1. Searching techniques Searching : It is a process to find whether a particular value with specified properties is present or not among a collection of items. If the value is present in the collection, then searching is said to be successful, and it returns the location of the value in the array. Otherwise, if the value is not present in the array, the searching process displays the appropriate message and in this case searching is said to be unsuccessful. 1) Linear or Sequential Searching 2) Binary Searching Linear_Search (A[ ], N, val , pos ) Step 1 : Set pos = -1 and k = 0 Step 2 : Repeat while k < N Begin Step 3 : if A[ k ] = val Set pos = k print pos Goto step 5 End while Step 4 : print “Value is not present” Step 5 : Exit int main( ) { int arr [ 50 ] , num , i , n , pos = -1; printf ("How many elements to sort : "); scanf ("%d", &n); printf (" Enter the elements : "); for( i = 0; i < n; i++ ) { printf (“arr [%d ] : “ , i ); scanf( "%d", &arr[ i ] ); } printf(“Enter the number to be searched : “); scanf(“%d”,&num); for(i=0;i<n;i++) if( arr [ i ] == num ) { pos = i ; break; } if ( pos == -1 ) printf(“ %d does not exist ”,num); else printf(“ %d is found at location : %d”, num , pos); Searches -- for each item one by one in the list from the first, until the match is found. Efficiency of Linear search : -- Executes in O ( n ) times where n is the number of elements in the list.
2.
3.
4. Bubble Sort Unsorted Sorted Bubbles up the highest After Pass 1 After Pass 2 After Pass 3 After Pass 4 After Pass 5 Bubble_Sort ( A [ ] , N ) Step 1 : Repeat For P = 1 to N – 1 Begin Step 2 : Repeat For J = 1 to N – P Begin Step 3 : If ( A [ J ] < A [ J – 1 ] ) Swap ( A [ J ] , A [ J – 1 ] ) End For End For Step 4 : Exit Complexity of Bubble_Sort The complexity of sorting algorithm is depends upon the number of comparisons that are made. Total comparisons in Bubble sort is n ( n – 1) / 2 ≈ n 2 – n Complexity = O ( n 2 ) Original List 10 47 12 54 19 23 54 10 47 12 23 19 54 47 10 23 12 19 54 47 23 10 19 12 54 47 23 19 10 12 54 47 23 19 12 10
5. void print_array (int a[ ], int n) { int i; for (i=0;I < n ; i++) printf("%5d",a[ i ]); } void bubble_sort ( int arr [ ], int n) { int pass, current, temp; for ( pass=1;(pass < n) ;pass++) { for ( current=1;current <= n – pass ; current++) { if ( arr[ current - 1 ] > arr[ current ] ) { temp = arr[ current - 1 ]; arr[ current - 1 ] = arr[ current ]; arr[ current ] = temp; } } } } int main() { int count,num[50],i ; printf ("How many elements to be sorted : "); scanf ("%d", &count); printf(" Enter the elements : "); for ( i = 0; i < count; i++) { printf ("num [%d] : ", i ); scanf( "%d", &num[ i ] ); } printf(" Array Before Sorting : "); print_array ( num, count ); bubble_sort ( num, count); printf(" Array After Sorting : "); print_array ( num, count ); } Bubble Sort For pass = 1 to N - 1 For J = 1 to N - pass A [ J – 1 ] > A [ J ] Temp = A [ J – 1 ] A [ J – 1 ] = A [ J ] A [ J ] = Temp T F Return
6. Insertion Sort TEMP Insertion_Sort ( A [ ] , N ) Step 1 : Repeat For K = 1 to N – 1 Begin Step 2 : Set Temp = A [ K ] Step 3 : Set J = K – 1 Step 4 : Repeat while Temp < A [ J ] AND J >= 0 Begin Set A [ J + 1 ] = A [ J ] Set J = J - 1 End While Step 5 : Set A [ J + 1 ] = Temp End For Step 4 : Exit insertion_sort ( int A[ ] , int n ) { int k , j , temp ; for ( k = 1 ; k < n ; k++ ) { temp = A [ k ] ; j = k - 1; while ( ( temp < A [ j ] ) && ( j >= 0 ) ) { A [ j + 1 ] = A [ j ] ; j - - ; } A [ j + 1 ] = temp ; } } Complexity of Insertion Sort Best Case : O ( n ) Average Case : O ( n 2 ) Worst Case : O ( n 2 ) 78 23 45 8 32 36 23 78 45 8 32 36 23 23 45 78 8 32 36 8 23 45 78 32 36 8 23 32 45 78 36 45 8 8 23 32 36 45 78 32 36
7. Selection Sort ( Select the smallest and Exchange ) Smallest Selection_Sort ( A [ ] , N ) Step 1 : Repeat For K = 0 to N – 2 Begin Step 2 : Set POS = K Step 3 : Repeat for J = K + 1 to N – 1 Begin If A[ J ] < A [ POS ] Set POS = J End For Step 5 : Swap A [ K ] with A [ POS ] End For Step 6 : Exit selection_sort ( int A[ ] , int n ) { int k , j , pos , temp ; for ( k = 0 ; k < n - 1 ; k++ ) { pos = k ; for ( j = k + 1 ; j <= n ; j ++ ) { if ( A [ j ] < A [ pos ] ) pos = j ; } temp = A [ k ] ; A [ k ] = A [ pos ] ; A [ pos ] = temp ; } } Complexity of Selection Sort Best Case : O ( n 2 ) Average Case : O ( n 2 ) Worst Case : O ( n 2 ) 23 78 45 8 32 56 8 78 45 23 32 56 8 23 45 78 32 56 8 23 32 78 45 56 8 23 32 45 78 56 8 23 32 45 56 78 8 23 32 45 56
