2. Introduction to lasers in NDT
Lasers can be used to generate and measure ultrasonic waves in
materials.
Laser based NDT methods came to acceptance with an increase
in the use of composite materials and sandwich structures in
industries.
These types of structures required high speed and large area
inspection for subsurface defects.
15-07-2022 2
3. Introduction to lasers in NDT(cont’d)
That is like disbonds , delaminations , sheared core,
invisible damage in aircraft, missiles and marine
composites.
There are 3 main laser testing methods in NDT.
Holography, shearography and profilometry testing all of
which make use of lasers to conduct testing.
1. Holography laser testing method
2. Laser shearography testing method
3. Laser profilometer testing methods
15-07-2022 3
4. Holography laser testing method
Holography testing methods use high frequency
vibration to identify irregular internal structure or
disbonds.
This non-destructive testing method is used for the real
time inspection of complex components like aero engine
turbine blades, felt metal engine seals, plasma coated
artificial hip and knee joints.
15-07-2022 4
6. Laser shearography testing method
This method utilizes an interferometer to identify the out
of plane derivative of deformation of the testing material
due to the non homogenous strain field due to subsurface
flaws.
Out-of-plane stress is created by applying vacuum,
vibration or thermal stress effects to the weakest bond of
laminar structure.
Shearography testing can identify changes in strains to 0.1
micro strain at video frame rates.
15-07-2022 6
8. Laser profilometer testing method
Laser profilometer testing methods are largely preferred for
cylindrical products.
The major use is found in pipeline inspections for assessing
highly corroded defects.
The principle behind the working of laser profilometry
testing is based on image processing of laser beam when it is
bent by the test object profile.
Using the profilometer method crucial information regarding
repair and operability can be assessed efficiently with an
accuracy of 0.03mm and with a resolution of 0.05mm.
15-07-2022 8
10. ULTRASONIC FLAW DETECTION
Ultrasonic flaw detection method or ultrasonic testing
(UT) is an effective NDT method applicable to most
materials.
It is a method to detect surface and internal
discontinuities such as laps , seams , voids , cracks ,
blow holes , inclusions and lack of bond.
UT uses high frequency sound energy to detect surface
and internal discontinuities.
UT is completely a safe method and widely used due to
its high penetrating capacity and inspection of extremely
thick sections. 15-07-2022 10
11. Ultrasonic waves
Sound waves having frequency above 20 khz .
Usual frequency for NDT are in the range of 0.5 to 10
MHz
The selection of actual frequency depends on
1. roughness of the surface
2.grain size of the material.
3.Dimensions of the flaw.
15-07-2022 11
12. Working Principle of ultrasonic testing
A typical ultrasonic system consists of several functional units
such as the pulse receiver, transducer and display devices.
A pulser/receiver can produce high voltage ultrasonic energy.
Driven by the pulser, the transducer generates high frequency
energy.
The sound energy is introduced and propagates through the
materials in the form of waves.
When there is a discontinuity in wave path part of energy will
be reflected back from surface.
15-07-2022 12
13. Working principle (cont’d)
The reflected wave signal is transformed into electrical
signal by the transducer and it is displayed on a screen.
Signal travel time can be directly related to the distance
that the signal travelled.
From the signal, information about the reflector flaw
location,size and orientation and other features can be
obtained.
15-07-2022 13
15. Transmission method
The flaw can be identified on quantifying the received
sound waves.
It consists of two transducers placed on opposite sides.
One is to transmit the sound wave and other is to receive
them.
Discontinuities provide some obstruction to sound
waves.
So it results in partial or total loss in transmitted sound
waves.
The decrease in the received signal amplitude indicates
the presence of defects in test specimen. 15-07-2022 15
17. Procedure followed in transmission method
Two transducers are placed opposite to each other on
the surface of the test specimen .
One is to transmit sound waves and other is to
receive them.
The result can be seen through CRT screen display.
The specimen without defect has no loss in
transmitted sound waves and the graph will be nearly
equal as shown in fig
The specimen with defect has loss in transmitted
sound waves so it will reflect in the graph by short
pulse as shown in fig
15-07-2022 17
18. Pulse - echo method
Here only one transducer is used.
This transducer acts as both transmitter and receiver.
It sends out a pulse of energy and the same receives it.
The transmitted sound wave reflects due to the presence
of discontinuities at the surface of the test specimen.
The amount of reflected wave is displayed with respect
to time .
Which provides the information about the size and the
location of features that reflect the sound.
15-07-2022 18
20. Procedure followed in pulse echo method
A test specimen is placed to conduct ultrasonic testing.
A pulse generator is used to generate pulse of required frequency.
The generated pulse is transmitted through transducer.
The reflected wave is received by the same transducer which has
receiver unit with it.
The received pulse is amplified by using an amplifier.
Then the both transmitted and received pulse is compared in CRO
display unit.
By plotting these against time, we can find the location of the
defects. 15-07-2022 20
21. Advantages of ultrasonic testing
Sensitive to both surface and subsurface discontinuities.
Small discontinuities can be detected.
Large size specimen can be inspected in short duration.
Ver cheap & has high speed of operation.
Minimal part preparation is required.
Inspection can be done from one surface of the object.
High sensitive and greater accuracy.
Electronic equipments provide instant results.
15-07-2022 21
22. Limitations of ultrasonic testing
Surface must be accessible and smooth.
Complex geometries are difficult to inspect.
Not suitable for coarse grained surfaces.
Skilled operator is required
Linear defects oriented parallel to the sound beam may
go undetected.
15-07-2022 22
23. Applications of ultrasonic testing
Testing ferrous and non ferrous pipes, rods and bars.
Detecting corrosion in various petroleum and gas pipe lines.
Erosion and corrosion thickness gauging.
Testing welds in pressure vessels, pipes, structures ,bridges
,aircraft, marines etc.
Fatigue detection in welds and boilers.
Inspecting large castings, forgings rails and rolled steel sections.
Estimation of void content in composites and plastics.
Detecting stages, blow holes, inclusions porosity and grain size.
15-07-2022 23
24. REFERENCE TEXTBOOKS
Non destructive testing : Dr . A . Anderson , Dr . S Ramachandran.
Non destructive testing techniques : Ravi Prakash
Non destructive testing and evaluation of materaials : J Prasad
15-07-2022 24
