  • 1. S60 Web Widgets Petro Soininen 29th September 2007
  • 2. Contents • Web browser and the Web browser as a run-time platform • Web applications • Widgets • Desktop widgets • Mobile widgets • Web application vs. widget • Web widget development • Web widget APIs
  • 3. Web Browser • All web browsers perform the same tasks. The order and how the process is performed is what differentiate browsers. • The tasks are: Fetch markup • Parse markup • Construct a document tree (nowadays a DOM tree) • Find external references (images, CSS, javascript) and issue load • requests for them. Construct boxes of content to render • Apply style information to boxes • Layout the boxes • Render boxes • Process user events •
  • 4. Web Browser for S60 APIs supporting Flexible for plug-ins & application interworking extensions S60 Browser UI Widget Runtime Netscape Browser Control S60 plug-ins, incl. Flash plug-in API Lite, SVG, and audio. (NPL) JavaScript S60 WebCore Nokia Core WebKit KHTML UI KJS features OS adaptations Memory manager Legend Symbian OS Symbian HTTP framework open sourced by Nokia Already open source Design not limited Closed source to particular OS (S60, Nokia, Symbian)
  • 5. Web Browser as a Run-Time Platform • It is the browser engine, which comprises of some core components such as the XML engine, HTML parser, JavaScript engine, CSS processor, rendering engine etc. • It has web applications and widgets as client applications • JavaScript as an application programming language • Scripts typically cannot directly access the file system or the network • It provides certain access level to the system properties • Traditionally, a browser mainly provides functionality to access data on the Internet, not data on a local storage • It is the Web Run-Time platform (WRT) • Browser as Development Platform
  • 6. Web Application • Web application is an application that is accessed with the Web browser over the Internet • Web application uses standard Web-based technologies such as HTML/XHTML, CSS, JavaScript, DOM etc. • Typical Web applications are Webmail, online auction (eBay), online booking or blogs
  • 7. Widgets • Widget is a standalone Web application • Runs, feels & acts like a native application • Local on the handset & distributed like any other application • Not necessarily dependent on network access Web page without a browser UI • Updates via server logic modifications or by redistributing the content to local device • Widget at its core is a Web page designed for a specific purpose • Widgets use standard web technologies HTML, CSS, JavaScript, AJAX… • Rapid development - days - not months or years • Development to Deployment in “clicks”
  • 8. Desktop Widgets
  • 9. Mobile Widget • S60 as the 1st mobile platform announcing widget support • Empowered by the mobile widget engine • Fully compliant with standard-based Internet technologies
  • 10. Web Run-Time - Current Goal • Widgets leverage the Web • use internet services and Web APIs to access information • use XmlHttpRequest and AJAX techniques • low effort to port widgets from other platforms • Widgets integrated into S60 user experience • display the icon in the Application Menu • can be assigned to Idle screen soft keys and shortcuts • appear in the Active Applications list • managed the same way as existing S60 applications • Familiar (Un)Installer user experience • Visible in Application manager • Enable access to Widget specific APIs (widget, system info, menu)
  • 11. Web Run-Time - Future Goal • Widgets leverage the smart phone platform • combine information from Web with platform services • improves user experience • Location, PIM & media… information • integrate widgets into Active Idle • additional UI enhancements and features • Widgets evolve as a development platform • Integrated safely/securely with S60 platform services • access platform services via S60 APIs • provide security and signing model for widgets
  • 12. Web Widget Framework
  • 13. Widget component structure • A widget is constructed by a bundle of files. • info.plist (mandatory) • icon.png • [name].html (mandatory) • [name].css • [name].js • A widget project is a file-system directory, in which widget’s component files are stored. • Widget’s mandatory files and the icon.png (if included) MUST be located at the root directory of a widget project.
