Reactive programming with rx java

Functional Reactive
Programming with
RxJava
Nguyen Cong Trung and Nguyen Hai Long
Software Engineer at SeeSpace

Overview
1. Introduction to Reactive Programming.
2. Why should use Reactive Programming.
3. RxJava.
4. RxAndroid
5. Unit testing RxJava.
6. References.
7. Demo.

1. Introduction to
Reactive Programming.
1.1. Side Effect.
1.2. Reactive Programming.

1.1. Side Effect.
• In computer science, a function or expression is said to have
a side effect if, in addition to returning a value, it also
modifies some state or has an observable interaction with
calling functions or the outside world.
• For example, a particular function might modify a global
variable or static variable, modify one of its arguments, raise
an exception, write data to a display or file, read data, or call
other side-effecting functions.

1.2. Reactive
Programming.
• Reactive programming is programming with asynchronous data streams.
• Event buses or typical click events are really an asynchronous event stream, on which
you can observe and do some side effects.
• Reactive is that idea on steroids. You are able to create data streams of anything, not
just from click and hover events.
• It has many functions to combine, create and filter any of those streams.
• A stream can be used as an input to another one. Even multiple streams can be used
as inputs to another stream.
• You can merge two streams. You can filter a stream to get another one that has only
those events you are interested in. You can map data values from one stream to
another new one.

• Each stream has many functions attached to it, such as map, filter, scan, etc. When
you call one of these functions, such as clickStream.map(f), it returns a new stream
based on the click stream. It does not modify the original click stream in any way. This
is a property called immutability.

2. Why should use
Reactive Programming.
2.1. Problems of Java Futures.
2.2. Problems of Callbacks.
2.3. Reactive.

2.1. Problems of Java
Futures.

• Java Futures are straight-forward to use for a
single level of asynchronous execution but they
start to add non-trivial complexity when they're
nested.
• Conditional asynchronous execution flows
become difficult to optimally compose (particularly
as latencies of each request vary at runtime) using
Futures. It can be done of course, but it quickly
becomes complicated (and thus error prone) or
prematurely blocks on 'Future.get()', eliminating
the benefit of asynchronous execution.
Link to demo.

2.2. Problems of
Callbacks.
• Callbacks offer a solution to the tendency to block
on Future.get() by not allowing anything to block.
They are naturally efficient because they execute
when the response is ready.
• Similar to Futures though, they are easy to use
with a single level of asynchronous execution but
become unwieldy with nested composition.
Link to demo.

2.3. Reactive.
• Reactive programming offers efficient execution and
composition by providing a collection of operators
capable of filtering, selecting, transforming, combining
and composing Observable's.
• The Observable data type can be thought of as a
"push" equivalent to Iterable which is "pull". With an
Iterable, the consumer pulls values from the producer
and the thread blocks until those values arrive. By
contrast with the Observable type, the producer
pushes values to the consumer whenever values are
available. This approach is more flexible, because
values can arrive synchronously or asynchronously.

• The following code demonstrates how a service layer method can choose
whether to synchronously return data from an in-memory cache or
asynchronously retrieve data from a remote service and callback with the
data once retrieved. In both cases the client code consumes it the same
way.

• The following code demonstrates the consumption of an Observable API.

• That code is declarative and lazy as well as functionally "pure" in that no
mutation of state is occurring that would cause thread-safety issues.
• The API Service Layer is now free to change the behavior of the methods
'getListOfLists', 'getVideos', 'getMetadata', 'getBookmark' and 'getRating' –
some blocking others non-blocking but all consumed the same way.
• In the example, 'getListOfLists' pushes each 'VideoList' object via 'onNext()'
and then 'getVideos()' operates on that same parent thread. The
implementation of that method could however change from blocking to non-
blocking and the code would not need to change.

3. RxJava.
3.1. The Basics.
3.2. Hello, World!
3.3. Introducing Transformation and Operators.
3.4. More on Operators.
3.5. Error Handling.
3.6. Schedulers.

