1. (2) Introduction of C# Basics – Part I
Nico Ludwig (@ersatzteilchen)

2. 2
TOC
● (2) Introduction of C# Basics – Part I
– A Tour through other .Net Programming Languages
– C# Syntax Cornerstones

3. 3
Challenge: Parse an Update Log
● Userstory: "As an administrator I want to know the latest updates on a PC, in order to get a report of that PC's state!"
● It is needed to parse the file "Software Update.log":
2009-04-06 12:43:04 +0200: Installed "GarageBand Update" (5.0.1)
2009-04-06 12:44:34 +0200: Installed "iMovie Update" (8.0.1)
2009-07-30 13:11:28 +0200: Installed "iMovie Update" (8.0.4)
2009-04-06 12:43:31 +0200: Installed "iTunes" (8.1)
…
● How can we solve this problem?

4. 4
Visual Basic 10 (VB 10)
Imports System
Imports System.IO
Imports System.Collections.Generic
Imports System.Text.RegularExpressions
Module Program
Sub Main()
' check arguments from console
If (0 < My.Application.CommandLineArgs.Count) Then
Dim latestUpdates As IDictionary(Of String, String) = New SortedDictionary(Of String, String)
Dim parseRex As Regex = New Regex("[^""]*""(?<appName>[^""]*)""s*((?<versionNo>[^(]*))")
' open and check file, read a line
For Each aLine As String In File.ReadAllLines(My.Application.CommandLineArgs.Item(0))
' parse the line: e.g. 2009-04-06 12:42:58 +0200: Installed "Digital Camera Raw Compatibility Update" (2.5)
Dim match As Match = parseRex.Match(aLine)
If (match.Success) Then
' store the parsed data
Dim appName As String = match.Groups.Item("appName").ToString()
Dim versionNo As String = match.Groups.Item("versionNo").ToString()
If (latestUpdates.ContainsKey(appName)) Then
If (0 < String.CompareOrdinal(versionNo, latestUpdates.Item(appName))) Then
latestUpdates.Item(appName) = versionNo
End If
Else
latestUpdates.Add(appName, versionNo)
End If
End If
Next
' output the collected data to console
For Each item As KeyValuePair(Of String, String) In latestUpdates
Console.WriteLine("App: {0}, Latest Update: {1}", item.Key, item.Value)
Next
End If
End Sub
End Module

5. 5
C++/CLI – Part I
#include "stdafx.h"
using namespace System;
using namespace System::IO;
using namespace System::Collections::Generic;
using namespace System::Text::RegularExpressions;
int main(array<String^>^ args)
{
// check arguments from console
if (0 < args->Length)
{
IDictionary<String^, String^>^ latestUpdates = gcnew SortedDictionary<String^, String^>();
Regex^ parseRex = gcnew Regex("[^"]*"(?<appName>[^"]*)"s*((?<versionNo>[^(]*))");
// open and check file, read a line
for each (String^ aLine in File::ReadAllLines(args[0]))
{
// parse the line: e.g. 2009-04-06 12:42:58 +0200: Installed "Digital Camera Raw Compatibility Update" (2.5)
Match^ match = parseRex->Match(aLine);
if (match->Success)
{
// store the parsed data
String^ appName = match->Groups["appName"]->ToString();
String^ versionNo = match->Groups["versionNo"]->ToString();
if (latestUpdates->ContainsKey(appName))
{
if (0 < String::CompareOrdinal(versionNo, latestUpdates[appName]))
{
latestUpdates[appName] = versionNo;
}
}
else

6. 6
C++/CLI – Part II
{
latestUpdates->Add(appName, versionNo);
}
}
}
// output the collected data to console
for each (KeyValuePair<String^, String^>^ item in latestUpdates)
{
Console::WriteLine("App: {0}, Latest Update: {1}", item->Key, item->Value);
}
}
}

