SplunkApplicationLoggingBestPractices_Template_2.3.pdf
- 2. § Reality of Event Logging § Liberating Application Data § Operational Best Practices § Data Enrichment | Other Data Sources § More Developer Tools Agenda 2
- 3. 3 Reality of Event Logging
- 4. The Accelerating Pace of Data Volume | Velocity | Variety | Variability GPS, RFID, Hypervisor, Web Servers, Email, Messaging, Clickstreams, Mobile, Telephony, IVR, Databases, Sensors, Telematics, Storage, Servers, Security Devices, Desktops Machine data is the fastest growing, most complex, most valuable area of big data
- 5. Event Logs Suck Online Services Web Services Servers Security GPS Location Storage Desktops Networks Packaged Applications Custom Applications Messaging Telecoms Online Shopping Cart Web Clickstreams Databases Energy Meters Call Detail Records Smartphones and Devices RFID On-‐ Premises Private Cloud Public Cloud § They have some structure § Structure is not consistent § Structure is non-‐standard § Keys can be stored separately § High volume, growing every day § Hard to access § Take up tons of space § Clog up the network
- 6. Event Logs Suck 050818 16:19:31 2 Query UPDATE xar_session_info SET xar_vars= 'XARSVuid|i:2;XARSVrand|i:343223999;XARSVuaid|s:2:"29";XARSVbrowsername|s:9:"Netscape6";XARSVbrowserversion|s: 3:"5.0";XARSVosname|s:7:"Unknown";XARSVosversion|s:7:"Unknown";XARSVnavigationLocale|s:11:"en_US.utf-‐ 8";SPLUNKAPP_IP|N;', xar_lastused = 1124407171 WHERE xar_sessid ='ll7joq442223fl6h07v3f3vpd2’ 10 Query UPDATE xar_session_info SET xar_vars= 'XARSVuid|i:2;XARSVrand|i:89426315;XARSVuaid|s :2:"29";XARSVbrowsername|s:9:"Netscape6";XARSVbrowserversion|s:3:"5.0";XARSVosname|s:7:"Unknown";XARSVosv ersion|s:7:"Unknown";XARSVnavigationLocale|s:11:"en_US.utf-‐8";SPLUNKAPP_IP|N;', xar_lastused = 1124407193 WHERE xar_sessid = 't2idg584t1co0scgj40qnnm’ 31 Connect caveuser@web2.int.splunk.com on cave Jun 2 13:36:50 DEBUG[1826]: Setting NAT on RTP to 0 Jun 2 13:36:50 DEBUG[1826]: Check for res for 5008office Jun 2 13:36:50 DEBUG[1826]: Call from user '5008office' is 1 out of 0 Jun 2 13:36:50 DEBUG[1826]: build_route: Contact hop: <sip:5008office@10.1.1.132:5060> Jun 2 13:36:50 VERBOSE[10887]: -‐-‐ Executing Macro("SIP/5008office-‐dfbd", ”
- 7. Apr 29 19:13:01 45.2.98.7 SentriantGenericAlert: Time="04/29/06 07:12 PM PDT",Host="roach_motel.enet.interop.net",Category="fabric_network_activity",Generator="R esponse:Slow Scan",Type="NOTICE",Priority="High",Body="Appliance=roach_motel.enet.interop.net,Reporti ng Segment=ENET network,Action=Response disabled,Response=Slow Scan,Duration=90 seconds,Source Segment=Unprotected,Source IP=88.73.39.200,Source MAC=00:01:30:BC:93:90,Current Target Count=0" Apr 29 19:13:01 45.2.98.7 SentriantGenericAlert: Time="04/29/06 07:12 PM PDT",Host="roach_motel.enet.interop.net",Category="fabric_network_activity",Generator="R esponse:Slow Scan",Type="NOTICE",Priority="High",Body="Appliance=roach_motel.enet.interop.net,Reporti ng Segment=ENET network,Action=Response disabled,Response=Slow Scan,Duration=69 seconds,Source Segment=Unprotected,Source IP=68.163.20.95,Source MAC=00:01:30:BC:93:90,Current Target Count=0" Apr 29 19:13:01 45.2.98.7 SentriantGenericAlert: Time="04/29/06 07:12 PM PDT",Host="roach_motel.enet.interop.net",Category="fabric_network_activity",Generator="R esponse:Slow 45.2.98.7 SentriantGe nericAlert: Time="04 Event Logs Rocks
- 8. • Ensure system security • Meet compliance mandates • Customer behavior and experience • Product and service usage • End-‐to-‐end transaction visibility Definitive record of activity and behavior Important insight for IT and the business 10.2.1.44 - [25/Sep/2009:09:52:30 -0700] type=USER_LOGIN msg=audit(1253898008.056:199891): user pid=25702 uid=0 auid=4294967295 msg='acct="TAYLOR": exe="/usr/sbin/sshd" (hostname=?, addr=10.2.1.48, terminal=sshd res=failed)' User IP Action Login Result 10.2.1.80 - - [25/Jan/2010:09:52:30 -0700] "GET /petstore/product.screen ?product_id=AV-CB-01 HTTP/1.1" 200 9967 "http:// category.screen?category_id=BIRDS" "Mozilla/5.0 ( Linux)”"JSESSIONID=xZDTK81Gjq9gJLGWnt2NXrJ2tpGZb1 User IP Product Category Gold Mine of Information 8
- 9. Interpretation = Real Business Value 9
- 10. 10
- 11. The Mighty Application Log Operations Security Business Intelligence Social/ Mobile § How many transactions are failing? § Which specific transactions are failing? § Is system performance falling behind? § Who is accessing the app? When? § What activity looks suspicious? § Is the application behaving as expected? § What is the purchase volume over time? § How do purchases compare to last month? § How are customers affected by app issues? § How is the customer experience? § Are transactions taking too long? § Where are transactions happening?