3.7. Subscriptions.
3.8. Backpressure.
3.9. Subject.

3.1. The Basics.
• The basic building blocks of reactive code are Observables and
Subscribers. An Observable emits items; a Subscriber
consumes those items.
• There is a pattern to how items are emitted. An Observable
may emit any number of items (including zero items), then it
terminates either by successfully completing, or due to an error.
• For each Subscriber it has, an Observable calls
Subscriber.onNext() any number of times, followed by either
Subscriber.onComplete() or Subscriber.onError().
• This looks a lot like your standard observer pattern, but it differs
in one key way - Observables often don't start emitting items
until someone explicitly subscribes to them.

3.2. Hello, World!
First, let's create a basic Observable:

Our Observable emits "Hello, world!" then completes. Now let's
create a Subscriber to consume the data:

Now that we've got myObservable and mySubscriber we can
hook them up to each other using subscribe():

RxJava has multiple built-in Observable creation methods for
common tasks. In this case, Observable.just() emits a single item then
completes, just like our code above:
Next, let's handle that unnecessarily verbose Subscriber. We don't
care about onCompleted() nor onError(), so instead we can use a
simpler class to define what to do during onNext():

Actions can define each part of a Subscriber. Observable.subscribe() can
handle one, two or three Action parameters that take the place of onNext(),
onError(), and onComplete(). Replicating our Subscriber from before looks like
this:
However, we only need the first parameter, because we're ignoring onError()
and onComplete():

Now, let's get rid of those variables by just chaining the method calls together:
Finally, let's use Java 8 lambdas to get rid of that ugly Action1 code.

3.3. Introducing Transformation
and Operators.
Suppose I want to append my signature to the "Hello, world!" output. One
possibility would be to change the Observable:
This works if you have control over your Observable, but there's no guarantee
that will be the case - what if you're using someone else's library? Another
potential problem: what if I use my Observable in multiple places but only
sometimes want to add the signature?

and Operators.
How about we try modifying our Subscriber instead:
This answer is also unsatisfactory, but for different reasons: I want my
Subscribers to be as lightweight as possible because I might be running them
on the main thread. On a more conceptual level, Subscribers are supposed to
be the thing that reacts, not the thing that mutates.
Wouldn't it be cool if I could transform "Hello, world!" with some intermediary
step?

and Operators.
Operators can be used in between the source Observable and the ultimate
Subscriber to manipulate emitted items. RxJava comes with a huge collection
of operators, but its best to focus on just a handful at first.
For this situation, the map() operator can be used to transform one emitted item
into another:

and Operators.
map() does not have to emit items of the same type as the source Observable.
Suppose my Subscriber is not interested in outputting the original text, but
instead wants to output the hash of the text:

and Operators.
Again, we can use lambdas to shorten this code:

and Operators.

Suppose I have this method available:

I want to make a robust system for searching text and displaying the
results. Given what we know from the last article, this is what one
might come up with:

This answer is highly unsatisfactory because I lose the ability to
transform the data stream. If I wanted to modify each URL, I'd have to
do it all in the Subscriber. We're tossing all our cool map() tricks out
the window!
I could create a map() from urls -> urls, but then every map() call
would have a for-each loop inside of it.

There is a method, Observable.from(), that takes a collection of items
and emits each them one at a time:
That looks like it could help, let's see what happens:

I've gotten rid of the for-each loop, but the resulting code is a mess.
I've got multiple, nested subscriptions now! Besides being ugly and
hard to modify, it also breaks some critical as-yet undiscovered
features of RxJava. The way RxJava does error handling, threading,
and subscription cancellation wouldn't work at all with this code.

Observable.flatMap() takes the emissions of one Observable and
returns the emissions of another Observable to take its place. Here's
how it solves this problem:

Simplified with lambdas it looks awesome:

flatMap() can return any Observable it wants. Suppose I've got a
second method available:
Instead of printing the URLs, now I want to print the title of each
website received. But there's a few issues: my method only works on a
single URL at a time, and it doesn't return a String, it returns an
Observable that emits the String.

