This document discusses bootstrapping a Smalltalk virtual machine. It begins by defining bootstrapping as building the minimal infrastructure of a language that can then be used to define the language itself. It provides examples of bootstrapping a language X using tools from another language Y. The document discusses existing approaches like Spoon, Chacharas, MicroSqueak, and CorGen. It also covers the authors' approach using CorGen, which involves creating stub objects, defining classes and metaclasses, compiling methods, and saving the image. Finally, it discusses related work and conclusions.

1. Bootstrapping a Smalltalk
G. Casaccio, S. Ducasse, L. Fabresse, J-B. Arnaud, B. van Ryseghem
Presented by: M. Denker
M.Denker - Bootstrapping a Smalltalk November 2011

2. What is Bootstrapping?
A process that builds
the minimal infrastructure of a language
that is reusable to define this language itself
M.Denker - Bootstrapping a Smalltalk November 2011 -

3. Example: Bootstrapping a language X
Tools
Language X Compiler
Loader
M.Denker - Bootstrapping a Smalltalk November 2011 -

4. Example: Bootstrapping a language X
Tools
Language X Compiler
Loader
How to create/write all of this for language X?
M.Denker - Bootstrapping a Smalltalk November 2011 -

5. Example: Bootstrapping a language X
Tools
Language X Compiler
Loader
Compiler
Language Y description or
Loader
M.Denker - Bootstrapping a Smalltalk November 2011 -

6. Example: Bootstrapping a language X
Tools
Language X Compiler
Resilient Loader
≠
Compiler
Language Y description or
Loader
Java
M.Denker - Bootstrapping a Smalltalk November 2011 -

7. Example: Bootstrapping a language X
Tools
Language X Compiler
Squeak/Pharo Loader
⊃
Compiler
Language Y description or
Loader
Slang
M.Denker - Bootstrapping a Smalltalk November 2011 -

8. Why Bootstrapping?
- Agile and explicit process
- Explicit malleability and evolution support
- Warranty of initial state
- Minimal self reference
M.Denker - Bootstrapping a Smalltalk November 2011 -

9. Existing approaches
Bootstrap Approaches
Execution-based Static-based
(tracing) (generation)
OnAbsence OnPresence Dumping Recreating
Spoon Chacharas MicroSqueak CorGen
Hazelnut GNU ST
M.Denker - Bootstrapping a Smalltalk November 2011 -

10. Existing approaches
Bootstrap Approaches
Execution-based Static-based
(tracing) (generation)
OnAbsence OnPresence Dumping Recreating
Spoon Chacharas MicroSqueak CorGen
Hazelnut GNU ST
M.Denker - Bootstrapping a Smalltalk November 2011 -

11. Spoon
- Client / Server approach
- Client side starts as minimal
- On each slot access if the target object is missing, fetch and copy it from
the server
ss
ce
t ac
lo
1 .s
t
jec
t
jec
ob
ob
ing
g
py
tin
co
ec
inj
3.
4.
Server Client
2. slot absent grabbing
it from server
M.Denker - Bootstrapping a Smalltalk November 2011 -

12. Chacharas
Same approach as Spoon but:
- Analyze a server side execution
- All reached objects are copied on the client
M.Denker - Bootstrapping a Smalltalk November 2011 -

13. MicroSqueak
1 - A kernel is loaded from MicroSqueak MicroSqueak
Kernel Kernel
files into a namespace
Fix references of
Create stub objects classes and
metaclasses
MicroSqueak MicroSqueak
Kernel Kernel
Fix references of
Save it
compiled method
M.Denker - Bootstrapping a Smalltalk November 2011 -

14. Hazelnut
Same approach as MicroSqueak but:
- does not rely on a specific list of class that are manually edited
- takes a list of classes as input and recursively copy classes into a new
namespace
M.Denker - Bootstrapping a Smalltalk November 2011 -

15. Discussion Bootstrap Approaches
Execution-based Static-based
Execution-based approaches: (tracing) (generation)
- difficult to control which objects will be selected for the
bootstrapped image OnAbsence OnPresence Dumping Recreating
MicroSqueak CorGen
- reflection breaks tracing Spoon Chacharas
Hazelnut GNU ST
- not suitable for interactive programs
+ suitable to compute the minimal runtime required by a program
Static-based approaches:
+ easier to control the result of a static generation
+ suitable for deep changes in a system (new object format, ...)
- hard to specify / write / maintain
M.Denker - Bootstrapping a Smalltalk November 2011 -

16. Our approach
Bootstrap Approaches
Execution-based Static-based
(tracing) (generation)
OnAbsence OnPresence Dumping Recreating
Spoon Chacharas MicroSqueak CorGen
Hazelnut GNU ST
M.Denker - Bootstrapping a Smalltalk November 2011 -