- 12. Traditional Analytics SELECT customers.* FROM customers WHERE customers.customer_id NOT IN(SELECT customer_id FROM orders WHERE year(orders.order_date) = 2004) Early Structure Binding Structure Data § Schema created a design time § Queries understood at design time § Homogenous § Must fit into table or converted to tables § Must match constraints
- 13. Analytics with Splunk Late Structure Binding Structure Data § Schema-‐less § Created at search time § Queries executed ad-‐hoc § Heterogeneous § Constantly changing § No conversion required § No constraints
- 14. Gain Intelligence Quickly Early Structure Binding Decide question to ask Design the schema Normalize data + write DB insertion code Create SQL & feed into analytics tool Write Semantic Events Collect Create Searches, Reports & Graphs Late Structure Binding § Days – Weeks – Months § Destructive § Minutes § Non-‐Destructive
- 16. Current State § You have no control over other system’s events § You have full control over events that YOU write § Most events are written by developers to help them debug § Some events are written to form an audit trail
- 17. Logging with Purpose § Logging for Debugging § Troubleshoot application problems § Identify trends § Categorize issues § Semantic Logging § Record the state of business processes § Examples: web clicks, financial trades, cell phone connections, audit trails, etc. void submitPurchase(purchaseId) { log.info( "action=submitPurchaseStart, purchaseId=%d", purchaseId) // These calls throw an exception: submitToCreditCard(...) generateInvoice(...) generateFullfillmentOrder(...) log.info( "action=submitPurchaseCompleted, purchaseId=%d", purchaseId) }
- 18. Liberating Log Data – In a Nutshell q Use clear key-‐value pairs q Create events humans can read q Use developer-‐friendly formats q Use timestamps for every event q Use unique identifiers (IDs) q Log in text format q Log more than debug events q Use categories q Identify the source q Minimize multi-‐line events
- 19. Use Clear Key-‐Value Pairs § Create Structure from Unstructured Data § Use space or comma delimited § Wrap values with spaces in quotes § Automatic field extraction § Self describing, does not require regular expressions to parse § Keys are stored alongside field values § No additional configuration work for Splunk Admin or Knowledge Manager Example (Good): Log.debug(“orderstatus=error,errorcode=454, user=%d,transactionid=%s”, userId, transId) Example (Bad): Log.debug(“error %d 454 - %s ”, userId, transId)
- 20. Create Human-‐Readable Events § Use ASCII Format § Avoid complex encoding § Avoid formats which require arbitrary code to decipher § Use Consistent Formatting § Separate events with different formats into individual files
- 21. Create Human-‐Readable Events § Avoid Binary Data § Binary data is compressed, but requires decoding and does not segment § Splunk cannot meaningfully search or analyze binary data § If data must be in binary format: § Provide tool to easily convert to ASCII § Create custom Splunk search command to decode binary segments inline § Place textual metadata in the event § For example, do not log the binary data of a JPG file, but do log its image size, creation tool, username, camera, GPS location, etc.
