Presentation of the paper "FaSet: A Set Theory Model for Faceted Search" by D. Bonino, F. Corno, L. Farinetti at the 2009 IEEE/ACM/WIC Intenationational Conference on Web Intelligence

1. Politecnico di Torino
Dipartimento di Automatica e Informatica
http://elite.polito.it
FaSet: A Set Theory Model for
Faceted Search
Dario Bonino, Fulvio Corno, Laura Farinetti

2. Outline
 Faceted Search
 Goal
 The FaSet Set-Theoretical Model
 FaSet Relational Implementation
2 WI/IAT 2009, Milano, Italy FaSet

3. Faceted Classification
 Originated in Library Science
 Ranganathan, 1962
 Content-based classification scheme
 Multi-dimensional
 Facet = classification dimension
 Multi-valued
 Focus = allowed value in one of the facets
3 WI/IAT 2009, Milano, Italy FaSet

4. Example
Color Shape Taste Facets
Yellow Cube Sweet
Red Sphere Bitter
Orange Cone Neutral
Allowed foci for
Green Cylinder Acid
each facet
Blue
White
Black
Choice of the foci
describing the item
4 WI/IAT 2009, Milano, Italy FaSet

5. Faceted Search Systems
 Faceted Classification
 Simple, intuitive, versatile, powerful
 Adopted by more and more web sites
 As a classification system for their
products/items/documents/resources/…
 As a model for the user interface in search, filtering,
refinement
5 WI/IAT 2009, Milano, Italy FaSet

6. Examples
6 WI/IAT 2009, Milano, Italy FaSet

7. Examples
7 WI/IAT 2009, Milano, Italy FaSet

8. Examples
8 WI/IAT 2009, Milano, Italy FaSet

9. Facets in the real world
 Multi-valued Color Shape
classification Yellow Squared ▼
Red Cube
 During classification
Orange Parallelepiped
 During search
Green Rounded ▼
 AND vs OR semantics? Sphere
Blue
 Hierarchical (nested) White Cylinder
facets Black
 Parents selectable? Other
Weight
 Incomplete classification 0-50 g
 Numerical ranges 50-100 g
100+ g
9 WI/IAT 2009, Milano, Italy FaSet

10. Facets in the Literature
User Interfaces Data and logic model
 Active research field  Methodologies from
since ~2000 Library science
 Usability studies (Broughton, Vickery)
 Mainly for search  Formal models
interfaces  Dynamic Taxonomies
 Application case studies (Sacco)
 Web vs desktop  Uniformities, Lattices
(Priss)
environment
 Granular computing
 Mainly for multimedia
data  Less applicable results
10 WI/IAT 2009, Milano, Italy FaSet

11. Goal of the paper
 Propose a formal model: FaSet
 for representing
 Faceted Classification of resources
 Faceted Search Interfaces for such resource sets
 Searching, Filtering, Ranking operations
 compatible with modern web applications
 Mathematically simple
 Easy mapping to Relational Algebra
 Decouple classification and resources
 versatile and flexible
 Supports all “real-world” variations on Facets
11 WI/IAT 2009, Milano, Italy FaSet

12. Facets and Foci
 Facets: disjoint sets U
 Fa, Fb, Fc, … Fb
 Facet space:
 U = Fa  Fb  Fc  … Fa
 Focus L: subset
 La  Fa Fa
 Many foci for each facet
La<2>
 Focus name: index list La<1>
 La<i,j,k,…> La<1,1>
La<1,2>
12 WI/IAT 2009, Milano, Italy FaSet

13. Hierarchy
 Hierarchical nesting of Fa
La<2>
foci is represented by
La<1>
subset containment
La<1,1>
 La<narrower> 
La<1,2>
La<broader>
 Locus names are  Incomplete taxonomy
chosen to represent  No overlap allowed
hierarchical containment  A focus may be larger
 La<i,j,k>  La<i,j> than the union of its sub-
 Reminds of Dewey Decimal
foci
Classification
13 WI/IAT 2009, Milano, Italy FaSet

14. Classification (Facet)
 Resources r are Fa
La<2>
classified w.r.t. the facet
La<1>
space
La<1,1>
 “Projection”: r  Fa
La<1,2>
 We may only represent
projections built by r  Fa
combining foci
 r  Fa = ∪p La<p>
 Just the focus names
are needed
 {<1,1>,<2>}
14 WI/IAT 2009, Milano, Italy FaSet

15. Classification (Multidimensional)
 On the multi-
dimensional space, the rU
cartesian product is r  Fb
taken
 r  U = rFa  rFb  ...
 Just the focus names r  Fa
are needed

15 WI/IAT 2009, Milano, Italy FaSet

16. Searching in FaSet
 Resources r r1
 Classified as r  U Fb q
r2
 Query q
 Expressed uniformly as q  U Fa
 Search = Filtering + Ranking
 Filtering: r is relevant to q iff: (r  U) ⋂ (q  U)  
 Ranking: estimate the similarity S(q, r) of r to q
16 WI/IAT 2009, Milano, Italy FaSet

17. Filtering
 All resources that match, even partially, with the
query
 (r  U) ⋂ (q  U)  
 May be easily computed by checking focus names
 Prefix-compatibility: La<p1> ≍ La<p2> iff
 p1 = p2, or
 p1 is a prefix of p2, or
 p2 is a prefix of p1
 At least one couple of foci, per each facet, must be
prefix-compatible
 ∀Fa : ∃ La<p1> ∈ q, La<p2> ∈ r : La<p1> ≍ La<p2>
17 WI/IAT 2009, Milano, Italy FaSet

18. Example
L<>
L<1> L<2>
L<1,1> L<1,2> L<1,3> L<2,1> L<2,2>
<1,3> <2> q
<1> r1
<2,2> r2
<1,2> <1,3> r3
<1,1> <1,2> r4
18 WI/IAT 2009, Milano, Italy FaSet

19. Ranking
 Compute similarity between resource and query
 Often neglected by Faceted Search Interfaces
 Define a Similarity Measure S(q, r) ∈ [0,1]
 Compute similarity between matching foci (deeper
matches give higher scores)
 Aggregate focus-based similarity measures in the same
facet (fuzzy sum)
 Normalize facet-level results
 Aggregate facet-based similarity measures across all
facets (fuzzy product)
19 WI/IAT 2009, Milano, Italy FaSet

20. FaSet Relational Implementation
 The FaSet classification requires
 A constant set of Facets
 A constant set of Foci
 An “index” table storing the list of focus names for each
resource constant
Resource
Database
20 WI/IAT 2009, Milano, Italy FaSet

21. FaSet Relational Implementation
 The FaSet search algorithm uses
 Set operations
 Universal and existential quantification
 Aggregate operations for computing ranking measures
 Directly supported by Relational DBMS primitives
21 WI/IAT 2009, Milano, Italy FaSet

22. Future work
 Experimentation of FaSet on sample data sets
 Performance evaluation
 Integration with front-end AJAX interfaces
 CMS module
 MIT Exhibit
 Evaluation of the ranking
algorithm from the
Information Retrieval
point of view
22 WI/IAT 2009, Milano, Italy FaSet

23. Conclusions - FaSet
 Formally defined faceted Representation & Search
model
 Light formalism
 Supports hierarchies, nesting, multiple classification,
incomplete specifications, …
 Compatible with modern web development
technologies
Thank
you!
23 WI/IAT 2009, Milano, Italy FaSet