17. CorGen
Bootstrap>>bootstrap [
1. Creation of the stub objects for literal self
instantiateSmalltalkObjects;
objects: nil, true, false, characters
2. Definition of classes and metaclasses importClassesFromSources;
3. Method compilation processClasses;
4. Creation of process and special object array setupSmalltalkObjects;
saveImage]
5. Image serialization.
M.Denker - Bootstrapping a Smalltalk November 2011 -

18. Stubs Creation
Bootstrap>>instantiateSmalltalkObjects [
self
instantiateNilGst;
instantiateTrueGst;
instantiateFalseGst;
instantiateCharactersTable; "build all the characters"
instantiateEnvironment "create System Dictionary"]
M.Denker - Bootstrapping a Smalltalk November 2011 -

19. Classes/Metaclasses creation
Bootstrap>>processClasses [
"fill the class stubs with real classes"
self
"create classes and add them to System Dictionary"
createClasses;
"compile and install CompileMethods"
compileMethods ]
M.Denker - Bootstrapping a Smalltalk November 2011 -

20. Compile Methods
- Methods either taken from the model or the source files
- Use a compiler parametrized by an environment and a symbol table
- Deep changes may be applied (change bytecode set, other optimization, ...)
M.Denker - Bootstrapping a Smalltalk November 2011 -

21. Initializing the System
Bootstrap>>setupSmalltalkObjects [
self setupCharacter; "insert references to the Character table"
setupSymbol; "insert references to the Symbol table"
setupProcessor "create Processor and install it" ]
Bootstrap>>setupProcessor [ | processorGst |
processGst := self createProcess.
processorGst := GstProcessorScheduler new.
processorGst scheduler: nilGst;
processes: self buildProcessList;
activeProcess: processGst;
idleTasks: nilGst. ]
M.Denker - Bootstrapping a Smalltalk November 2011 -

22. Initializing the System
Bootstrap>>createProcess [
| processGst |
(processGst := GstProcess new)
nextLink: nilGst;
suspendedContext: self createInitContext;
priority: 4;
myList: nilGst;
name: GstString new;
interrupts: nilGst;
interruptLock: nilGst ]
M.Denker - Bootstrapping a Smalltalk November 2011 -

23. Saving the Image
- Comply with image file format:
- Image header
- Special object array
- Serialize objects according to their shape (CompiledMethods, ...)
- Avoid object duplication during serializing
M.Denker - Bootstrapping a Smalltalk November 2011 -

24. The Result
A 54 classes Smalltalk Kernel:
Kernel (15 classes): Behavior, BlockClosure, BlockContext, Boolean, Class,
ClassDescription, ContextPart, False, Metaclass, MethodContext, MethodInfo, Object,
ProcessorScheduler, True, UndefinedObject.
Collection (27 classes): Array, ArrayedCollection, Bag, BindingDictionary, ByteArray,
CharacterArray, Collection, CompiledBlock, CompiledCode, CompiledMethod, Dictionary,
HashedCollection, IdentityDictionary, Iterable, Link, LinkedList, LookupTable,
MethodDictionary, OrderedCollection, Process, Semaphore, SequenceableCollection, Set,
String, Symbol, SystemDictionary, WeakSet.
Magnitude (12 classes): Association, Character, Float, Fraction, Integer, LookupKey,
Magnitude, MethodInfo, Number, SmallInteger, VariableBinding, HomedAssociation.
M.Denker - Bootstrapping a Smalltalk November 2011 -

25. Related Work
- Lisp : using image such Smalltalk, the bootstrap is done by migrate the
current image, using a cross-compiler include in the host image.
- Ruby : the kernel is load and initialize by the VM some low level initialization
is done in C, all the other is done by ruby processing. After all the module is
load separately by the Virtual Machine.
- Python : the Python virtual machine is initialized. Some classes stubs are
created and initialized in the virtual machine. (close of the ruby bootstrap)
M.Denker - Bootstrapping a Smalltalk November 2011 -

26. Conclusion and Future Work
Pros and Cons:
- Execution-based bootstrapping (tracing) such as Hazelnut
- Static-based bootstrapping (declarative) such as CoreGen
Future work: Boostrapping Pharo
- use an execution-based approach as an intermediate solution
- reach a static-based bootstrap that can easily be maintained and co-
evolve with the system
M.Denker - Bootstrapping a Smalltalk November 2011 -

27. THANKS
Bootstrapping a Smalltalk
G. Casaccio, S. Ducasse, L. Fabresse, J-B. Arnaud, B. van Ryseghem
Presented by: M. Denker
M.Denker - Bootstrapping a Smalltalk November 2011
