1. January 30, 2018
How to achieve PCI compliance for
MySQL & MariaDB with
ClusterControl
Laurent Blume & Vinay Joosery
Presenters

2. Copyright 2017 Severalnines AB
I'm Jean-Jérôme from the Severalnines Team and
I'm your host for today's webinar!
Feel free to ask any questions in the Questions
section of this application or via the Chat box.
You can also contact me directly via the chat box
or via email: jj@severalnines.com during or after
the webinar.
Your host & some logistics

3. Copyright 2017 Severalnines AB
Copyright 2017 Severalnines AB
About Severalnines and ClusterControl

4. Copyright 2017 Severalnines AB
What we do
Manage Scale
MonitorDeploy

5. What Problems do we Address?
Copyright 2017 Severalnines AB
Deploy
Deploy MySQL, Postgres or MongoDB - single
instances or entire clusters
Monitor
Get a unified view of all clusters across all your
data centers
Scale
Add/remove nodes, resize instances & clone
your production clusters
Manage
Automatically repair & recover broken nodes
or clusters. Test & automate upgrades

6. ClusterControl Platform
Copyright 2017 Severalnines AB
ClusterControl
CC Clients
Notifications
Email
PagerDuty
VictorOps
OpsGenie
Slack
TeleGram
Webhooks
Web UI
S9s CLI
JSON RPC
Support
24/7
KeepAlived
HAProxy ProxySQL MaxScale
Galera
MariaDb
Percona
Replication
MariaDb
Percona
MongoDb
MongoDb Inc
Percona
PostgreSql
PgSQL
Codership
Cloud
Backup

7. Deployment Features in ClusterControl
Copyright 2017 Severalnines AB
● Each Cluster can be deployed and existing Clusters can be imported.
● Web UI
○ Deployment Wizard
● CLI
○ Allows easy integration with e.g Ansible
s9s cluster
--create
--cluster-type=galera
--nodes='10.10.10.26;10.10.10.27;10.10.10.28'
--vendor=percona
--cluster-name=PXC_CENTOS7
--provider-version=5.7
--os-user=vagrant --wait
● Supports multiple NICs and templated
configurations.

8. Monitoring Features in ClusterControl
Copyright 2017 Severalnines AB
● Database specific stats and Health status
○ Graphs and Dashboards
● Host statistics
○ E.g Predictive disk space usage monitoring
● Query Monitoring
○ E.g Top Queries, Outlier detection
● Advisors
○ Developer Studio with JS like syntax
● Notifications
○ Email, Pagerduty, VictorOps etc
● Operational Reports

9. Management Features in ClusterControl
Copyright 2017 Severalnines AB
● Availability
○ Node/Cluster Recovery
● Backup and Restore
○ MySQL: mysqldump, xtrabackup
○ Postgres: pg_dump, pg_basebackup
○ MongoDb: Mongodump, MongoDb
Consistent Backup
● Configuration
● Upgrades
● Loadbalancer
○ HAProxy, ProxySQL, MaxScale
○ KeepAlived

10. Copyright 2017 Severalnines AB
Supported Databases

11. Copyright 2017 Severalnines AB
Customers

12. Copyright 2017 Severalnines AB
Copyright 2017 Severalnines AB
Agenda

13. Today’s topics
Copyright 2017 Severalnines AB
● Introduction to the PCI-DSS standard
● The impact of PCI on database management
● Meeting PCI requirements for MySQL / MariaDB with
ClusterControl
● Conclusion
● Q&A

14. About me
Copyright 2017 Severalnines AB
Laurent Blume, Unix Systems Engineer & PCI-DSS implementer

15. Copyright 2017 Severalnines AB
Copyright 2017 Severalnines AB
Introduction to the PCI-DSS standard

16. Header
Copyright 2017 Severalnines AB
Source: https://www.pcisecuritystandards.org/pci_security/maintaining_payment_security

17. What is PCI-DSS ?
Copyright 2017 Severalnines AB
● Managed by the PCI Security Standard Council, which was
founded by major payment card companies
● Set of technical & operational requirements to protect
cardholder data
● Governs all merchants and organizations that
store/process/transmits this data

18. What isn’t PCI-DSS ?
Copyright 2017 Severalnines AB
● Not set in stone
○ Version 3.2 (April 2016) currently in force
● Not a goal that can be reached then forgotten
○ Yearly reviews and audits
● Not a governmental regulation
○ Those also need to be respected (GDPR, …)