8. Insertion sort k = 1; k < n ; k++ temp = a [ k ] j = k - 1 temp < a [ j ] && j >= 0 a [ j + 1 ] = a [ j ] j = j - 1 a [ j + 1 ] = temp return Selection sort k = 0; k < n - 1 ; k++ pos = k j = k + 1 ; j < n ; j++ temp = a[ k ] a [ k ] = a [ pos ] a [ pos ] = temp return a[ j ] < a[ pos ] pos = j
9. Bubble sort – Insertion sort – Selection sort Bubble Sort : -- very primitive algorithm like linear search, and least efficient . -- No of swappings are more compare with other sorting techniques. -- It is not capable of minimizing the travel through the array like insertion sort. Insertion Sort : -- sorted by considering one item at a time. -- efficient to use on small sets of data. -- twice as fast as the bubble sort. -- 40% faster than the selection sort. -- no swapping is required. -- It is said to be online sorting because it continues the sorting a list as and when it receives new elements. -- it does not change the relative order of elements with equal keys. -- reduces unnecessary travel through the array. -- requires low and constant amount of extra memory space. -- less efficient for larger lists. Selection sort : -- No of swappings will be minimized. i.e., one swap on one pass. -- generally used for sorting files with large objects and small keys. -- It is 60% more efficient than bubble sort and 40% less efficient than insertion sort. -- It is preferred over bubble sort for jumbled array as it requires less items to be exchanged. -- uses internal sorting that requires more memory space. -- It cannot recognize sorted list and carryout the sorting from the beginning, when new elements are added to the list.
10. Quick Sort – A recursive process of sorting Algorithm for Quick_Sort : -- set the element A [ start_index ] as pivot. -- rearrange the array so that : -- all elements which are less than the pivot come left ( before ) to the pivot. -- all elements which are greater than the pivot come right ( after ) to the pivot. -- recursively apply quick-sort on the sub-list of lesser elements. -- recursively apply quick-sort on the sub-list of greater elements. -- the base case of the recursion is lists of size zero or one, which are always sorted. Original-list of 11 elements : Set list [ 0 ] as pivot : pivot pivot Rearrange ( partition ) the elements into two sub lists : Sub-list of lesser elements Sub-list of greater elements Apply Quick-sort recursively on sub-list Apply Quick-sort recursively on sub-list Complexity of Quick Sort Best Case : O ( n log n ) Average Case : O ( n log n ) Worst Case : O ( n 2 ) 8 3 2 11 5 14 0 2 9 4 20 8 3 2 11 5 14 0 2 9 4 20 4 3 2 2 5 0 8 11 9 14 20
12. Quick Sort – Program void quick_sort(int a[ ] , int beg , int end ) { int loc; if ( beg < end ) { loc = partition( a , beg , end ); quick_sort ( a , beg , loc – 1 ); quick_sort ( a , loc + 1 , end ); } } void print_array (int a [ ],int n) { int i; for ( i = 0 ; I < n ; i++ ) printf( "%5d“ ,a [ i ] ) ; } int main () { int count , num[ 50 ] , i ; printf ("How many elements to sort : "); scanf ("%d", &count ); printf (" Enter the elements : "); for( i = 0; i < count; i++ ) { printf ("num [%d ] : “ , i ); scanf( "%d", &num[ i ] ); } printf (“ Array Before Sorting : “ ); print_array ( num , count ) ; quick_sort ( num ,0 , count-1) ; printf ( " Array After Sorting : “ ); print_array ( num , count ); } int partition ( int a [ ], int beg, int end ) { int left , right , loc , flag = 0, pivot ; loc = left = beg; right = end; pivot = a [ loc ] ; while ( flag == 0 ) { while( (pivot <= a [ right ] )&&( loc != right ) ) right - - ; if( loc == right ) flag = 1; else { a [ loc ] = a [ right ] ; left = loc + 1 ; loc = right; } while ( (pivot >= a [ left ] ) && ( loc != left ) ) left++; if( loc == left ) flag = 1; else { a [ loc ] = a [ left ] ; right = loc - 1; loc = left; } } a [ loc ] = pivot; return loc; }
13. partition ( int a [ ], int beg, int end ) loc = left = beg flag = 0, right = end pivot = a [ loc ] Flag == 0 pivot <= a [ right ] && loc != right right = right - 1 loc == right a [ loc ] = a [ right ] left = loc + 1 ; loc = right; flag = 1 F T B A B A pivot >= a [ left ] &&loc != left left = left + 1 loc == left a [ loc ] = a [ left ] right = loc - 1 ; loc = left; flag = 1 F T a[ loc ] = pivot return loc quick_sort ( int a [ ], int beg, int end ) loc == left T loc = partition( a , beg , end ) quick_sort ( a , beg , end ) quick_sort ( a , beg , end ) F return
14.
