2. Produced by Mapako M 2
Objectives
• Learn about recursive definitions
• Explore the base case and the general case of a
recursive definition
• Learn about recursive algorithm
• Learn about recursive functions
• Explore how to use recursive functions to implement
recursive
3. Data Structures Using C++ 3
Recursive Definitions
• Recursion
– Process of solving a problem by reducing it to smaller
versions of itself
– The recursive algorithm must have one or more base
case(s), and the general solurion must eventually be
reduced to a base case
4. Recursive Definitions (cont’d.)
• Direct solution
– Right side of the equation contains no factorial
notation
• Recursive definition
– A definition in which something is defined in terms of
a smaller version of itself
• Base case
– Case for which the solution is obtained directly
– The case for which the solution can be stated non-
recursively
Data Structures Using C++ 4
5. Recursive Definitions (cont’d.)
• General(Recursive) case
– Case for which the solution is obtained indirectly
using recursion
– Case for which the solution is expressed in terms of
the smaller version of itself
• Recursive algorithm
– A solution that is expressed in terms of smaller
instances of itself and a base case
– Finds problem solution by reducing problem to
smaller versions of itself
Data Structures Using C++ 5
6. Data Structures Using C++ 6
Recursive Definitions (cont’d.)
• Recursion insight gained from factorial problem
– Every recursive definition must have one (or more)
base cases
– General case must eventually reduce to a base case
– Base case stops recursion
• Recursive function
– Function that calls itself
7. Recursive Definitions (cont’d.)
• Recursive function notable comments
– Recursive function has unlimited number of copies of
itself (logically)
– Every call to a recursive function has its own
• Code, set of parameters, local variables
– After completing a particular recursive call
• Control goes back to calling environment (previous call)
• Current (recursive) call must execute completely before
control goes back to the previous call
• Execution in previous call begins from point
immediately following the recursive call
Data Structures Using C++ 7
8. Data Structures Using C++ 8
Recursive Definitions (cont’d.)
• Direct and indirect recursion
– Directly recursive function
• Calls itself
– Indirectly recursive function
• Calls another function, eventually results in original
function call
• Requires same analysis as direct recursion
• Base cases must be identified, appropriate solutions to
them provided
• Tracing can be tedious
– Tail recursive function
• Last statement executed: the recursive call
9. Data Structures Using C++ 9
Recursive Definitions (cont’d.)
• Infinite recursion
– Occurs if every recursive call results in another
recursive call
– Executes forever (in theory)
– Call requirements for recursive functions
• System memory for local variables and formal
parameters
• Saving information for transfer back to right caller
– Finite system memory leads to
• Execution until system runs out of memory
• Abnormal termination of infinite recursive function
10. Data Structures Using C++ 10
Recursive Definitions (cont’d.)
• Requirements to design a recursive function
– Understand problem requirements
– Determine limiting conditions
– Identify base cases, providing direct solution to each
base case
– Identify general cases, providing solution to each
general case in terms of smaller versions of itself
11. Data Structures Using C++ 11
Factorial
• Recursive function implementing the factorial
function
FIGURE 6-1 Execution of factorial
12. Data Structures Using C++ 12
Fibonacci Number
• Sequence: 1, 1, 2, 3, 5, 8, 13, 21, 34 . . .
• Given first two numbers (a1 and a2)
– nth number an, n >= 3, of sequence given by: an = an-1
+ an-2
• Recursive function: rFibNum
– Determines desired Fibonacci number
– Parameters: three numbers representing first two
numbers of the Fibonacci sequence and a number n,
the desired nth Fibonacci number
– Returns the nth Fibonacci number in the sequence
13. Data Structures Using C++ 13
Fibonacci Number (cont’d.)
• Third Fibonacci number
– Sum of first two Fibonacci numbers
• Fourth Fibonacci number in a sequence
– Sum of second and third Fibonacci numbers
• Calculating fourth Fibonacci number
– Add second Fibonacci number and third Fibonacci
number
14. Data Structures Using C++ 14
Fibonacci Number (cont’d.)
• Recursive algorithm
– Calculates nth Fibonacci number
• a denotes first Fibonacci number
• b denotes second Fibonacci number
• n denotes nth Fibonacci number
• a series of numbers in which each number (
Fibonacci number ) is the sum of the two preceding
numbers. The simplest is the series 1, 1, 2, 3, 5, 8,
etc.
15. Data Structures Using C++ 15
Fibonacci Number (cont’d.)
• Recursive function implementing algorithm
• Trace code execution
16. Data Structures Using C++ 16
Fibonacci Number (cont’d.)
