Release Engineering at
Eclipse
Sravan Kumar Lakkimsetti
Lead – Releng Project and Committer on SWT
IBM India
27 August
2016
Release Engineering at Eclipse 2
Agenda
 Architecture
 Types of builds
 Build
 Git Cloning
 Maven build
 Signing
 Packaging
 Build Promotion
 Automated testing
27 August
2016
Release Engineering at Eclipse 3
Architecture
27 August
2016
Release Engineering at Eclipse 4
Platform
HIPP
Releng
HIPP
Shared
HIPP
Build.eclipse.org GIT
Download.ecl
ipse.org
Centos test
machine
Mac test
machine
Windows
test
machine
SLES test
machine
Types of Builds
 Generic Builds
 N – build (nightly build)
 Built on master
 Every day
 I – build (Integration build)
 Built on master branch on every Tuesday.
 M – build (maintenance build)
 Built on maintenance branch
 Currently on R4.6_maintenance
 Built on every Wednesday
27 August
2016
Release Engineering at Eclipse 5
Build
 Build runs on build.eclipse.org
 Triggered by Releng HIPP
 Uses master-build.sh
 Master Build Script
 Git repo cloning
 Maven Build
 Build Promotion
 Triggering Tests
27 August
2016
Release Engineering at Eclipse 6
Git Cloning
 Git repositories
 Main repository used is eclipse.platform.releng.aggregator
 Defines other projects as submodules
 Uses two step cloning
 Bare repo
 Regular repo
27 August
2016
Release Engineering at Eclipse 7
Maven Build
 Uses Tycho plugins
 Compile
 Jar signing and Packaging
 App signing
 Windows:
 eclipse.exe is signed
 Mac:
 Uses app layout
 Eclipse.app is signed using apple’s signing service
 SDK packaging
27 August
2016
Release Engineering at Eclipse 8
Build Promotion
 Generate Download page
 Generated and available on build.eclipse.org
 Promote the build to download.eclipse.org
 Uses rsync
 Send email to the platform-releng-dev group
 Trigger Hudson jobs on Shared and Platform HIPPs
This completes master-build.sh
27 August
2016
Release Engineering at Eclipse 9
Testing
 Uses To HIPPs Shared and Platform
 Defined as Hudson jobs
 Triggered by master-build.sh using REST API
 Uses Junit framework
 Completed test results are collected using Hudson jobs
 Update the download page with results
This completes the build cycle
27 August
2016
Release Engineering at Eclipse 10
SWT and Launcher native builds
 Built by SWT team on different platforms
 Uses multiple machines
 Pushes SWT Libraries to eclipse.platform.swt.binaries
 Pushes Launcher libraries and executables to rt.equinox.binaries
 Eclipse SDK build pickups these during packing from respective repositories
27 August
2016
Release Engineering at Eclipse 11
Other builds
 Eclipse Packaged Products
 Examples Eclipse for committers, Eclipse JEE development etc
 Defined in org.eclipse.epp.packages
 Can create user’s own custom package
 Creates packaged products as defined in the org.eclipse.epp.packages
27 August
2016
Release Engineering at Eclipse 12
Release Engineering at Eclipse
Questions
27 August
2016
13
Release Engineering at Eclipse
Thank You
27 August
2016
14
