This document provides specifications for various Carrier freezer models including their dimensions, weights, volumes, compressor types, features, and contact information. It describes key aspects of the freezers such as their durable galvanized steel outer casing with baked-on paint finish, rust-free stucco aluminum inner lining, high-density polyurethane foam insulation, energy efficient R-134a refrigerant, adjustable thermostat, and robust construction making them suitable for commercial use. Contact details are provided for sales offices across India.

1. Climate Controls Security
Carrier Freezers
Process Cooling | Cold Storage | Retail Display Units
Energy Saver
Compressor
60mm Thick Insulation
for long thaw-out time
Galvanized Steel
for Durability
Fast Pull Down

2. HARD TOP FREEZER MODELS GLASS TOP FREEZER MODELS
HF 110 HF150 HF 200 HF 300 HF 400 HF 400DD HF500 HF 500DD GT 300 GT 400
OVERALL UNIT DIMENSIONS
(W x D x H) mm 810x580x530 810x582.5x630 810x722.5x630 810x1012.5x630 810x1302.5x630 810x1552.5x630 810x1552.5x630 810x1552.5x630 820x1013.5x 634.5 820x1303.5x 634.5
GROSS WEIGHT (Kgs.) 47.5 51.5 54.5 65 75 75 89.5 89.5 68 83.5
GROSS VOLUME (Ltrs.) 110 150 200 300 400 400 500 500 300 400
COMPRESSOR MAKE LG/Tecumseh LG/Tecumseh Tecumseh Tecumseh LG/Tecumseh LG/Tecumseh LG/Tecumseh Emerson Emerson Emerson
CABINET ILLUMINATION NA NA NA NA NA NA NA NA NA NA
DOOR HANDLE 1 no. 1 no. 1 no. 1 no. 1 no. 2no. 1 no. 2 no. NA NA
HEAVY DUTY CASTORS /WHEELS Castor (4 no)
LOCK Provided Provided Provided Provided Provided Provided Provided Provided Provided Provided
NUMBER OF DOOR One One One One One Two One Two Sliding Sliding
WIRE SHELVES BASKETS NIL NIL 1 1 2 2 2 2 2 2
THERMOSTAT Provided
OUTER SHELL MATERIAL & FINISH Precoated GI sheet; White
INNER SHEET MATERIAL High Quality Stucco Alumiunium/Precoated GI sheet; White
RATED POWER 185 185 220 220 270 325 325 430 430 430
* All specifications are subject to change w/o prior notice as per the company policy of continues improvements.
For more details please contact the following Carrier sales offices:-
CARRIER REGISTERED OFFICE: Carrier Airconditiong & Refrigeration Ltd., Carrier Complex, Vill. Narsingpur, Kherki Daula Post, Gurgaon–122004,
Haryana; Phone No.: 0124-4825500. CARRIER SALES OFFICES: Gurgaon: 0124-4707333, Ghaziabad: 0120-4183260, Chandigarh: 0172-5007548-
50, Jaipur: 0141-5113444, 5113999, Mumbai: 022-26528989, 26541755, Pune: 020-25468301, 25437741, Goa: 0832-2447028, 2447027, Ahmedabad:
079-40267777, Kolkata: 033-40201300, Chennai: 044-42222888, Bangalore: 080-41114747, Patna: 0612-2323517, Hyderabad: 040-40118106,
40118147-48, Cochin: 0484-4029001, 4029000, Lucknow: 0522-2202346, 2230598, Indore: 0731-4294700, Pondicherry: 0413-2226676, Coimbatore:
0422-4385403, Guwahati: 0361-2595003, Bhubaneshwar: 0674-2587178, 2585893, Nagpur: 0712-6453790, Ranchi: 0651-6452488, 09835373982,
Raipur: 0771-4013245.
www.carrierindia.com
PIONEERING THE COLD CHAIN
Deep Freezer Product Features
Freezer with double door
Freezer with single door hard top
Freezer with sliding glass top
• Compact design with large storage capacity
• Outer casing is galvanized steel with baked-on paint finish for durability.
• Robust construction and elegant looks
• Stucco Aluminum inner line (Rust free & hygienic)
• Higher Capacity System for fast pull down
• High density, environment-friendly, polyurethane foam for better insulation
using high pressure injection machine.
• R-134a Refrigerant, chlorine free, environment consumption
• Energy Saver Compressor – Low energy consumption
• Longer thaw-out time to take care of prolonged periods of power failure
• 60 mm thick insulation
• PVC coated baskets
• Adjustable thermostat
• Skin & Auxiliary Condenser for better performance