With flatMap(), solving this problem is easy; after splitting the list of
URLs into individual items, I can use getTitle() in flatMap() for each url
before it reaches the Subscriber:

And once more, simplified via lambdas:

We've only looked at two operators so far, but there are so many
more! How else can we improve our code?
getTitle() returns null if the URL 404s. We don't want to output "null"; it
turns out we can filter them out!

filter() emits the same item it received, but only if it passes the boolean
check.
And now we want to only show 5 results at most:

take() emits, at most, the number of items specified. (If there are fewer
than 5 titles it'll just stop early.)
Now we want to save each title to disk along the way:

doOnNext() allows us to add extra behavior each time an item is
emitted, in this case saving the title.
Link to other Operators.

Up until this point, we've largely been ignoring onComplete() and
onError(). They mark when an Observable is going to stop emitting
items and the reason for why (either a successful completion, or an
unrecoverable error).
Our original Subscriber had the capability to listen to onComplete()
and onError(). Let's actually do something with them:

• onError() is called if an Exception is thrown at any
time.
• The operators don't have to handle the Exception.
• You know when the Subscriber has finished
receiving items.

3.6. Schedulers.
• You've got an Android app that makes a network
request. That could take a long time, so you load it
in another thread. Suddenly, you've got problems!
• Multi-threaded Android applications are difficult
because you have to make sure to run the right
code on the right thread; mess up and your app
can crash. The classic exception occurs when you
try to modify a View off of the main thread.

3.6. Schedulers.
• In RxJava, you can tell your Observer code which thread to run on
using subscribeOn(), and which thread your Subscriber should run
on using observeOn():

3.6. Schedulers.
• Everything that runs before my Subscriber runs on an I/O thread.
Then in the end, my View manipulation happens on the main
thread.
• The great part about this is that I can attach subscribeOn() and
observeOn() to any Observable! They're just operators! I don't have
to worry about what the Observable or its previous operators are
doing; I can just stick this at the end for easy threading.

3.6. Schedulers.
You obtain a Scheduler from the factory methods described in the
Schedulers class.
• Schedulers.computation( ): meant for computational work such as
event-loops and callback processing; do not use this scheduler for
I/O (use Schedulers.io( ) instead); the number of threads, by
default, is equal to the number of processors.
• Schedulers.from(executor): uses the specified Executor as a
Scheduler.
• Schedulers.immediate( ): schedules work to begin immediately in
the current thread.

3.6. Schedulers.
• Schedulers.io( ): meant for I/O-bound work such as asynchronous
performance of blocking I/O, this scheduler is backed by a thread-
pool that will grow as needed; for ordinary computational work,
switch to Schedulers.computation( ); Schedulers.io( ) by default is a
CachedThreadScheduler, which is something like a new thread
scheduler with thread caching.
• Schedulers.newThread( ): creates a new thread for each unit of
work.
• Schedulers.trampoline( ): queues work to begin on the current
thread after any already-queued work

3.7. Subscriptions.
• When you call Observable.subscribe(), it returns a Subscription.
This represents the link between your Observable and your
Subscriber:

3.7. Subscriptions.
• You can use this Subscription to sever the link later on:
• What's nice about how RxJava handles unsubscribing is that it
stops the chain. If you've got a complex chain of operators, using
unsubscribe will terminate wherever it is currently executing code3.
No unnecessary work needs to be done!

3.8. Backpressure.
• In RxJava it is not difficult to get into a situation in which an
Observable is emitting items more rapidly than an operator or
subscriber can consume them. This presents the problem of what
to do with such a growing backlog of unconsumed items.
• The examples in this section will show how you might use such
operators to handle a bursty Observable like the one illustrated in
the following marble diagram:
• By fine-tuning the parameters to these operators you can ensure
that a slow-consuming observer is not overwhelmed by a fast-
producing Observable.

3.8. Backpressure.
3.8.1. Throttling.
3.8.2. Buffers and windows.

3.8.1. Throttling.
• Operators like sample( ) or throttleLast( ), throttleFirst( ), and
throttleWithTimeout( ) or debounce( ) allow you to regulate the rate
at which an Observable emits items.

