This document discusses India's national missions and goals regarding sustainable power development through green power technologies. It outlines India's three stage nuclear power programme and goals to increase renewable energy and clean coal technologies. The document also summarizes the challenges of increasing power generation while reducing greenhouse gas emissions and the impacts of climate change. It promotes utilizing green energy technologies like carbon capture and storage to help India meet its energy needs in a sustainable manner.

1. “Sustainable Power Development
through Green Power
Technologies”
Presented By:

2. Power Generation
Transmission & Distribution
At a Glance

4. Thermal

5. Three Stage Indian Nuclear Power Programme
Stage – I
PHWRs
• 17 Operating (4240
MWe)
• 1 to start soon(220 MWe)
• 4– 700 MWe units under
construction (2800 Mwe)
•Several 700 MWe units
planned
LWRs
• 2 BWRs Operating
(320MWe)
• 2 VVERs under
construction (2000 Mwe)
• Several LWRs planned
90
79
75
84 84 86
90
91
85
89
83
82
50
55
60
65
70
75
80
85
90
95
100
1997-
98
1998-
99
1999-
00
2000-
01
2001-
02
2002-
03
2003-
04
2004-
05
2005-
06
2006-
07
2007-
08
2008-
09
Availability
Stage - II
Fast Breeder Reactors
• 40 MWth FBTR - Operating
since 1985
• Technology realised
• 500 MWe PFBR-
Under Construction
• Pre-project activities for two
more FBRs approved
• TOTAL POWER POTENTIAL 
530 Gwe (including  300 GWe with
Thorium)
No additional mined uranium
is needed for this scale up
Stage - III
Thorium Based Reactors
• 30 kWth KAMINI- Operating
• 300 MWe AHWR-
ready for deployment
• Availability of ADS can enable
early introduction of Thorium
on a large scale
ENERGY POTENTIAL IS
VERY LARGE
World class
performance
Globally Advanced
Technology
Globally Unique

6. The Major Contradictory Challenges
Faced by Developing world
 Quest for increased Generation
capacity - Terawatt Challenge
 Climate Change
- rising GHG level
 Continued focus on coal based
generation

7. Government of India’s National Missions
 National Solar Mission 2009
 National Renewable Energy Mission
“A target of 10% of Renewable Energy by 2012”
 National Mission on Combating Climate Change
through Green & Clean Power
 National Bio-diesel Mission
 National Mission of Hydro Potential Exploitation
 National Mission on ‘Clean Coal Technologies’ for
Mega Power Generation

10. CLIMATE CHANGE CAUSED BY INCREASED GHG EMISSION
• Green House Gas level rise to a current level of 390
ppm and consequent climate change, floods and
draughts has affected 260 million people between
2000 and 2004 through natural calamities, of these,
98% were in developing nations.
• Developed countries with population of 15% of
world population have the share of CO2 emissions at
50%.
• CO2 level has risen to 390 ppm from 1975 level of
330 ppm.
• There is so much momentum in the system that
we will certainly double CO2 level by end of the
century.
• Global temperature rise by 3 to 4 0C will cause
displacement of over 330 million people in
developing world.

11. • China and India are projected to account
for 30% of the world’s increase in
energy consumption between 2000-2020
and 92% of increase in coal use.
• World Green House inventory is over
29,000 Million tones per annum
(MTPA) with US over 20% (India with
total emission of about 1400 MTPA is
only at 4.8 %.)
• Coal is going to remain main stay for
power generation in at least next Three
decades for India (87,093 MW Coal
based generation out of 1,63,669 MW
total power installed capacity)

12. Green House inventory for India for
Energy Sector (Million Tonnes of CO2)
Energy Sector CO2
CO2 equivalent
(CO2+CH4+NOX)
Total Emission 834
(58% of total)
928
(64% of total)
Source: IAE: 1999