- 22. Use Developer-‐Friendly Formats § JSON and XML are Readable by Humans and Machines § Seamless parsing by most programming languages right in the browser § Useful for capturing hierarchy or membership, and self-‐describing § Easily interpreted by Splunk spath command {"widget": { "text": { "data": "Click here", "size": 36, "data": "Learn more", "size": 37, "data": "Help", "size": 38, }} date size data ---------- ---- ---------- 2014-08-12 36 Click here 37 Learn more 38 Help
- 23. Use Timestamps § Time is a First Class Citizen § Timestamps are critical to understanding the sequence of events for debugging, analytics, and deriving transactions § Timestamps are automatically detected, but best to use an intelligent format § Timestamp Dos § Use most verbose granularity, if possible microseconds since events can become orphaned from the originating event § Place timestamps at beginning of event § Include a four digit year § Include a time zone § Timestamp Do Nots § Do not use a time offset Example (Good): 08/12/2014:09:16:35.842 GMT INFO key1=value1 key2=value2
- 24. Use Unique Identifiers (IDs) § More Power for Debugging and Analytics § Examples: Transaction IDs, user IDs § Used to find exact transactions § Carry Unique IDs Through Multiple Touch Points § Avoid changing format between modules or systems § Include transitive closures transid=abcdef, transid=abcdef, otherid= qrstuv, . . . . . otherid=qrstuv Transaction
- 25. Unique IDs Through Multiple Touch Points Order ID Customer’s Tweet Time Waiting On Hold Product ID Company’s Twitter ID Order ID Customer ID Twitter ID Customer ID Customer ID Sources Order Processing Twitter Care IVR Middleware Error
- 26. Minimize Multi-‐ Line/Value Events § Multi-‐ Line/Value Events are Less Efficient § More difficult for software to parse § Generate many segments, affects indexing/search speed + disk compression § Break multi-‐line events into separate events § Break multi-‐value fields into separate events for easier manipulation Example (Good): <TS> phonenumber=333-‐444-‐4444, app=angrybirds, installdate=xx/xx/xx <TS> phonenumber=333-‐444-‐4444, app=facebook, installdate=yy/yy/yy Example (Bad): <TS> phonenumber=333-‐444-‐4444, app=angrybirds,facebook
- 27. Log More Than Debug Events § Log anything that can add value when aggregated and/or visualized § user actions § timing § transactions § audit trails § Log Category § Severity levels can aid navigation and baselining § Identify the Source § Use class, function or filename
- 29. Operational Best Practices § Log locally to log files § Provides local buffer § Non-‐blocking during network failures § Use syslog-‐ng or rsyslog + Splunk forwarder for syslog data § Implement rotation policies § Logs take up space § Many compliance regulations require years of archival storage § Decide on destroying or backing up logs
- 30. Operational Best Practices § Use Splunk Forwarders § Data collection in real-‐time § Tracks and maintains state § Enable collection of data over many channels: HTTP | Queues | Multicast | Web services | Databases § Collect events from everything, everywhere § Application logs | database logs | network data | configuration files | performance data | time-‐based data § More data captured = more visibility
- 31. Copyright © 2014 Splunk Inc. 31 Un|Structured Data
- 32. Creating Value With Structured Data Enrich search results with additional business context Easily import data into Splunk for deeper analysis Integrate multiple DBs concurrently Simple set-‐up, non-‐invasive and secure DB Connect provides reliable, scalable, real-‐time integration between Splunk and traditional relational databases Microsoft SQL Server JDBC Database Lookup Database Query Connection Pooling Other Databases Oracle Database Java Bridge Server 32
- 33. Hadoop and NoSQL offer simple storage but hard analytics: difficult to explore, analyze, visualize Hard-‐to-‐staff skills: require months of labor by specialists with rare and expensive skill sets Inflexible approaches: must predefine fixed schemas or program MapReduce jobs Hadoop (MapReduce & HDFS) YARN DataFu H i v e Mahout Pig Sqoop Wide Range of Open Source Projects for Analytics and Data Visualization Azkaban It’s Hard to Turn Raw Data Into Refined Insights NoSQL Data Stores
- 34. Integrated Analytics Platform for Diverse Data Stores Full-‐featured, Integrated Product Fast Insights for Everyone Works with What You Have Today Explore Visualize Dashboard s Share Analyze Hadoop Clusters NoSQL and Other Data Stores Hadoop Client Libraries Streaming Resource Libraries Bi-‐directional Integration with Hadoop
- 36. The Splunk Enterprise Platform Collection Indexing Search Processing Language Core Functions Inputs, Apps, Other Content SDK Content Core Engine User and Developer Interfaces Web Framework REST API
- 37. What’s Possible with the Splunk Enterprise Platform? Power Mobile Apps Log Directly Extract Data Customer Dashboards Integrate BI Tools Integrate Platform Services Developer Platform
- 38. Powerful Platform for Enterprise Developers REST API Web Framework Web Framework Ruby C# PHP Data Models Search Extensibility Modular Inputs SDKs Simple XML JavaScript Django Developers Can Customize and Extend
- 39. Splunk Software for Developers Gain Application Intelligence Build Splunk Apps Integrate and Extend Splunk
- 40. 40 Thank You
