This document describes a programmable large size shaking incubator. It has a temperature range of 10-60°C, speeds of 10-350 RPM, and programmable temperature and timer functions. The incubator uses a brushless DC motor and PID controller to precisely control shaking and temperature for growing bacteria, yeast, and other cells.

1. PROGRAMMABLE LARGE SIZE
SHAKING INCUBATOR
MODEL NO. ACM-I03422-04S
R

2. TECHNOLOGIES PVT. LTD.
Weiber Programmable Large Size Shaking Incubator is suited for the growth of bacteria, yeast, and insect
and plant cells in a temperature-controlled environment. This programmable shaking incubator offers safety
features for reliable shaking of lab glassware with programmable temperature and agitation timers.
The Programmable large size shaking incubator is equipped with microprocessor based P.I.D controller with
brushless DC motor producing less noise. This brushless induction drive motors are maintenance-free and quiet
even at high speeds. It offers wide temperature range with speed of 10 RPM with programmable temperature
and agitation timers.
PROGRAMMABLE LARGE SIZE
SHAKING INCUBATOR
R

3. TECHNOLOGIES PVT. LTD.
TECHNICAL SPECIFICATIONS
R
SALIENT FEATURES
Ÿ Digital display for temperature and speed
Ÿ Unique retractable platform for easy loading and unloading
Ÿ Variable plate of flask available
Ÿ Small Table size design
Ÿ Easy to use
Ÿ Brushless DC motor
Ÿ 10RPM slow speed Support
Ÿ Timer
Ÿ Digital PID controller
Ÿ Betless Drum Mechanism
Ÿ Safety Features
Ÿ Variable flask & Tube Support
Ÿ Light Bank
Ÿ 4 step speed program
Ÿ 10 step Speed program
Temperature range 10°C to 60°C
Display LED display
Speed range 10 – 350 RPM
Temperature controller Digital P.I.D controller
Circulation Fan 90mm convection fan
Motor Brushless DC motor
Power 220V, 6A, 1.2 kW, 60 Hz
Safety Device Over temperature Protector, Door Detector
Timer 99 Hr & Hold for long run
Standard plate 250ml X 40EA
Certification ISO certified
Programmability 4 Speed Step/ 10 Temp. Program
Drive system Beltless direct drive
Working mode Normal, Step, Frequently, Delay start
Lid Silicone Packaging & Shock absorber
Weight 137. 5 kg