  • 14. Info.plist – Property of a Widget •A manifest file in XML format, containing the property and configuration information of a widget. <?xml version=quot;1.0quot; encoding=quot;UTF-8quot;?> <!DOCTYPE plist PUBLIC quot;-//Nokia//DTD PLIST 1.0//ENquot; quot;http://www.nokia.com/NOKIA_COM_1/DTDs/plist-1.0.dtdquot;> <plist version=quot;1.0quot;> <dict> <key>DisplayName</key> <string>WidgetName</string> <key>Identifier</key> <string>com.company.widget.project</string <key>MainHTML</key> <string>Main.html</string> </dict> </plist>
  • 15. WRT Supported Properties Name Type Use Description String Required Specify the actual name of the widget DisplayName listed on the Installed application bar String Required Specify unique string identifier for the Identifier widget in reverse domain format String Required Specify the name of the main HTML page MainHTML that points to the widget AllowNetworkAccess Boolean Optional Specify access to the network based resources from the widget ShortVersionString String Optional Specify release version of the widget bundle Number Optional Specify build version of the widget bundle Version
  • 16. Icon.png • PNG image to be used as application icon • Recommended size 88x88 px • Default S60 application icon used if icon.png is missing
  • 17. …just to clarify (or confuse?)
  • 18. HTML – The Backbone of a Widget • Defines the structure of the <html> widget. <head> .. • Recommended HTML 4.01 </head> specification. <body id=quot;bodyquot;> <div id=‘mainView’> • Use the <div> (block-level) <span class=‘title’>Front view</span> element to construct the </div> widget’s views. <div id=‘subView1’ class=‘subView’> <p class=‘title’>Back view</p> • Views can be constructed </div> with static HTML elements or <div id=‘subView2’ class=‘subView’> can be dynamically created <p class=‘title’>Config view</p> by JavaScript at runtime. </div> </body> </html>
  • 19. CSS – Makeup for a Widget // Class selector to define common • Style and layout style for similar components .title { information font-size: 26px; color: blue; • Defines how to display } HTML element: position, .subView { color, background color display: none } etc. // Id selector to define a unique style for a unique component • CSS information can be #mainView { font-size: 16px; embedded in the HTML file color: red; text-align: center; • Or imported from an external } stylesheet // Pseudo-class selector to design a pattern style div.subview div { margin: 10px 0 0 0; padding: 20px 20px 20px 20px; font-size: 22px; text-align: left; color: blue; }
  • 20. JS – The Brain of a Widget • The intelligence of a widget? • Without JavaScript code, a widget is just a passive Web page • JavaScript code can be embedded in the HTML file within <script> elements • JavaScript API, Java DOM API, AJAX API • ECMAScript standard; Extension JavaScript objects • Core DOM and HTML DOM APIs • XMLHttpRequest object • Platform services via Nokia-specific extended JavaScript API: • Available only from Widget JavaScript code
  • 21. JavaScript // define some global variable var globalVariable = 0; // function multiply(xValue, yValue){ return xValue * yValue; } // create a new element with DOM function var newElement = document.createElement(‘div’); newElement.setAttribute(‘id’, ‘extraView’); newElement.setAttribute(‘class’, ‘subView’); // show/hide views function changeView(activeViewId, hiddenViewId){ var activeView = document.getElementById(activeViewId); var hiddenView = document.getElementById(hiddenViewId); activeView.style.display = ‘block’; hiddenView.style.display = ‘none’; }
  • 22. Widget APIs Introduction
  • 23. Widget Object • Widget methods • Widget object is a built-in module of the widget engine • openURL(String:url) • setPreferenceForKey(String:prefere widget or window.widget nce, String:key) • preferenceForKey(String:key) • Widget object provides basic • prepareForTransition utility functions to manipulate (String:transitionState) widget’s properties • performTransition(void) • setNavigationEnabled(Boolean:flag) • openApplication(Uid, param) • setDisplayLandscape(void) • setDisplayPortrait (void) • Widget properties var h = window.screen.height; var w = window.screen.width; • identifier [readonly, String] if (h < w) • onshow [assigned callback function] widget.setDisplayLanscape(); • onhide [assigned callback function] • isRotationSupported [readonly, Booloean] widget.onhide = pause; function pause() { clearTimeout(timer); }
