Implementing Vision DL Solution using Open Source Tools
- 1. Unearth the Journey of Implementing Vision based Deep Learning Solution using Open Source Tools Neethu Elizabeth Simon Software Engineer Intel Corporation Phoenix, AZ
- 7. Video – Eye of IoT
- 9. Dried Chili Peppers Cinnamon Sticks Solution Data Set
- 10. Implementation • Build Model • Improve Models to meet performance & accuracy objectives • Deploy Model • Make Predictions by applying the Trained Model on new Data • Label Data• Data Acquisition & Organization • Preprocessing Collect Annotation TrainingInference
- 11. Implementation – Data Collection Collect Annotation TrainingInference Data Acquisition & Organization • Web Crawling/Scraping - Download pictures & videos Python Packages Request, Parcel, Beautiful Soup Frameworks/Tools Scrapy, Pyspider, Mechanical Soup
- 12. Implementation – Data Collection Collect Annotation TrainingInference Data Acquisition & Organization • Web Crawling/Scraping - Download pictures & videos • Live Video Recording/Image Capture from actual retail store Python Packages Request, Parcel, Beautiful Soup Frameworks/Tools Scrapy, Pyspider, Mechanical Soup
- 13. Implementation – Data Collection Collect Annotation TrainingInference Pre-processing • Data Cleanup • Remove Bad/Unrelated Data
- 14. Implementation – Data Annotation Collect Annotation TrainingInference Label Data • Establish ground truth
- 15. Implementation – Data Annotation Collect Annotation TrainingInference Open Source Tools • Bbox - https://github.com/puzzledqs/BBox-Label-Tool • LabelImg - https://github.com/tzutalin/labelImg • VGG Image Annotator (VIA) http://www.robots.ox.ac.uk/~vgg/software/via/ • Computer Vision Annotation Tool (CVAT) https://github.com/opencv/cvat Paid Tools – Labelbox, Dataloop, RectLabel
- 17. Implementation – Training Collect Annotation TrainingInference dried_chilli_pepper cinnamon_stick Lots of Labeled Data !!! Model Weights Forward Backward
- 18. Implementation – Training Collect Annotation TrainingInference Data • Type/Amount – Visual, Sensors • Labeled Datasets – PASCAL VOC, COCO, KITTI, ImageNet or ILSVRC, SUN • Custom Data
- 19. Implementation – Training Collect Annotation TrainingInference Compute Platform • Complexity Determined by Data • Cloud vs Edge • Intel® Xeon vs Core vs Atom Data • Type/Amount – Visual, Sensors • Labeled Datasets – PASCAL VOC, COCO, KITTI, ImageNet or ILSVRC, SUN • Custom Data Intel Core + GPU
- 20. Implementation – Training Collect Annotation TrainingInference Object Detection Algorithm • YOLO – You Only Look Once • SSD, R-CNN, Fast R-CNN, Faster RCNN, R-FCN Compute Platform • Complexity Determined by Data • Cloud vs Edge • Intel® Xeon vs Core vs Atom Data • Type/Amount – Visual, Sensors • Labeled Datasets – PASCAL VOC, COCO, KITTI, ImageNet or ILSVRC, SUN • Custom Data Intel Core + GPU YOLO
- 21. Implementation – Training Collect Annotation TrainingInference Deep Learning Framework • DarkNet - C & CUDA - https://pjreddie.com/darknet/ • DarkFlow - Tensorflow implementation of DarkNet https://github.com/thtrieu/darkflow • Others – PyTorch, Caffe Object Detection Algorithm • YOLO – You Only Look Once • SSD, R-CNN, Fast R-CNN, Faster RCNN, R-FCN Compute Platform • Complexity Determined by Data • Cloud vs Edge • Intel® Xeon vs Core vs Atom Data • Type/Amount – Visual, Sensors • Labeled Datasets – PASCAL VOC, COCO, KITTI, ImageNet or ILSVRC, SUN • Custom Data YOLO Intel Core + GPU DarkFlow