7. 7
F# 3
#light
open System
open System.IO
open System.Text.RegularExpressions
if 2 >= Environment.GetCommandLineArgs().Length then
let parseRex = new Regex(@"[^""]*""(?<appName>[^""]*)""s*((?<versionNo>[^(]*))")
// open and check file, read the lines, parse and process the data, output the processed data to console
File.ReadLines(Environment.GetCommandLineArgs().GetValue(1).ToString())
|> Seq.map(parseRex.Match)
|> Seq.filter(fun theMatch -> theMatch.Success)
|> Seq.sortBy(fun theMatch -> theMatch.Groups.Item("versionNo").ToString())
|> Seq.map(fun theMatch -> theMatch.Groups.Item("appName").ToString(), theMatch.Groups.Item("versionNo").ToString())
|> dict
|> Seq.sortBy(fun item -> item.Key)
|> Seq.iter(fun item -> printfn "App: %s, Latest Update: %s" item.Key item.Value)

8. 8
C# 5 – Part I
using System;
using System.IO;
using System.Collections.Generic;
using System.Text.RegularExpressions;
public class Program
{
public static void Main(string[] args)
{
// check arguments from console
if (0 < args.Length)
{
IDictionary<string, string> latestUpdates = new SortedDictionary<string, string>();
Regex parseRex = new Regex(@"[^""]*""(?<appName>[^""]*)""s*((?<versionNo>[^(]*))");
// open and check file, read a line
foreach (string aLine in File.ReadAllLines(args[0]))
{
// parse the line: e.g. 2009-04-06 12:42:58 +0200: Installed "Digital Camera Raw Compatibility Update" (2.5)
Match match = parseRex.Match(aLine);
if (match.Success)
{
// store the parsed data
string appName = match.Groups["appName"].ToString();
string versionNo = match.Groups["versionNo"].ToString();
if (latestUpdates.ContainsKey(appName))
{
if (0 < string.CompareOrdinal(versionNo, latestUpdates[appName]))
{
latestUpdates[appName] = versionNo;
}
}
else

9. 9
C# 5 – Part II
{
latestUpdates.Add(appName, versionNo);
}
}
}
// output the collected data to console
foreach (KeyValuePair<string, string> item in latestUpdates)
{
Console.WriteLine("App: {0}, Latest Update: {1}", item.Key, item.Value);
}
}
}
}