3.8.1. Throttling.
Sample (or throttleLast):
The sample operator periodically "dips" into the sequence and emits
only the most recently emitted item during each dip:

3.8.1. Throttling.
throttleFirst
The throttleFirst operator is similar, but emits not the most recently
emitted item, but the first item that was emitted after the previous "dip":

3.8.1. Throttling.
debounce (or throttleWithTimeout)
The debounce operator emits only those items from the source
Observable that are not followed by another item within a specified
duration:

3.8.2. Buffers and
windows.
You can also use an operator like buffer( ) or
window( ) to collect items from the over-producing
Observable and then emit them, less-frequently, as
collections (or Observables) of items. The slow
consumer can then decide whether to process only
one particular item from each collection, to process
some combination of those items, or to schedule
work to be done on each item in the collection, as
appropriate.

3.8.2. Buffers and
windows.
buffer
You could, for example, close and emit a buffer of items from the
bursty Observable periodically, at a regular interval of time:

3.8.2. Buffers and
windows.
window
window is similar to buffer. One variant of window allows you to
periodically emit Observable windows of items at a regular interval of
time:

3.8.2. Buffers and
windows.
You could also choose to emit a new window each time you have
collected a particular number of items from the source Observable:

3.9. Subject.
3.9.1. The basics.
3.9.2. AsyncSubject.
3.9.3. BehaviorSubject.
3.9.4. PublishSubject.
3.9.5. ReplaySubject.
3.9.6. SerializedSubject.

3.9.1. The basics.
A Subject is a sort of bridge or proxy that acts both as an Subscriber
and as an Observable.
In this very basic example, I create a subject, subscribe to that subject
and then publish values to the sequence (by calling
subject.OnNext(T)).
If you have a Subject and you want to pass it along to some other
agent without exposing its Subscriber interface, you can mask it by
calling its asObservable method, which will return the Subject as a
pure Observable.

3.9.2. AsyncSubject.
Subject that publishes only the last item observed to each Observer
that has subscribed, when the source Observable completes.

Subject that emits the most recent item it has observed and all
subsequent observed items to each subscribed Observer.

Example usage:

Subject that, once an Observer has subscribed, emits all subsequently
observed items to the subscriber.

Example usage:

Subject that buffers all items it observes and replays them to any
Observer that subscribes.

Example usage:

3.9.6.
SerializedSubject.
Wraps a Subject so that it is safe to call its various on methods from
different threads.
When you use an ordinary Subject as a Subscriber, you must take
care not to call its Observer.onNext(T) method (or its other on
methods) from multiple threads, as this could lead to non-serialized
calls, which violates the Observable contract and creates an ambiguity
in the resulting Subject.
To protect a Subject from this danger, you can convert it into a
SerializedSubject with code like the following:

4. RxAndroid.
4.1. Overview.
4.2. Retrofit.
4.3. Migrate old code to Observable.
4.4. Lifecycle.

4.1. Overview.
RxAndroid is an extension to RxJava built just for Android. It includes
special bindings that will make your life easier.
First, there's AndroidSchedulers which provides schedulers ready-
made for Android's threading system. Need to run some code on the
UI thread? No problem - just use AndroidSchedulers.mainThread():

4.1. Overview.
If you've got your own Handler, you can create a scheduler linked to it
with HandlerThreadScheduler.
Next we have AndroidObservable which provides more facilities for
working within the Android lifecycle. There is bindActivity() and
bindFragment() which, in addition to automatically using
AndroidSchedulers.mainThread() for observing, will also stop emitting
items when your Activity or Fragment is finishing (so you don't
accidentally try to change state after it is valid to do so).

4.1. Overview.
I also like AndroidObservable.fromBroadcast(), which allows you to
create an Observable that works like a BroadcastReceiver. Here's a
way to be notified whenever network connectivity changes:

4.1. Overview.
Finally, there is ViewObservable, which adds a couple bindings for
Views. There's ViewObservable.clicks() if you want to get an event
each time a View is clicked, or ViewObservable.text() to observe
whenever a TextView changes its content.

