Worldpipe offers a cloud-based IPTV solution that transforms consumer-owned internet devices into high-quality set-top boxes via its Virtual Set-Top Box (vSTB) technology. This platform utilizes a VPN for secure streaming and integrated customer management while reducing capital and operational costs compared to traditional pay TV models. The solution aims to enhance customer acquisition and revenue streams by leveraging virtual assets instead of fixed infrastructure.

2. Direct to consumer entertainment service
• Broadcast television
• Video on demand
• High quality, resolution, available streaming
Delivery over a closed IP, QOS enabled network
–Fixed wire delivery
Offered by last mile network service provider
What is IPTV?

3. OTT INTERNET VIDEO
=
VoD• Only delivers partial solutions (VoD) that augments PayTV - not
replaces
• It is not like watching TV.

4. Traditional video distribution systems have
required the installation and maintenance of a
separate coax infrastructure.
World Pipe’s distribution platform ports the
CaTV business and service models over the
public Internet leveraging a VPN.

5. Competitors CAPEX Costs Per Household
$80
DSL Modem
$130 X 2=$260
STBs
Headend
ADSL 2+/FTTH Cost
Structure
$300
INFRASTRUCTURE
+
$400
$1000 Per$1000 Per
HouseholdHousehold
DEPLOYED

6. WORLDPIPE’s CAPEX Costs Per Deployment
$80
DSL Modem
$130 X 2=$260
STBs
Headend
ADSL 2+/FTTH Cost
Structure
$300
INFRASTRUCTURE
+
$400
$10 Per$10 Per
DeploymentDeployment

7. OPEX

8. Last Mile Solution

11. WORLDPIPE’s cloud
based IPTV solutions

12. VSTB (virtual Set-Top-Box)
is a dynamically created (unique WAN ID) application
that enables any consumer owned Internet enabled
devices to receive high quality video/media becoming
a distinct node (account) on WORLDPIPE's closed
and private Headend.
With an embedded VPN client, the VSTB receives
and decodes signal ONLY broadcasted from
WORLDPIPE's Headend.
VSTB

13. WORLDPIPE’s VSTB product
enables any Windows or
Android device to become a
TV grade set-top box.
• Every enrolled (consumer owned) endpoint is an active node on a private network
• 128-bit encryption transmission to every endpoint
• Every endpoint becomes a billable account on a managed service
• WORLDPIPE’S framework and OTT topology complies with rebroadcast contracts

14. VSTB
H.264 application w/RTP/RTSP stream supported with
multi-socket support for rapid channel changing

15. CRM/CMDB (Customer Relationship
Management/Configuration Management
Database)
is a unified, cloud based database which brings together
internal cloud device controls and manages VSTB
deployments for provisioning and activation, all in a holistic
real-time managed solution.
The WORLDPIPE CRM

16. The WORLDPIPE CRM:
• manage all your users' accounts, billing and support
• compiles VSTB applications from baseline code
(VPN,H.264 a/v codecs) for MS Windows and Android
OSs for each user accounts
• generates unique WAN (connection) profiles on
WORLDPIPE's VPN concentrator within the private
cloud infrastructure for each VSTB deployment
• updates internal permission within WORLDPIPE's
cloud LDAP server for each VSTB deployment

17. Other Cloud based assets ~
• VPN concentrator to connect an unlimited number of
endpoints
• Virtual streaming servers to scale to meet any demand
• First Mile asset management

18. Increase
Profits
acquire
customers
anywhere
reaching customers
with virtual assets
were your competition
with fixed assets
cannot…
create new RMR
streams reduce network
operations and
plant costs
reduce CAPEX &
OPEX Cost
increase ad revenues
with relevant
advertising
bridge the
Cable/PayTV
gap
eliminate the human
element with
enhanced deployment
services

19. THANK YOU