10. 10
Common Intermediate Language (CIL, also just IL)
IL_0001: ldc.i4.1
IL_0002: newarr System.String
IL_0007: stloc.s 08 // CS$0$0000
IL_0009: ldloc.s 08 // CS$0$0000
IL_000B: ldc.i4.0
IL_000C: ldstr "C:UsersnludwigDesktopapplication.properties"
IL_0011: stelem.ref
IL_0012: ldloc.s 08 // CS$0$0000
IL_0014: stloc.0 // args
IL_0015: ldc.i4.0
IL_0016: ldloc.0 // args
IL_0017: ldlen
IL_0018: conv.i4
IL_0019: clt
IL_001B: ldc.i4.0
IL_001C: ceq
IL_001E: stloc.s 09 // CS$4$0001
IL_0020: ldloc.s 09 // CS$4$0001
IL_0022: brtrue IL_0154
IL_0028: newobj System.Collections.Generic.SortedDictionary<System.String,System.String>..ctor
IL_002D: stloc.1 // latestUpdates
IL_002E: ldstr "[^"]*"(?<appName>[^"]*)"s*((?<versionNo>[^(]*))"
IL_0033: newobj System.Text.RegularExpressions.Regex..ctor
IL_0038: stloc.2 // parseRex
IL_003A: ldloc.0 // args
IL_003B: ldc.i4.0
IL_003C: ldelem.ref
IL_003D: call System.IO.File.ReadAllLines
IL_0042: stloc.s 0A // CS$6$0002
IL_0044: ldc.i4.0
IL_0045: stloc.s 0B // CS$7$0003
IL_0047: br IL_00EF
IL_004C: ldloc.s 0A // CS$6$0002
IL_004E: ldloc.s 0B // CS$7$0003
IL_0050: ldelem.ref
IL_0051: stloc.3 // aLine
IL_0053: ldloc.2 // parseRex
IL_0054: ldloc.3 // aLine
IL_0055: callvirt System.Text.RegularExpressions.Regex.Match
IL_005A: stloc.s 04 // match
IL_005C: ldloc.s 04 // match
IL_005E: callvirt System.Text.RegularExpressions.Group.get_Success
IL_0063: ldc.i4.0
IL_0064: ceq
IL_0066: stloc.s 09 // CS$4$0001
IL_0068: ldloc.s 09 // CS$4$0001
IL_006A: brtrue.s IL_00E8
IL_006D: ldloc.s 04 // match
IL_006F: callvirt System.Text.RegularExpressions.Match.get_Groups
IL_0074: ldstr "appName"
IL_0079: callvirt System.Text.RegularExpressions.GroupCollection.get_Item
IL_007E: callvirt System.Object.ToString
IL_0083: stloc.s 05 // appName
IL_0085: ldloc.s 04 // match
IL_0087: callvirt System.Text.RegularExpressions.Match.get_Groups
IL_008C: ldstr "versionNo"
IL_0091: callvirt System.Text.RegularExpressions.GroupCollection.get_Item
IL_0096: callvirt System.Object.ToString
IL_009B: stloc.s 06 // versionNo
IL_009D: ldloc.1 // latestUpdates
IL_009E: ldloc.s 05 // appName
IL_00A0: callvirt System.Collections.Generic.IDictionary<System.String,System.String>.ContainsKey
IL_00A5: ldc.i4.0
IL_00A6: ceq
IL_00A8: stloc.s 09 // CS$4$0001
IL_00AA: ldloc.s 09 // CS$4$0001
IL_00AC: brtrue.s IL_00DA
IL_00AF: ldc.i4.0
IL_00B0: ldloc.s 06 // versionNo
IL_00B2: ldloc.1 // latestUpdates
IL_00B3: ldloc.s 05 // appName
IL_00B5: callvirt System.Collections.Generic.IDictionary<System.String,System.String>.get_Item
IL_00BA: call System.String.CompareOrdinal
IL_00BF: clt
IL_00C1: ldc.i4.0
IL_00C2: ceq
IL_00C4: stloc.s 09 // CS$4$0001
IL_00C6: ldloc.s 09 // CS$4$0001
IL_00C8: brtrue.s IL_00D7
IL_00CB: ldloc.1 // latestUpdates
IL_00CC: ldloc.s 05 // appName
IL_00CE: ldloc.s 06 // versionNo
IL_00D0: callvirt System.Collections.Generic.IDictionary<System.String,System.String>.set_Item
IL_00D8: br.s IL_00E7
IL_00DB: ldloc.1 // latestUpdates
IL_00DC: ldloc.s 05 // appName
IL_00DE: ldloc.s 06 // versionNo
IL_00E0: callvirt System.Collections.Generic.IDictionary<System.String,System.String>.Add
IL_00E9: ldloc.s 0B // CS$7$0003
IL_00EB: ldc.i4.1
IL_00EC: add
IL_00ED: stloc.s 0B // CS$7$0003
IL_00EF: ldloc.s 0B // CS$7$0003
IL_00F1: ldloc.s 0A // CS$6$0002
IL_00F3: ldlen
IL_00F4: conv.i4
IL_00F5: clt
IL_00F7: stloc.s 09 // CS$4$0001
IL_00F9: ldloc.s 09 // CS$4$0001
IL_00FB: brtrue IL_004C
IL_0101: ldloc.1 // latestUpdates
IL_0102: callvirt System.Collections.Generic.IEnumerable<System.Collections.Generic.KeyValuePair<System.String,System.String>>.GetEnumerator
IL_0107: stloc.s 0C // CS$5$0004
IL_0109: br.s IL_012F
IL_010B: ldloc.s 0C // CS$5$0004
IL_010D: callvirt System.Collections.Generic.IEnumerator<System.Collections.Generic.KeyValuePair<System.String,System.String>>.get_Current
IL_0112: stloc.s 07 // item
IL_0115: ldstr "App: {0}, Latest Update: {1}"
IL_011A: ldloca.s 07 // item
IL_011C: call System.Collections.Generic.KeyValuePair<System.String,System.String>.get_Key
IL_0121: ldloca.s 07 // item
IL_0123: call System.Collections.Generic.KeyValuePair<System.String,System.String>.get_Value
IL_0128: call System.Console.WriteLine
IL_012F: ldloc.s 0C // CS$5$0004
IL_0131: callvirt System.Collections.IEnumerator.MoveNext
IL_0136: stloc.s 09 // CS$4$0001
IL_0138: ldloc.s 09 // CS$4$0001
IL_013A: brtrue.s IL_010B
IL_013C: leave.s IL_0152
IL_013E: ldloc.s 0C // CS$5$0004
IL_0140: ldnull
IL_0141: ceq
IL_0143: stloc.s 09 // CS$4$0001
IL_0145: ldloc.s 09 // CS$4$0001
IL_0147: brtrue.s IL_0151
IL_0149: ldloc.s 0C // CS$5$0004
IL_014B: callvirt System.IDisposable.Dispose
IL_0151: endfinally