FIGURE 6-7 Execution of rFibNum(2, 3, 4)
17. Data Structures Using C++ 17
Tower of Hanoi
• Object
– Move 64 disks from first needle to third needle
• Rules
– Only one disk can be moved at a time
– Removed disk must be placed on one of the needles
– A larger disk cannot be placed on top of a smaller disk
FIGURE 6-8 Tower of Hanoi problem with three disks
18. Data Structures Using C++ 18
Tower of Hanoi (cont’d.)
• Case: first needle contains only one disk
– Move disk directly from needle 1 to needle 3
• Case: first needle contains only two disks
– Move first disk from needle 1 to needle 2
– Move second disk from needle 1 to needle 3
– Move first disk from needle 2 to needle 3
• Case: first needle contains three disks
19. Data Structures Using C++ 19
Tower of Hanoi (cont’d.)
FIGURE 6-9 Solution to Tower of Hanoi problem with three disks
20. Data Structures Using C++ 20
Tower of Hanoi (cont’d.)
• Generalize problem to the case of 64 disks
– Recursive algorithm in pseudocode
21. Data Structures Using C++ 21
Tower of Hanoi (cont’d.)
• Generalize problem to the case of 64 disks
– Recursive algorithm in C++
22. Data Structures Using C++ 22
Tower of Hanoi (cont’d.)
• Analysis of Tower of Hanoi
– Time necessary to move all 64 disks from needle 1 to
needle 3
– Manually: roughly 5 x 1011 years
• Universe is about 15 billion years old (1.5 x 1010)
– Computer: 500 years
• To generate 264 moves at the rate of 1 billion moves per
second
23. Data Structures Using C++ 23
Converting a Number from Decimal to
Binary
• Convert nonnegative integer in decimal format (base
10) into equivalent binary number (base 2)
• Rightmost bit of x
– Remainder of x after division by two
• Recursive algorithm pseudocode
– Binary(num) denotes binary representation of num
24. Data Structures Using C++ 24
Converting a Number from Decimal to
Binary (cont’d.)
• Recursive function implementing algorithm
25. Data Structures Using C++ 25
Converting a Number from Decimal to
Binary (cont’d.)
FIGURE 6-10 Execution of decToBin(13, 2)
26. Multiply 2 numbers by addition
int multiply (int a,int b)
{
if(b==0)//base case for recursion to stop
return 0;
else return a + multiply(a,b-1);//recursive case }
Data Structures Using C++ 26
• Recursive function implementing algorithm
27. Computing powers via linear recursion
int calculatePower(int base, int powerRaised)
{ if (powerRaised != 1)
return (base*calculatePower(base,
powerRaised-1));
else return 1;
}
Data Structures Using C++
27
28. Reversing an array
• Algorithm ReverseArray(A, i, j):
Input: An array A and nonnegative integer indices
i and j
Output: The reversal of the elements in A starting
at index i and ending at j
if i < j then
Swap A[i] and A[j]
ReverseArray(A, i+1, j-1)
return
Data Structures Using C++ 28
29. Data Structures Using C++ 29
Recursion or Iteration?
• Dependent upon nature of the solution and efficiency
• Efficiency
– Recursion is less efficient in terms of time and space
– Overhead of recursive function: execution time and memory
usage
• Given speed memory of today’s computers, we can depend
more on how programmer envisions solution
– Use of programmer’s time
– Any program that can be written recursively can also be written
iteratively
– Recursion is simpler and more natural for programmer to write
30. Advantages of recursion
• Recursion is a must to use in some programming
situations like display a list of files of the system
cannot be solved without recursion
• Recursion is very flexible in data structures like
stacks, queues, linked list and quick sort
• Using recursion the length of the program can be
reduced.
• It makes the code easier to read as it reflex our
normal manner of thinking
• It makes a function or a procedure easier to
understand
Data Structures Using C++ 30
31. Disadvantages of recursion
• May be slower than iteration
• Use greater resources because of extra function
calls
• More difficult to understand in some algorithms. An
algorithm that can be naturally expressed iteratively
may not be easy to understand if expressed
recursively.
• There is no portable way to tell how deep recursion
can go without causing trouble( how much ‘stack
space’ the machine has) and there is no way to
recover from deep recursion( a stack overflow)
Data Structures Using C++ 31
32. Data Structures Using C++ 32
Summary
• Recursion
– Solve problem by reducing it to smaller versions of
itself
• Recursive algorithms implemented using recursive
functions
– Direct, indirect, and infinite recursion
• Many problems solved using recursive algorithms
• Choosing between recursion and iteration
– Nature of solution; efficiency requirements
• Backtracking
– Problem solving; iterative design technique