15. void merge(int a[ ],int low,int high,int mid){ int i, j, k, c[50]; i=low; j=mid+1; k=low; while( ( i<=mid )&&( j <= high ) ) { if( a[ i ]<a[ j ] ){ c[ k ]=a[ i ]; k++; i++; }else { c[ k ]=a[ j ]; k++; j++; } } while( i<=mid ) { c[k]=a[ i ]; k++; i++; } while(j<=high) { c[k]=a[ j ]; k++; j++; } for(i=low;i<k;i++) a[ i ]=c[ i ]; } void merge_sort(int a[ ], int low, int high){ int mid; if( low < high) { mid=(low+high)/2; merge_sort (a, low, mid); merge_sort (a, mid+1 ,high); merge (a, low, high, mid); } } Merge Sort - Program void print_array (int a [ ],int n) { int i; for ( i = 0 ; I < n ; i++ ) printf( "%5d“ ,a [ i ] ) ; } int main () { int count , num[ 50 ] , i ; printf ("How many elements to sort : "); scanf ("%d", &count ); printf (" Enter the elements : "); for( i = 0; i < count; i++ ) { printf ("num [%d ] : “ , i ); scanf( "%d", &num[ i ] ); } printf (“ Array Before Sorting : “ ); print_array ( num , count ) ; merge_sort ( num ,0 , count-1) ; printf ( " Array After Sorting : “ ); print_array ( num , count ); }
16. Merge_Sort low < high mid = ( low + high ) / 2 merge_sort (a, low, mid) merge_sort (a, mid, high ) Merge (a, low,high , mid) Return T F merge i =low ; j = mid+1;k = low i <= mid && j <= high a[ i ] < a[ j ] c[ k ] =a [ i ] ; k++ ; i++ c[ k ] =a [ j ] ; k++ ; j++ i <= mid c[ k ] =a [ i ] ; k++ ; i++ j <= high c[ k ] =a [ j ] ; k++ ; j++ i = low ; i < k ; i ++ a[ i ] = c [ i ] return F T
![Searching techniques Searching : It is a process to find whether a particular value with specified properties is present or not among a collection of items. If the value is present in the collection, then searching is said to be successful, and it returns the location of the value in the array. Otherwise, if the value is not present in the array, the searching process displays the appropriate message and in this case searching is said to be unsuccessful. 1) Linear or Sequential Searching 2) Binary Searching Linear_Search (A[ ], N, val , pos ) Step 1 : Set pos = -1 and k = 0 Step 2 : Repeat while k < N Begin Step 3 : if A[ k ] = val Set pos = k print pos Goto step 5 End while Step 4 : print “Value is not present” Step 5 : Exit int main( ) { int arr [ 50 ] , num , i , n , pos = -1; printf ("How many elements to sort : "); scanf ("%d", &n); printf (" Enter the elements : "); for( i = 0; i < n; i++ ) { printf (“arr [%d ] : “ , i ); scanf( "%d", &arr[ i ] ); } printf(“Enter the number to be searched : “); scanf(“%d”,&num); for(i=0;i<n;i++) if( arr [ i ] == num ) { pos = i ; break; } if ( pos == -1 ) printf(“ %d does not exist ”,num); else printf(“ %d is found at location : %d”, num , pos); Searches -- for each item one by one in the list from the first, until the match is found. Efficiency of Linear search : -- Executes in O ( n ) times where n is the number of elements in the list.](https://image.slidesharecdn.com/unit6-111030014123-phpapp01/85/unit6-c-1-320.jpg)