11. 11
What is the C# programming language?
● C# is standardized in ECMA-334.
● C# blends features of C++, Java and other popular languages.
– Without C# being based on Java, .Net would not have been a success!
● A CLS compliant language, ECMA and ISO/IEC standard.
● Major platform is Windows (compilers and CLR from MS).

12. 12
C# Core Features
● Multiparadigm language.
● Static typing by default.
● C-style syntax with extensions.
● CTS is the first class type system.
● C# is popular and evolving.
– Relatively short innovation cycles. Learned stuff gets stale early (~two years).
● C# is relatively simple to learn.
– It is basically pointer free. (We could use pointers. The CTS doesn't use pointers.)
– It doesn't use manual memory management, the runtime has a garbage collector.

13. 13
Structure of a C# Console Application
// Program.cs
using System;
namespace ConsoleApplication
{
public class Program
{
// The execution of a program always starts in the method Main().
public static void Main(string[] args)
{
Console.WriteLine("Hello World!");
}
}
}

14. 14
Code Snippets
● Hence we'll begin using snippets as code examples, i.e. no Main() etc.!
// Program.cs
using System;
namespace ConsoleApplication
{
public class Program
{
public static void Main(string[] args)
{
Console.WriteLine("Hello World!");
}
}
}
Console.WriteLine("Hello World!");
● In the end no fully runnable program code will be shown in upcoming lectures!

15. 15
C# as a compiled Language
● C# reserves symbols for its grammar, these are called keywords.
● Syntax versus Semantics:
int count = 2;
count = 2;
– Both statements do not mean the same, but the syntax is similar!
– Locals need to be initialized, uninitialized fields have default values.
● Compile time errors versus run time errors:
int zero = 0;
int oddResult = 42/zero;
– Both statements are ok for the compiler.
● But the last one throws a DivisionByZeroException at run time.

16. 16
C# Syntax Cornerstones – Part I – Imperative Elements
if (answerIsOk) {
Console.WriteLine("Result: "+(3 + 4));
}
● Basic elements: expressions, statements, blocks. They can be freely formatted.
– Imperative programming: Statements and blocks are executed sequentially.
– The order of execution of expressions is strictly defined in C#!
● The most elementary statements are variable definitions.
– Variable definitions make variables applicable in the code.
– By default, variables need to be typed on definition, this is called static typing.
● Implicit and dynamic typing is also possible, but we stick to explicit static typing in this course.
● Besides definition, variables can be initialized and assigned to.
– Initialization gives initial values to a variable.
– Assignment sets a variable to a new value.
int age = 19;
age = 25;
double width = 32.8;