- 22. Implementation – Training Collect Annotation TrainingInference Deep Learning Framework • DarkNet - C & CUDA - https://pjreddie.com/darknet/ • DarkFlow - Tensorflow implementation of DarkNet https://github.com/thtrieu/darkflow • Others – PyTorch, Caffe Object Detection Algorithm • YOLO – You Only Look Once • SSD, R-CNN, Fast R-CNN, Faster RCNN, R-FCN Compute Platform • Complexity Determined by Data • Cloud vs Edge • Intel® Xeon vs Core vs Atom Data • Type/Amount – Visual, Sensors • Labeled Datasets – PASCAL VOC, COCO, KITTI, ImageNet or ILSVRC, SUN • Custom Data YOLO Intel Core + GPU DarkFlow Images - 1000 Images Training Time - 10 hrs Model Size – 800 MB Average loss – ~0.9
- 23. Implementation – Training Collect Annotation TrainingInferencedried_chilli_pepper cinnamon_stick Lots of Labeled Data !!! Model Weights Forward Backward python flow --train --model cfg/yolov2-2c.cfg --load bin/yolov2.weights --annotation all_Spice_Annotations/ --dataset all_Spice_Images/ DarkFlow
- 24. Implementation – Inference Collect Annotation TrainingInference Model Weights Forward dried_chilli_pepper Edge Device – Laptop/NUC/Mobile ???? Intel® OpenVINO Toolkit https://software.intel.com/en- us/openvino-toolkit Open Source Tool for Inference Support Different Models (Caffe/Tensorflow/MXNet/ONNX/Kaldi) Model Optimization Speed Deploymentpython flow --imgdir all_test_images/ --model cfg/yolov2-2c.cfg --load new_model_weights DarkFlow
- 25. Results [{"label": "cinnamon_stick", "confidence": 0.87, "topleft": {"x": 42, "y": 22}, "bottomright": {"x": 208, "y": 113}}] [{"label": "cinnamon_stick", "confidence": 0.06, "topleft": {"x": 93, "y": 216}, "bottomright": {"x": 384, "y": 402}}]
- 26. Results [{"label": "dried_chilli_pepper", "confidence": 0.95, "topleft": {"x": 0, "y": 25}, "bottomright": {"x": 761, "y": 352}}] [{"label": "dried_chilli_pepper", "confidence": 0.02, "topleft": {"x": 357, "y": 93}, "bottomright": {"x": 513, "y": 446}}, {"label": "cinnamon_stick", "confidence": 0.03, "topleft": {"x": 21, "y": 6}, "bottomright": {"x": 568, "y": 472}}]
- 28. Implementation Challenges • More is Better • Object Orientation, angle, lighting • Remove Bad/Unrelated Data • Require SME knowledge to define bad data & remove unrelated data Collect Annotation TrainingInference
- 29. [{"label": "cinnamon_stick", "confidence": 0.87, "topleft": {"x": 42, "y": 22}, "bottomright": {"x": 208, "y": 113}}]
- 30. Implementation Challenges • Manual vs Automation • Time consuming • Expensive • Difficult to Scale • More is Better • Object Orientation, angle, lighting • Remove Bad/Unrelated Data • Require SME knowledge to define bad data & remove unrelated data Collect Annotation TrainingInference
- 31. Implementation Challenges • Iterative Learning • Varied Data parameters & tuning • Hyperparamter optimization & data overfitting • High Compute • Manual vs Automation • Time consuming • Expensive • Difficult to Scale • More is Better • Object Orientation, angle, lighting • Remove Bad/Unrelated Data • Require SME knowledge to define bad data & remove unrelated data Collect Annotation TrainingInference
- 32. Implementation Challenges • Iterative Learning • Varied Data parameters & tuning • Hyperparamter optimization & data overfitting • High Compute • Constantly Update Models • Complexity in Hardware design – combination of CPU/GPU/Accelerators • Data Privacy & Security • Manual vs Automation • Time consuming • Expensive • Difficult to Scale • More is Better • Object Orientation, angle, lighting • Remove Bad/Unrelated Data • Require SME knowledge to define bad data & remove unrelated data Collect Annotation TrainingInference
- 33. Neethu Elizabeth Simon Software Engineer Intel Corporation Phoenix, AZ
