Design process inthe responsive ageA UX perspectivePon Kattera Senior Interaction Designer R/GA@pkattera                  ...
TONIGHTA little about meResponsive process (alpha)Responsive process (beta)Resources and tips getting startedQuestions    ...
TL;DROur job now is to create future friendly designsystems (not fixed pixel width interfaces).This requires a change in p...
A LITTLE ABOUT MEI’m a senior Interaction Designer at R/GAI’m an AustralianI’m loving New York!                           ...
BACK IN 2009Fixed width pixel designs were all the rageDesktop screens were getting largerMobile users were visiting our s...
MY 2010
2011:GOODBYE TIMBUKTU,HELLO NEW YORKWhat’s this “responsive webdesign” thing you speak of?                              7
SO, WHAT DOES IT TAKE TO CREATE A RESPONSIVE DESIGN?1. A flexible, grid based layout2. Flexible images and media, and3. Me...
RESPONSIVE WEB DESIGN VSADAPTIVE WEB DESIGN“Adaptive web design is about                                         ADAPTIVEc...
DOES THIS PROCESSSOUND FAMILIAR?      PLANNING                    AND STRATEGY                                     USER   ...
DOES THIS PROCESSSOUND FAMILIAR?      PLANNING                    AND STRATEGY                                            ...
DOES THIS PROCESSSOUND FAMILIAR?      PLANNING                    AND STRATEGY                                            ...
DOES THIS PROCESSSOUND FAMILIAR?      PLANNING                    AND STRATEGY                                     USER   ...
WHY CHANGE OUR PROCESS?To increase efficiencySave time and make money.To design better websitesDesign systems, not fixed p...
WHY CHANGE“RWD comes under criticism for notbeing commercially viable. It’s becauseit’s trying to be shoe-horned into anex...
IF YOU DON’T CHANGE                      16
RESPONSIVE PROCESS      (ALPHA)                     17
CASE STUDYFINANCIAL ADVISORSRESPONSIVE SITEProject Details:An existing Financial Advisors website thatincludes basic profi...
CASE STUDYFINANCIAL ADVISORS   Business                     Objectives                                              User  ...
TIPS       SHOULD I GO RESPONSIVE FOR MY PROJECT       It depends…       Project context       Budget and timelines       ...
TIPS       Responsive web design may not be the       best option right now for your project                              ...
CASE STUDYWHY WE WENT   Client’s              Business                             Supporting                             ...
CASE STUDY             OUR APPROACH             Mobile first (content first)             responsive web design            ...
CASE STUDYRESPONSIVE PROCESSUser          Content                      Iterative design & development            Prototype...
CASE STUDYUSER         PERSONAS   SCENARIOSRESEARCH                                    25
CASE STUDYCONTENT      INFORMATION    CONTENT             ARCHITECTURE   REFERENCE DIAGRAMS                               ...
CASE STUDYCONTENT INVENTORY AND PRIORITIZATION                                                                            ...
TIPS       CONTENT STRATEGY: A USEFUL RULE OF THUMB       “Generally speaking, your web content is useless       unless it...
TIPSSHOULD WE HAVE LESS CONTENT FOR OUR MOBILE SITE?                                                   29
CASE STUDY ITERATIVE DESIGN AND DEVELOPMENT                         TEST                                    PROTOTYPE     ...
CASE STUDYITERATIVE DESIGN AND DEVELOPMENT PROCESS BREAKDOWNClient check ins:           1Start with:     STRATEGY  USER RE...
CASE STUDYITERATIVE DESIGN AND DEVELOPMENT PROCESS BREAKDOWNClient check ins:           1             2                   ...
CASE STUDYITERATIVE DESIGN AND DEVELOPMENT PROCESS BREAKDOWNClient check ins:           1             2               3   ...
CASE STUDYITERATIVE DESIGN AND DEVELOPMENT PROCESS BREAKDOWNClient check ins:           1             2               3   ...
CASE STUDYITERATIVE DESIGN AND DEVELOPMENT PROCESS BREAKDOWNClient check ins:           1             2               3   ...
CASE STUDYINTERACTION   SKETCH   WIREFRAME   PROTOTYPEDESIGN                                               36
CASE STUDYVISUAL       VISUAL     GRIDS ANDDESIGN       LANGUAGE   PROPORTIONS                                      37
38
SPEEDIS A DESIGNDECISION              39
TIPS       RWD ISSUES       What screen sizes should I design?       Start at 320px?       Then what?                     ...
TIPS       RWD ISSUES       How do I select breakpoints?       Breakpoints should be device agnostic       Let page conten...
CASE STUDYKEEPING PAGES BALANCED: THE PROBLEMAdvisors can choose between 1 and 20 content modules                         ...
CASE STUDYKEEPING PAGES BALANCED: SOLUTIONSContent priority       Two column layout, dynamic grid layout   One column, fix...
TIPS       RWD ISSUES       Presenting responsive designs to clients       On screen, with all layouts side by side       ...
CASE STUDY PROTOTYPE:     Cheap    Fast    Focus LOW FIDELITY                        [DEMO]                               ...
CASE STUDY PROTOTYPE:      Treatment                 of media                             Testing visual                  ...
RESPONSIVE PROCESS       (BETA)                     47
DESIGNING IN TEXTSimply, write down the contentfor each page in text form.The text should communicate theessence of the pa...
STYLE TILES BY SAMANTHA WARRENhttp://styletil.es/                                 49
HTML STYLE GUIDESGet started earlyUse throughout the projectAdd responsive patternsPattern Primer by Jeremy Keith      Pea...
DESIGNING IN THE BROWSERCreating elements and styles inHTML/CSS“The most important part here is to use a toolwhich doesn’t...
STOP.COLLABORATE.AND LISTEN.               52
WHAT ARE OTHERS DOING?                         53
MARK      1. SketchBOULTON   2. Prototype          3. Design          4. Iterate          5. Talk          Mark Boulton’s,...
STEPHEN   1. Content inventory          2. Content reference wireframesHAY       3. Design in text (structured content)   ...
VILJAMISALMINEN           Viljami Salminen, on responsive workflow, 28 May 2012           http://viljamis.com/blog/2012/re...
HOW WOULD I APPROACH A NEWRESPONSIVE PROJECT STARTING TODAY?                                     57
MY RESPONSIVE PROCESSFOR THE NEXT PROJECT(depending on project context)     USER   RESEARCH                               ...
MY RESPONSIVE PROCESSFOR THE NEXT PROJECT(depending on project context)     USER          CONTENT   RESEARCH        STRATE...
MY RESPONSIVE PROCESSFOR THE NEXT PROJECT(depending on project context)     USER          CONTENT       DESIGN   RESEARCH ...
MY RESPONSIVE PROCESSFOR THE NEXT PROJECT                                             VISUAL(depending on project context)...
MY RESPONSIVE PROCESSFOR THE NEXT PROJECT                                             VISUAL                TEST(depending...
HTML STYLE                                                                                   GUIDE                        ...
RESPONSIVE RESOURCES                       64
Start hereGETTING   http://www.alistapart.com/articles/responsive-web-designSTARTED   http://futurefriend.ly/          Rea...
RESPONSIVE   Stephan Hay’s Responsive Design Workflow             http://www.slideshare.net/stephenhay/mobilism2012PROCESS...
RESPONSIVE   As RWD evolves, so will our processRESOURCES    RESS: http://www.lukew.com/ff/entry.asp?1392             Resp...
THANKS@PKATTERAUXRAVE.COM             68
