The document summarizes the specifications of the SUBLI 1510 large format sublimation press. It can sublimate items up to 150 x 100 cm in size with fast heating up times and multi-zone temperature control. The press is manufactured in France and comes with a 2-year warranty. It is suited for applications like sports goods, advertising, photos and posters through sublimation transfer on textiles and rigid surfaces.

1. SUBLI 1510
High thermal efficiency.
- Ideal for sublimation with
good productivity and flexibility.
- Multizones temperature control
- Fast startup ! (15 to 20min)
- Plate size : 150 x 100 cm
- 2 years guarantee on the machine.
- Manufactured in France.
LARGE FORMAT SUBLIMATION PRESS
- Application examples :
* Sports goods.
* Advertising, flags, banners, accessories.
* Large photos, posters.
* Transfer on Hard Substrate
(ceramic, aluminium, plastic, wood...)
* Textile : home finishing, apparel, curtains...
Powerful Extraction fan
Driven front load double sliding plate
Hidden time preparation from single
operator.
Z.I. de Pastabrac - 11260 ESPERAZA - FRANCE
Tél. +33 (0)4 68 74 05 89 - Fax +33 (0)4 68 74 24 08
E-mail : contact@sefa.fr - Web-site : www.sefa.fr

2. Advantages Dimensions
Touch Screen PanelTechnical characteristics
220 cm
211 cm
166 cm
Box weight : 175kg
140 cm
1500 x 1000 mm
900 kg
175 kg
4000 daN
220°C
400 V
17.5 KW
28 A
4 to 8 bars
35 mm
- Mechanics :
* Designed and built for big productions.
* Double driven plates, working
alternatively.
* Pressure transmitted by 4 air cylinders.
- Quality :
* Security assured by an optical detection
cell and 3 emergency stop buttons.
* Reinforcement of the plates : allows to
sublimate some heavy media (such as
ceramic tiles).
* 2 independent thermocontrol for very
consistent edge to edge temperature
control
.
- Ergonomy :
* Touch screen panels and user friendly
interface.
* Preparation of next transfer in hidden
time.
Plates Sizes
Weight
Packaging weight
Pressure
Max Temperature
Power Supply
(3phase current)
Electric Power
Amperage
Compressed air required
Max thickness of materials
Electronics developped by Sefa.
From 0 to 220°C (precision +/- 0.5%).
Temperature rising time from 0 to 180°C : 15 mn.
260 cm
- Accurate and fast regulation (PID control) for a
wide range of heat transfer products :
* Sublimation on textiles (sports goods, flags,
banners..)
* Sublimation on rigid substrates (Aluminium,
MDF for photos transfers)
- Multizones temperature adjustment.
- Multilingual interface.
Non contractuel document - Depending on changes in range, we reserve the right to modify the characte-
ristics of our products.
Do not discard on the street.
195 cm