4.2. Retrofit.
There's one notable library that supports RxJava: Retrofit, a popular
REST client for Android. Normally when you define an asynchronous
method you add a Callback:
With RxJava installed, you can have it return an Observable instead:

4.2. Retrofit.
Retrofit support for Observable also makes it easy to combine multiple
REST calls together. For example, suppose we have one call that gets
the photo and a second that gets the metadata. We can zip the results
together:

4.3. Migrate old code to
Observable.
Observable.just() and Observable.from() are suffice for creating an
Observable from older code most of the time:
That works well if oldMethod() is fast, but what if it's slow? It'll block the
thread because you're calling oldMethod() before passing it to
Observable.just().

4.3. Migrate old code to
Observable.
To get around that problem, here's a trick I use all the time - wrapping
the slower part with defer():
Now, the Observable returned won't call slowBlockingMethod() until
you subscribe to it.

4.4. Lifecycle.
How do you handle the Activity lifecycle? There are two issues that
crop up over and over again:
1. Continuing a Subscription during a configuration change (e.g.
rotation). Suppose you make REST call with Retrofit and then want
to display the outcome in a ListView. What if the user rotates the
screen? You want to continue the same request, but how?
2. Memory leaks caused by Observables which retain a copy of the
Context. This problem is caused by creating a subscription that
retains the Context somehow, which is not difficult when you're
interacting with Views! If Observable doesn't complete on time, you
may end up retaining a lot of extra memory.

4.4. Lifecycle.
The first problem can be solved with some of RxJava's built-in caching
mechanisms, so that you can unsubscribe/resubscribe to the same
Observable without it duplicating its work. In particular, cache() (or
replay()) will continue the underlying request (even if you
unsubscribe). That means you can resume with a new subscription
after Activity recreation:

4.4. Lifecycle.
Note that we're using the same cached request in both cases; that way
the underlying call only happens once. Where you store request I
leave up to you, but like all lifecycle solutions, it must be stored
somewhere outside the lifecycle (a retained fragment, a singleton,
etc).

4.4. Lifecycle.
The second problem can be solved by properly unsubscribing from
your subscriptions in accordance with the lifecycle. It's a common
pattern to use a CompositeSubscription to hold all of your
Subscriptions, and then unsubscribe all at once in onDestroy() or
onDestroyView():

4.4. Lifecycle.
For bonus points you can create a root Activity/Fragment that comes
with a CompositeSubscription that you can add to and is later
automatically unsubscribed.
A warning! Once you call CompositeSubscription.unsubscribe() the
object is unusable, as it will automatically unsubscribe anything you
add to it afterwards! You must create a new CompositeSubscription as
a replacement if you plan on re-using this pattern later.

The ugly way
The first way is to simply subscribe in the same way we would from
outside the tests and then save the result in a global variable that can
later on be asserted.
For example, imagine we have a method in a database helper class
that is in charge of loading a user object.

Then the test for this method would look like this:

This code works because, by default, the Observable will run on the
same thread. Therefore, the assertion will always happen after the
result is set in the global variable.

The better way
Use static methods of a class called RxAssertions written by Software
Engineers at ribot.

The official way
Use TestSubscriber provided by RxJava.
Chaining assertions is not possible, because the assert methods don’t
return the TestSubscriber.

6. References.
• Side effect (computer science) – Wikipedia.
• Referential transparency (computer science) – Wikipedia.
• The introduction to Reactive Programming you've been missing by André Staltz.
• Reactive Programming in the Netflix API with RxJava by Ben Christensen and Jafar Husain.
• Grokking RxJava by Dan Lew.
• Unit Testing RxJava Observables by Iván Carballo.
• Learning RxJava for Android by example by Kaushik Gopal.
• ReactiveX IO.
• Official RxJava’s Wiki.

Reactive programming with rx java

Recommended

Recommended

More Related Content

What's hot

What's hot (20)

Viewers also liked

Viewers also liked (14)

Similar to Reactive programming with rx java

Similar to Reactive programming with rx java (20)

Recently uploaded

Recently uploaded (20)

Reactive programming with rx java