19. Applicable Data
Copyright 2017 Severalnines AB
● All revolves around the card number, aka the PAN
○ You can store it after a transaction, but it needs protection
● Other elements used during the transaction must never be
stored (PIN, CVV, …)
Ref: https://www.pcisecuritystandards.org/pdfs/pci_fs_data_storage.pdf

20. Why comply?
Copyright 2017 Severalnines AB
● Required in order to accept credit cards
● A security breach has serious consequences
○ Regulatory notification
○ Fines
○ Litigation
○ Impacts your customers and reputation

21. Compliance Checks
Copyright 2017 Severalnines AB
● The same rules apply to every company handling card
information
● Merchant levels define how the compliance is checked
○ Minimum: an annual Self Assessment Questionnaire
and network scan
○ Maximum: an annual audit by a Qualified Security
Assessor
https://pci.qualys.com/static/help/merchant/getting_started/pci_merchant_levels.htm

22. Copyright 2017 Severalnines AB
Copyright 2017 Severalnines AB
The Impact of PCI on Database
Management

23. Cardholder Data Environment (CDE)
Copyright 2017 Severalnines AB
● PCI-DSS applies to every single component inside the CDE
● That CDE must be precisely defined
● An isolated network can reduce the scope

24. Cardholder Data Environment (CDE)
Copyright 2017 Severalnines AB
● What’s inside the CDE:
○ Workstations
○ Application servers
○ Network equipment
○ Databases
○ ...

25. Cardholder Data Environment (CDE)
Copyright 2017 Severalnines AB
● The database often is the central element of the CDE
○ It contains sensitive data that must be protected
○ It sends and receives fresh data
○ It must be reachable, but only by authorized parties
(load balancers, application servers, …)

26. Procedures and Provability
Copyright 2017 Severalnines AB
● Doing things right: of course you must
● Proving you’re doing them right?
○ Not as obvious as you might think...

27. Procedures and Provability:
Making it easier
Copyright 2017 Severalnines AB
● Automation:
○ It takes time to set it up, then it saves time
○ It helps making sure an action made once will not be
forgotten next time
○ It helps proving what you’ve been doing since the last
time you saw the auditor

28. Database environment is distributed
Copyright 2017 Severalnines AB
● You process card numbers?
● You need security
● It’s likely you also need reliability
○ Multiple servers
○ Multiple data centers

29. Single view/control of distributed environment
Copyright 2017 Severalnines AB
● In short, you need a cluster
○ Distributed database of identical nodes
○ Load balancers manage access to those nodes
○ Application clients use one connection string
○ Single view: all nodes as a single entity facilitates compliance

30. Copyright 2017 Severalnines AB
Copyright 2017 Severalnines AB
Meeting PCI Requirements for MySQL &
MariaDB with ClusterControl

31. PCI Data Security Standard - Overview
Copyright 2017 Severalnines AB

32. 2. Do not use vendor-supplied defaults for
system passwords & other security parameters
Copyright 2017 Severalnines AB
● Set root password, disable remote root login
● Remove anonymous users/test database
● Automated via ClusterControl
○ Easily audited in the UI
● … more in our ‘10 Security Tips’ blog*
* https://severalnines.com/blog/ten-tips-how-achieve-mysql-and-mariadb-security

33. 3. Protect stored cardholder data
Copyright 2017 Severalnines AB
● Some fields must not be stored in any form
○ PIN, CVV2
● A stored PAN must be masked or encrypted
○ MySQL encryption functions
○ Transparent Data Encryption
● Ensure logs do not contain sensitive data
● ClusterControl
○ Helps understanding the database
structure
○ Allows to check its logs

34. 4. Encrypt transmission of cardholder data
across open, public networks
Copyright 2017 Severalnines AB
● Setup TLS between database nodes
○ Replication traffic
● Setup TLS from application to database
● ClusterControl can set up the TLS
connections between nodes and for
database users

35. Example: Encrypting client/server traffic +
intra-cluster replication traffic
Copyright 2017 Severalnines AB

36. 6. Develop & maintain secure systems &
applications
Copyright 2017 Severalnines AB
● Track
○ what is running in production
○ vulnerabilities and current risk level
● Patch
○ any critical vulnerability within a month
○ non-critical ones within 3 months
● Separate dev and staging environments