13. Tera-watt Challenge for synergy in Energy
& Environment
 A terawatt Challenge of 2012 for India
To give over one billion people in India the minimum Electrical Energy
they need by 2012, we need to generate over 0.2 terra watt (oil
equivalent to over 3 million barrels of oil per day) and 1 TW by
2050,primarily through Advanced fossil fuel technologies like CCTs for
limiting GHG emission levels
 By 2020 our mix of generation would have the Peak in
Thermal, certainly it would be the Green Thermal
Power:
 Thermal 326,000MW
 Renewable & Hydro 104,000 MW
 Nuclear 20,000 MW
 Total 450,000 MW

14. Energy for the Earth Planet- Non-CO2 Options
 World Generates 15 Terawatt of Energy (the US -
about 3TW, India - 0.16 TW) today to support 10
billion world population. This is Equivalent to230
million barrels of oil /day.
 By 2050 it is projected to need about 35 TW. The
world would need about 20 TW of non-CO2 energy
to stabilize CO2 in the atmosphere by mid century.
 Among the non-CO2 options , it is possible that
solar is the only one that can meet this Terawatt
challenge and at the same time contribute to the
reduction of climate change, with about 125,000
TW of global incident sunlight.

18. 4/7/2024 18
4/7/2024 18
Can we address the following
issues by roping in renewables?
 GDP growth must be sustained and lack of
energy availability should not pull it down.
 Exchange crisis should not recur due to
bulging Oil import bills
 Climate change is a concern and countries
with low per capita income are more
vulnerable to the effects of climate change
The answer seems to be ….yes.

19. National Solar Mission-
Proposed Road Map
Segment Target
(2010-13)
Target
(2013-17)
Target
(2017-22)
Solar Collectors
(million sq.
meters)
7 15 20
Off grid Solar
applications, MW
200 1000 2000
Utility grid power
including
rooftops, MW
1000-2000 4000-10000 20000
4/7/2024 19

20. The National Solar Mission
The National Solar Mission is a major
initiative of the Government of India
and State Government to promote
ecologically sustainable growth while
addressing India’s energy security
challenge.
It will also constitute a major
contribution by India to the Global
efforts to meet the challenges of
Climate Change

21. INDIAN POWER SECTOR - TOWARDS
SUSTAINABLE POWER DEVELOPMENT
 Total Installed Capacity … 1,63,669 MW
 Thermal Generation … over 64 %
 Although no GHG reduction targets for India
but taken steps through adoption of
Renewable Energy Technologies,Combined
cycles, Co-generation, Coal beneficiation,Plant
Performance optimization
 Under Kyoto Protocol; Clean Development
Mechanism (CDM) conceived to reduce cost of
GHG mitigation, while promoting sustainable
development as per Framework Convention on
Climate change (FCCC)

22.  GREEN ENERGY TECHNOLOGIES – PRIMARILY THE
CLEAN COAL TECHNOLOGIES
 ZERO EMISSION TECHNOLOGIES FOR TRANSPORT,
POWER PLANTS & INDUSTRIAL SECTOR
 AFFORDABLE RENEWABLE ENERGY TECHNOLOGIES
 ENERGY EFFICIENCY
 CDM OPPORTUNITIES IN ENERGY SECTOR
FRONTALS IN ENERGY & ENVIRONMENT

23. Mission Energy Security and Energy independence
 Climate Change – Nature’s Fury
 Solar for irrigation
 High Efficiency CNT Based PV Cells
 Hydrogen as Fuel for future
 Accelerated Program on Thorium based Nuclear
Reactor
 Clean coal Technologies like SCR, IGCC
 Bio-fuels for Railways and Mass Transport
 Energy Security by 2020, Energy Independence
by2030
….Reference: Address by President of India 14th Aug 2005

25. Green Energy solutions
 Promote CCT in countries like India & China
where coal is main stay fuel for Power
Generation.
 Increased use of Advanced Fossil Fuel
Technology
 Energy Farming
 Energy Efficiency
 Major shift towards Green Technologies
 Adoption of Renewable Energy Technologies in
Rural Sector

