Professional Fluid Head                                                                                                                           Professional Tripod Kit
Professional Tripod - ZEUS




                                                                                                                                                                                                                                                                                            Professional Tripod - ZEUS
                                   100mm Bowl Head                                                                                                                                   ZEUS Series Tripod Kit

                                   ZEUS                                                                                                                                              ZEUS EFP Kit

                                                                                                                                                                                                                TX-V20 Fluid Head
                                                                                                                                 The Zeus fluid head is an extensively high                                     Two-Stage EFP Heavy-Duty Carbon Fiber Tripod
                                                                                                                                 quality tripod product for professional content                                Heavy-Duty Ground Spreader
                                                                                                                                 creators in ENG/EFP and HD field production. It                                Soft Case
                                                                                                                                 perfectly support portable broadcast camcor-                                   Also available with off ground spreader
                                                                                                                                 dor, heavy configured camcorder, studio
                                                                                                                                 application with teleprompter or studio compact
                                                                                                                                 lens and even light 3D rig. It can be used for
                                                                                                                                 documentary making, commercial, drama,
                                                                                                                                 feature film and high quality television produc-
                                                                                                                                                                                                              Specification
                                                                                                                                 tion.                                                                              Payload Range           12-26 kgs/26.45-57.32 lbs
                                                                                                                                 Zeus head is built with high quality craftsman-                                        Weight              10.5 kgs/23 lbs
                                                                                                                                 ship. With the selectable 8 position counterbal-                                  Maxiumum Height          1.80 m/70.86 in
                                                                                                                                 ance, Zeus is able to balance payload between
                                                                                                                                 12-26 kgs/26-57 lbs. 7 position pan & tilt drag                                   Minimum Height           0.76 m/20.92 in
                                                                                                                                 proivde professional drag performance and                                         Transport Length         0.97 m/38.18 in
                                                                                                                                 offer operators the silky smooth movement and
                                                                                                                                 precise framing.

                                                                                                                                 It is equipped with camera platform with
                                                                                                                                 extensively 120mm sliding range and
                                                                                                                                 illuminated leveling bubble. It adopts quick
                                                                                                                                 release mini Euro plate system, enable the
                                                                                                                                 easy setup of cameras.

                                                                                                                                 Combined with our heavy-duty EFP tripod, it is
                                                                                                                                 surely the best cost effective tripod solution in
                                      Perfect professional drag performance, selectable 7 positions pan &                        its class.
                                      tilt drag including zero position.
                                      Selectable 8 position counterbalance system for payloads between
                                      12-26kg.
                                      Quick release, camera platform with extensive 120mm sliding range
                                      and mini Euro plate mounting.

                                      Readily accessible controls and illuminated bubble level.

                                      Ideal for the EFP configuration, HD field production and studio
                                      application.
                                                                                                            Specification
                                      100mm ball levelling
                                                                                                                  Model Number                  TX-V20
                                                                                                                  Payload Range                 12-26 kgs/26.45-57.32 lbs
                                                                                                               Camera Platform Type             Mini Euro Plate
                                                                                                                   Sliding Range                120 mm/2.75 in
                                                                                                                   Camera Plate                 1/4" and 3/8" screw
                                                                                                              Counterbalance System             8 steps (1-8)
                                                                                                                     Tilt Drag                  7 steps (0+6)
                                                                                                                                                                                                Heavy-Duty EFP Tripod with new enhanced heavy duty ground spreader
                                                                                                                     Tilt Range                 +90/-75°
                                                                                                                     Tilt Lock                  Calliper disc brake system
                                                                                                                     Pan Drag                   7 steps (0+6)
                                                                                                                    Pan Range                   360°
                                                                                                                     Pan Lock                   Calliper disc brake system
                                                                                                            Operating Temperature Range         -40°C to +65°C/104°F to +140°F
                                                                                                                      Pan Bar                   Double Telescopic
                                                                                                                  Levelling Bubble              Yes, illuminated
                                                                                                                      Weight                    5.45 kg/12.01 lbs
                                                                                                                  Bowl Diameter                 100 mm




                             Nediva 2011                                                                                                                                                                                                                                www.nedivapro.com