17. 17
C# Syntax Cornerstones – Part II – Types
● Primitive types are integrated types, whose objects can be created with literals.
– Simple value integral types: int, long (etc.).
– Simple value float types: float, double (etc.).
– Simple value boolean type: bool.
– Simple value character type: char.
– Reference text type: string. (an alias C# keyword for the .Net type System.String)
– We can create compile time constants (const) of primitive type.
● There exist value types (e.g. int) and reference types (e.g. string).
– Variables of reference type are often simply called references.
● Explicit type conversion:
// Conversion with cast:
int i = (int)2.78;
– Explicit conversions are done with explicit casts or the as operator.
– Explicit conversions can be done safely with checked expressions and contexts.
– The type System.Convert (various types) and the methods ToString()/Parse() (string).
// Conversion with as:
string text = choice as string;

18. 18
C# Syntax Cornerstones – Part III – Identifiers and
Comments
• C# uses case sensitive identifiers, we have to obey common conventions.
– aString is not the same identifier as aStRiNg!
– We've to use a common notation (e.g. camelCase or PascalCase) as convention!
– Language specific characters can be used (e.g. umlauts) as well as the underscore.
– C# keywords mustn't be used as identifiers.
• Comments can be applied everywhere in code. We should exploit comments!
/* commented */ /** commented */ // commented /// commented (triple slash)
• The usage and definition of methods will be discussed later.
– Methods are .Net's pendant of functions/member functions in other languages.
• In the next slides we're going to understand the most important operators in C#.

19. 19
Operator Notations – Arity
● Binary operators
// Addition as binary operator:
int sum = 2 + 3;
● Unary operators
// Increment as unary operator:
int i = 1;
++i; // Increments i (the result is 2).
● Ternary operator
// The conditional operator is the only ternary operator:
int i = 2;
int j = 3;
string answer = (i < j) ? "i less than j" : "i not less than j";

20. 20
Operator Notations – Placement
● Prefix operators
// Negation as prefix operator:
bool succeeded = !failed;
● Postfix operators
// Increment as postfix operator:
int result = item++;
● Infix operators
// Addition as infix operator:
int sum = 2 + 3;

21. 21
Mathematical Operators
● Binary +, - and *, / are known form elementary mathematics.
– Attention: Integer division yields an integer result!
– The result of the division by 0 results in a run time error.
● A DivisionByZeroException will be thrown.
● Unary – and + as sign-operators.
● Somewhat special: ++/-- and %
● Math.Log(), Math.Pow() and other operations in the class Math.
● Bit operations work with integers as arguments and result in integers.
– Operators: ^, |, &, ~, <<, >>

22. 22
Other Operators and Operator Overloading
● Assignment and combined assignment.
– Operators: =, +=, *=, /= etc.
– Operators: &=, |=, ^=, <<=, >>=
● Concatenation of strings with the operators + and +=.
– But: strings are still immutable!
● Important extra operators:
– Operators: [], (), ?:, ??, new, is, as, typeof
– Operators: ., ::
– Operators: *, ->, sizeof
– Operators: =>
int i = 12;
i = i + 2; // (i = 14) Add and assign.
i += 2; // (i = 16) Add-combined assignment.
● C# permits to redefine (overload) operators for user defined types UDT.

23. 23
Logical Operators
● Used to compare values and combine boolean results.
– Comparison: ==, !=, <, >, <=, >=
– Combination: &&, ||, !
– Logical operators return boolean results, not integral results.
● && (logical and) and || (logical or) support short circuit evaluation.
// The mathematic boolean expression a = b and c = b:
// Ok
if (a == b && c == b) { /* pass */ }
// Wrong!
if (a && b == c) { /* pass */ }
● Logical operators are applied in conditional expressions for control structures (branches and loops).

24. 24
Precedence, Associativity and Order of Execution
● Precedence and precedence groups.
– Some operators have the same precedence and make up a precedence group.
– As operator priority in maths, precedence is controllable with parentheses.
● Associativity defines evaluation among expressions of the same precedence.
– Associativity is defined as a "direction".
– Associativity is controllable with parentheses as well.
● The order of execution within expressions is strictly defined in C#.
– The order is from left to right and from inner to outer.
int i = 0;
Console.WriteLine("{0} {1}", i++, i);
// >0 1 → Always this result …
// Never 0 0!

25. 25
Thank you!