26. Impact Green Projects at RGTU
 CO2 Capture, Sequestration and Production of
Multi-purpose fuels – Hydrogen, Methane and
Biodiesel through Algae route
 Production of CNG from Coal–gasification route
 Solar, Wind & Biomass Hybrid System
 60 kW Solar-Wind Hybrid system at Hill top of
RGTU
 High yield Jatropha plantation and Bio-diesel
production using indigenously designed Bio-diesel
reactors

27. CO2 Sequestration Pilot Plant installed under the DST Project

28. THE ROAD MAP
 Government of India has declared its policy on
CO2 abatement by the announcement and
adoption of the ‘National Action Plan on
Climate Change’.
 It has also made voluntary commitment at the
Copenhagen Summit that the Country shall
decrease its Carbon Intensity by 20% by 2020
and 50% by 2050.
 The bulk of CO2 is emitted by the Thermal
Plants in the Power Sector. For EPA
regulations to be implemented there have to
be a road map as to how this can be done
without major impact on the cost or efficiency
of the Thermal Plants

29. Solution lies in…
 The thermal plants in India have a thermal
efficiency of 35% and an emission ratio of
0.90Kg/kWh of CO2 emissions as published
by CEA. The reduction of 20% intensity
would translate to a decrease of
0.20Kg/kWh of CO2 emissions i.e. below
0.70Kg/kWh CO2 emissions by 2020.
 This decrease is possible by a combination of
abatement and recycling measures. The CO2
reduction by an Amine system of 30% CO2
capture would mean a decrease of Thermal
Efficiency by 2%

30. Application Potential:
Long Term
• Deployment of the Technology to Actual Power Plants of NTPC
through BHEL / TOSHIBA or any other major player
Immediate
• Green Energy Technology Centre (GETC) being set-up for Teaching
& Research (M. Tech & PhD)
Future action plan:
Efforts are underway to extend the scope of the process by
incorporation a Coal gasifier and recycling of carbon through
collaborative research and Distributive Research Initiatives (DRI) with
Research Organizations and Power Industries.

31. • India’s position with regard to Carbon
Capture & Storage (CCS) is very clear. We
don’t make any commitment at this stage
regarding deployment of CCS technologies.
India advocates very strongly the Carbon
Capture & Sequestration.
• Some of the demo pilot projects include.
-Pilot project on Geological CO2
sequestration in basalt rock formation.
The question of adoption of CCS will depend
on this technology being cost effective.
-Projects under DST sponsored National
Program on Carbon Sequestration
(NPCS)
Carbon Capture & Sequestration

32. CO2 mitigation Options: Case of Electricity
Sector
 Coal: Dominates the electricity sector today
 Fuel switching (Coal NG)
 Conventional Plants + Carbon Capture &
Sequestration (CCS)
(Post –Combustion CO2 Capture)
 Gasification/ Reforming + CCS
(Pre-Combustion CO2 Capture)
 Oxyfuel Combustion + CCS

33. CO2 Capture/Sequestration
200
150
100
50
0 0 500 1000 1500 2000
Nuclear
200
150
100
50
0 0 500 1000 1500 2000
Renewable
200
150
100
50
0 0 500 1000 1500 2000
Million tones CO2
Figure: Comparison of CO2 capture & Sequestration Technologies
with other leading mid-to long-term option
$
per
tonne
CO2
avoided
$
per
tonne
CO2
avoided
$
per
tonne
CO2
avoided

34. Issues before the house
 Promotion of Clean Coal Technologies
 Technology break thoughts in the areas like CO2
capture and Clean Coal Technologies
 Development of low cost solar photo voltaic cells
 Bringing Energy Efficiency & Energy Conservation
on the top of the National Agenda
 Promotion of Carbon Trading on the strength of
Energy Efficiency and Green Environment
initiatives.
 Base line methodologies for variety of Clean and
Green Technologies need to be redefined.
