and technology, Millennium€™s design and functionality converts into numerous technical and installation advantages. The wide range of switches boasts slim line design with straight and square lines, modern and contemporary finishes that is made in real stainless steel material, and the first British Standard range with wide rocker and metal finish that has a screw less front plate.
The Millenium series has been specially designed to reduce the environmental impact throughout its product life cycle; from design to production, operation, distribution and product recall. It is no wonder that it is the first British Standard range of wiring accessories with Eco design Certificate. Having won the Design awards Interior Innovation Award and the red dot design award in 2013, it is needless to say that this range offers elegance and distinction and is the perfect match to all living spaces.
