This document contains an airport layout plan showing runways, taxiways, facilities, and other infrastructure at an airport. Runway 16-34 is the primary runway, measuring 3,192 meters long and 45 meters wide. Windsocks are located throughout the airport property. Surrounding land uses include forest areas, residential areas, and Highway 1. The legend provides labels for the different airport features depicted on the plan.
