1. The Triax TSS400 is a device that converts satellite TV signals to IP streams, allowing satellite channels to be viewed on smartphones, tablets, and other devices connected to the home network.
2. It has 4 tuners that receive signals from a quad or quattro LNB, and its web interface allows for configuring settings like network information, software updates, and LNB settings.
3. Mobile apps are available to view live TV, recordings, and guide information from the TSS400 over WiFi, with features like timeshifting and downloading updated channel lists.
