In the binary search, if the array being searched has 32 elements in.pdfarpitaeron555
In the binary search, if the array being searched has 32 elements in it, how many elements of the
array must be examined to be certain that the array does not contain the key? What about 1024
elements? Note: the answer is the same regardless of whether the algorithm is recursive or
iterative.
Solution
Binary Search Algorithm- Fundamentals, Implementation and Analysis
Hitesh Garg | May 15, 2015 | algorithms | 5 Comments
Binary Search Algorithm and its Implementation
In our previous tutorial we discussed about Linear search algorithm which is the most basic
algorithm of searching which has some disadvantages in terms of time complexity,so to
overcome them to a level an algorithm based on dichotomic (i.e. selection between two distinct
alternatives) divide and conquer technique is used i.e. Binarysearch algorithm and it is used to
find an element in a sorted array (yes, it is a prerequisite for this algorithm and a limitation too).
In this algorithm we use the sorted array so as to reduce the time complexity to O(log n). In this,
size of the elements reduce to half after each iteration and this is achieved by comparing the
middle element with the key and if they are unequal then we choose the first or second half,
whichever is expected to hold the key (if available) based on the comparison i.e. if array is sorted
in an increasing manner and the key is smaller than middle element than definitely if key exists,
it will be in the first half, we chose it and repeat same operation again and again until key is
found or no more elements are left in the array.
Recursive Pseudocode:
1
2
3
4
5
6
7
8
9
10
11
12
// initially called with low = 0, high = N – 1
BinarySearch_Right(A[0..N-1], value, low, high) {
// invariants: value >= A[i] for all i < low
value < A[i] for all i > high
if (high < low)
return low
mid = low +((high – low) / 2) // THIS IS AN IMPORTANT STEP TO AVOID BUGS
if (A[mid] > value)
return BinarySearch_Right(A, value, low, mid-1)
else
return BinarySearch_Right(A, value, mid+1, high)
}
Iterative Pseudocode:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
BinarySearch_Right(A[0..N-1], value) {
low = 0
high = N - 1
while (low <= high) {
// invariants: value >= A[i] for all i < low
value < A[i] for all i > high
mid = low +((high – low) / 2) // THIS IS AN IMPORTANT STEP TO AVOID BUGS
if (A[mid] > value)
high = mid - 1
else
low = mid + 1
}
return low
}
Asymptotic Analysis
Since this algorithm halves the no of elements to be checked after every iteration it will take
logarithmic time to find any element i.e. O(log n) (where n is number of elements in the list) and
its expected cost is also proportional to log n provided that searching and comparing cost of all
the elements is same
Data structure used -> Array
Worst case performance -> O(log n)
Best case performance -> O(1)
Average case performance -> O(log n)
Worst case space complexity -> O(1)
So the idea is-
RECURSIVE Implementation of Binary search in C programming language
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
.