  • 24. Menu Object • Menu object is an extension • Menu methods from the widget object • append(MenuItem menuItem) menu or window.menu • remove(MenuItem menuItem) • Menu object provides • replace (MenuItem oldMenuItem, MenuItem interfaces to manipulate the newMenuItem) options menu and softkeys (right and middle keys) of a • getMenuItemById(Integer:id) widget • getMenuItemByName(String:label) • setRightSoftKeyLabel(String:label, function:callbackfunction) • showSoftkeys(void) var opMenu = window.menu; // ! menu is reserved • hideSoftkeys(void) • clear(void) { ... • Menu properties opMenu.setRightSoftKeyLabel( ‘Back’, toMainView); • onShow [assigned callback function] } function toMainView() { ... opMenu.setRightSoftkeyLabel(‘’, null); }
  • 25. MenuItem Object • MenuItem provides • Menu Item methods interfaces to create • new MenuItem(String:label, menu items and Integer:id) submenus • append(MenuItem:childMenuItem) (cascading) for the • remove(MenuItem:childMenuItem) options menu • replace(MenuItem:oldMenuItem, MenuItem:newMenuItem) • setDimmed(Boolean:flag) • Menu Item properties • onSelect [assigned callback function] function createMenu { var settings = new MenuItem( ‘Settings’, 10); settings.onSelect = showSettings; window.menu.append(settings); } function showSettings(id) { document.getElementById( ‘setting’).style.display = ‘block’; }
  • 26. System Info Service API • System info service API is a scriptable Netscape plug-in module • Subset of system properties accessible • Memory, network and battery status, etc. • System info service plug-in module is loaded via an HTML <embed> element <embed type=quot;application/x-systeminfo-widgetquot; hidden=quot;yesquot;></embed> • System info service plug-in module is not loaded in Browser context
  • 27. System Info Service API • Power properties • chargelevel [readonly, int] • chargerconnected [readonly, int] • onchargelevel [writeonly, function] • onchargerconnected [writeonly, function] • Network properties • signalbars [readonly, int] • signalstrength [readonly, int] • networkname [readonly, string] • registrationstatus [readonly, int] • onsignalstrength [assigned callback function] • onregistrationstatus [assigned callback function]
  • 28. System Info Service API var sysInfo = null; function init() { // get the handle to the system info object sysInfo = document.embeds[0]; var battLevel = sysInfo.chargelevel; sysInfo.onchargelevel = quot;batteryStatusCallback()quot;; } function batteryStatusCallback() { var battLevel = sysInfo.chargelevel; }
  • 29. System Info Service API cont. • Light methods • lighton(Int:lighttarget, Int:duration, Int:intensity, Int:fadein) • lightblink(Int:lighttarget, Int:duration, Int:onduration, Int:offduration, Int:intensity) • lightoff(Int:lighttarget, Int:duration, Int:fadeout) • Light properties • lightminintensity [readonly, Int] • lightmaxintensity [readonly, Int] • lightdefaultintensity [readonly, Int] • lightinfiniteduration [readonly, Int] • lightmaxduration [readonly, Int] • lightdefaultcycletime [readonly, Int] • lighttargetprimarydisplayandkeyboard [readonly, Int] • lighttargetsystem [readonly, Int]
  • 30. System Info Service API cont. • Vibra methods • startvibra(Integer:duration, Integer:intensity) • stopvibra(void) • Vibra properties • vibraminintensity [readonly, Integer] • vibramaxintensity [readonly, Integer] • vibramaxintensity [readonly, Integer] • vibrasettings [readonly, Integer] • Beep methods • beep(Integer:frequency, Integer:duration) • Memory properties • totalram [readonly, Integer] • freeram [readonly, Integer]
  • 31. System Info Service API cont. • File system methods • drivesize(String:drive) • drivefree(String:drive) • File system properties • drivelist [readonly, String] • Language properties • language [readonly, String]
  • 32. Web Widget Development
  • 33. What You Need? • For implementing widget code: • Text editor or a web IDE • For debugging a running widget • Firefox • firebug • Greasemonkey • XmlHttpRequest Bypass Securityquot; script for free XmlHttpRequest access from local file. • For testing a widget: • S60 3rd Edition FP2 SDK emulator • Beta available soon ☺ • Compatible S60 device with custom SW
  • 34. Widget Installation Package •Widget installation file format • Compressed with any ZIP application • ZIP file contains html, CSS, js, icons, graphics and the widget info file •Widget installation file extension • WidgetName.wgz •Widget installation MIME type • x-nokia-widgets
  • 35. Widget Installation Process Widget.wgz x-nokia-widgets Symbian OS system MIME Widget MIME type recognizer recognizer S60 SW installer Widget framework Installer Installed
  • 36. Demo (fingers crossed)
  • 37. Support Workshops, eLearning and Developer training details to be published at forum.nokia.com Developer documentation available at S60 3rd FP2 Beta SDK launch
  • 38. Thank you.

×
