Universal Wellhead Services provides wellhead equipment and services to the oil and gas industry. Their product catalog outlines their offerings which include:
- Casing heads, casing spools, tubing heads, and casing hangers to support and seal multiple casing strings.
- Secondary seals, chokes, valves, and other accessories.
- They have manufacturing and service locations across the US and offer custom designs, repairs, and 24/7 service support.
- UWS prides itself on superior customer service, low cost manufacturing, safety, and dependability.