37. Upgrade Report
from ClusterControl

38. Automate upgrades via ClusterControl
Copyright 2017 Severalnines AB
● Makes database upgrades simpler:
○ Each node is upgraded in turn without service
interruption
○ After the database version is upgraded, the schema is
updated by the script
● Makes system upgrades simpler
○ After the OS is updated (yum upgrade, …), each node
can be rebooted in sequence
● No service interruption during upgrades

39. Automate upgrades via ClusterControl
Copyright 2017 Severalnines AB

40. ClusterControl built on standard bricks
Copyright 2017 Severalnines AB
● ClusterControl uses Apache, PHP, ssh, from standard
Linux distributions
● Easier for Severalnines developers to follow industry
Best Practices
● Easier for end-users to deploy and manage using
standard tools

41. 7. Restrict access to cardholder data by business
need to know
Copyright 2017 Severalnines AB
● Root account accessed from localhost
● Administrator manages the DB but does not
access the content
● Developer account defines DB structure
● Service accounts to access content, used
only by application and limited to its needs
● Least privilege model
● Accounts and privileges can be audited in
ClusterControl in different environments:
development, staging, production

42. 8. Identify & authenticate access to system
components
Copyright 2017 Severalnines AB
● View of all granted users + permissions
● Control addition/deletion of user IDs
● No shared ID rule
● ClusterControl
○ shows all database user accounts at a
glance
○ can use LDAP for its own access control

43. User Mgmt: Single view
Copyright 2017 Severalnines AB

44. 10. Track & monitor all access to network
resources & cardholder data
Copyright 2017 Severalnines AB
● ClusterControl keeps
○ an audit trail for management access
○ logs to remote syslog server
● Audit plugins from MariaDB and Percona

45. 10. Track & monitor all access to network
resources & cardholder data
Copyright 2017 Severalnines AB
● ClusterControl keeps
○ an audit trail for management access
○ logs to remote syslog server
● Audit plugins from MariaDB and Percona

46. 10. Track & monitor all access to network
resources & cardholder data
Copyright 2017 Severalnines AB
● ClusterControl keeps
○ an audit trail for management access
○ logs to remote syslog server
● Audit plugins from MariaDB and Percona

47. 10. Track & monitor all access to network
resources & cardholder data
Copyright 2017 Severalnines AB

48. 1. Install & maintain a firewall configuration to
protect cardholder data
Copyright 2017 Severalnines AB
● Different flows of data either allowed or
blocked
● Limit incoming/outgoing connections to
what is absolutely needed

49. 5. Protect all systems against malware & regularly
update anti-virus software or programmes
Copyright 2017 Severalnines AB
● Understand impact on database performance
● Can create false positives on certain file formats
● ClusterControl can’t help with that :)

50. 9. Restrict physical access to cardholder data
Copyright 2017 Severalnines AB
● Not directly applicable to ClusterControl

51. 11. Regularly test security systems and processes
Copyright 2017 Severalnines AB
● ClusterControl will be itself scanned
● It works as for any other web application
without adding an additional burden
● It helps keep the database part up to date

52. 12. Maintain an information security policy for all
personnel
Copyright 2017 Severalnines AB
● Last but not least, and often overlooked:
technology matters, but people stay in
charge
● Streamline the management of the
database environment via ClusterControl
● Management actions performed via UI

53. Copyright 2017 Severalnines AB
Copyright 2017 Severalnines AB
Conclusion

54. An ongoing process
Copyright 2017 Severalnines AB
● Payment card security not a fixed goal
● PCI Standard is upgraded every year
○ Announced last week: PCI SPoC*
● Environments must evolve with the changes
* https://www.pcisecuritystandards.org/pdfs/SPOC_Press_Release_24_Jan.pdf

55. Making Compliance less time consuming
Copyright 2017 Severalnines AB
● MySQL/MariaDB not designed for modern security
● Reaching compliance for an existing environment can be
overwhelming
● Leverage reliable database tools to ease out crucial parts
● Automate and manage your MySQL & MariaDB databases
with ClusterControl

56. Secure DB Setup with ClusterControl
Copyright 2017 Severalnines AB
● A simple example of a CDE with
ClusterControl

57. Copyright 2017 Severalnines AB
Copyright 2017 Severalnines AB
Q&A

58. Additional Resources
Copyright 2017 Severalnines AB
● White paper: How to achieve PCI compliance for MySQL
& MariaDB with ClusterControl
● ClusterControl in Financial Technology
● Download ClusterControl
● Contact us: info@severalnines.com
