This document provides information about the SAP - 2016 16 Channel PCI Card. It is a 16 channel PCI card with caller ID recognition and hardware compression chips that provide better voice quality while saving hard disk space. It supports Windows operating systems and can record phone calls in various modes. It also has features like caller ID popup, conversation monitoring, call logging, backup and more. The technical specifications include its size, weight, channel capacity, compression rates, voltage resistance, power consumption and other details.

1. SAP - 2016 – 16 Channel PCI Card
Website : www.sapelectronics.com
SAP – 2016 PCI Card basic function
Is PCI card, 16 channels.
CallerID King Tech", get perfect caller ID recognizing rate.Thicker golden
finger PCB, more stable to any PC.
Hardware compress(rate=2/5) chips added to board,get better voice quality,
save a lot of HDD space.
Support DTMF/FSK incoming CallerID.
Support Incoming CallerID Popup.
135 Hours /G HDD
Supports Windows 98/2000/XP/2003/NT/Win7 /Vista 32/64 Bit System
Support DTMF/FSK incoming CallerID, Support Incoming CallerID Popup
Consists of the incoming customer management system to recognize the incomers and
the Popup Screen
Support monitor the conversation for every line on the real time by LAN
Supports three recorder mode : Phone, Audio, Key
Support list and print all the dialed-in, dialed-out and missed calls
Can record the direct call. Support the simultaneous recording for the direct phone
and extension
Supports auto-backup, FTP back up the files onto the burning ROM, supports the auto
fold repeat.
The outward phone cables, extension cables, ISDN catalog cables, output cables for
the wireless interphones are
Alarm information displayed on the screen or in the e-mails when e meeting abnormal
situation (cable broken)
Support duple/quintuple/octuple compression and save and WAV format
Support inquire, play and monitoring for the network.

2. SAP - 2016 – 16 Channel PCI Card
Website : www.sapelectronics.com
SAP – 2108 PCI Card Technical Parameter
Size: 260mm(L)*112m(W) Weight: About 350g
Channel: 16 port
Compress
Rate:
Hardware=2
Software=5
Module voltage
resistance:
250V Codec: HDB3 /AMI
Max installation for
1 PC:
10(80 channel)
Power
Consumption:
¡Ü15W
Working
Temperature
5¡æ-40¡æ
Signal-To-
Noise:
¡Ý30dB
Humidity: 5%-85%
Storage
Temperature:
-20¡æ-70¡æ
Frequency Range: 300-3400Hz£¨¡À3dB£©
Input
Impedance:
600¦¸
Clock and Data
Recorering
Complied to CCITT
Rec.G.823-1988
Frame
Structure:
CCITT G.704-
1988
Data Rate: 64KBPS¡¢32KBPS¡¢16KBPS
Voice
Distortion
Rate:
¡Ü2%
Caller ID: FSK¡¢DTMF
FSK Modulate
Mode:
Logical
0:2200Hz¡À1%
Signal Monitor: Signal sound,voice sound ¡¡
Logical
1:1200Hz¡À1%
DTMF Code 0~9¡¢*¡¢#¡¢A¡¢B¡¢C¡¢D
Data
Transmission:
Binary
asynchronous
serial
Voice
Function:
WAV, VC2,
VC5,AGC
Shaking limit£º Complied to CCITT Rec.G.823,G.737,G.739,G.742-1988
Phone Status Judge Voltage70-100V(Ring) 20-48V(Idle) 5-17V(Hang up)
3.2V(Power off)
