1. PARALLEL AND DISTRIBUTED COMPUTING
MESSAGE PASSING INTERFACE (MPI)

2. MPI INTRODUCTION
 The first difference is in the price of communication, time
needed to exchange certain amount of data between
processors
 MPI is a standardized means of exchanging messages between
multiple computers running a parallel program across
distributed memory

3. MPI (MESSAGE PASSING INTERFACE)
 MPI is not a language but all MPI operations are expressed as
functions or subroutines
 MPI Standard defines the syntax and semantics of operations
 MPI Program consists of autonomous process that are able to
execute their own code in the sense of MIMD

4. MPI (MESSAGE PASSING INTERFACE)
 MPI provides at least two operations
 send(message) and receive(message)
Message sent by a process can be of either fixed or variable size
Fixed Size: system level implementation is straightforward but make
the task of programming more difficult
Variable size: system level implementation is difficult but makes task
programming more simpler.

5. MPI (MESSAGE PASSING INTERFACE)
 If process P and Q want to communicate, they send messages
to and receive messages from each other
 So we need a communication link between them

6. HELLO WORD
#include <stdio.h>
#include <mpi.h>
main(int argc, char **argv)
{
MPI_Init(&argc, &argv);
printf("Hello worldn");
MPI_Finalize();
}

7.  Header file mpi.h must be included to compile MPI Code.
 MPI-Init() from this point processes can collaborate,
send/receive message until MPI-Finalize()
 finalizing leads to freeing all the resources reserved by MPI.

8. BASIC DATA TYPES RECOGNIZED BY MPI
MPI DATATYPE HANDLE C DATATYPE
MPI_INT Int
MPI_SHORT Short
MPI_LONG Long
MPI_FLOAT Float
MPI_DOUBLE Double
MPI_CHAR Char

9.  MPI also provides routines that let the process determine its
process ID, as well as the number of processes that have been
created.

11.  MPI_Comm_size(): returns total number of processes
 MPI_Comm_rank(): returns process id that called the
function
MPI rank us used to specify a particular process
 It is an integer range from 0 to n
 It is necessary for a process to know it rank.

12. MPI COMMUNICATOR
 A process group and context together form an MPI
Communicator
 MPI Communicator – holds a group of processes that can
communicate with each other.
 MPI_COMM_WORLD is default communicator that contains
all processes available for use.

13. SEND AND RECEIVE MPI
 Process A decides to sent message to process B. Process A pack
up all information into buffer and sent. Process A acknowledged
that data has transmitted

14. SYNTAX OF SEND OPERATION
MPI_SEND (buf, count, datatype, dest, tag,
comm)
MPI_SEND will not complete until a matching MPI-RECV
Identified
 Buf - pointer to send buffer, data to send
 Count - number of data item (non negative)
 Datatype - type of data
 Dest - receiver address
 Tag - message tag

15. SYNTAX OF RECEIVE OPERATION
 MPI_RECV (buf, count, datatype, dest, tag, comm, status)
MPI_SEND will not complete until a matching MPI-RECV Identified
 Buf - pointer to send buffer, data to send
 Count - number of data item (non negative)
 Datatype - type of data
 Dest - receiver address
 Tag - message tag
 Comm- communicator (handle)
 Status – contains furter information about

16. MPI PROGRAM: PROCESS 1TO SEND MESSAGETO PROCESS 2
 int main(int argc, char** argv) {
 int process_Rank, size_Of_Cluster, message_Item;
 MPI_Init(&argc, &argv);
 MPI_Comm_size(MPI_COMM_WORLD, &size_Of_Cluster);
 MPI_Comm_rank(MPI_COMM_WORLD, &process_Rank);
 if(process_Rank == 0){
 message_Item = 42;
 MPI_Send(&message_Item, 1, MPI_INT, 1, 1, MPI_COMM_WORLD);
 printf("Message Sent: %dn", message_Item); }
 else if(process_Rank == 1){
 MPI_Recv(&message_Item, 1, MPI_INT, 0, 1, MPI_COMM_WORLD, MPI_STATUS_IGNORE);
 printf("Message Received: %dn", message_Item); }
 MPI_Finalize(); }

17. COLLECTIVE MPI COMMUNICATION
 MPI Collective operations are called by all processes in a
communicator
 Following are some collective MPI Collective Operations
 MPI_BARRIER
 MPI_BCAST
 MPI_SCATTER
 MPI_GATHER

18. MPI BARRIERS
 Like many other programming utilities, MPI-Barrier is a process
lock that holds each process at a certain line of code until all
processes have reach that line in code.
 MPI_Barrier can be called as such:
 MPI_Barrier(MPI_Comm comm)

19. MPI_BCAST
 Implements a one-to-all broadcast operation
 Root process sends its data to all other processes
 MPI_BCAST(inbuf, incnt, intype, root, comm)
 Inbuf: consisting of input data
 Incnt: count number of data
 Intype: type of data

20. MPI_GATHER
 All-to-one operator, also called by all process in the
communicator.
 Gather data from participating processes into a single structure

21. MPI_SCATTER
 Break a structure into portions and distribute those portions
to other processes
 Inverse of MPI_Gather
 Data is scattered to other processes into equal parts

22. COLLECTIVE MPI DATA MANIPULATIONS
 MPI Provides a set of operations that performs simple
manipulations on the transferred data
 Manipulation are based on data reduction paradigm that reduce
data into smaller set of data.

23. COLLECTIVE MPI DATA MANIPULATIONS
 MPI_Max, MPI_Min: return maximum or minimum of data item
 MPI_Sum, MPI_Prod: Return sum or product of all data items
 MPI_LAND, MPI_LOR, MPI_BAND, MPI_BOR: return logical or
bitwise operation across data.

24. MPI REDUCTION
 The MPI Operation that implements al kind of data reduction is
 MPI_Reduce: Works similar to MPI_Gather followed by
manipulation operation in process root.

25. MPI REDUCTION
 The MPI Operation that implements al kind of data reduction is
 MPI_AllReduce: Works as MPI_Reduce followed by MPI_Bcast
 Final result has to be available to all process

26. POINT-TO-POINT COMMUNICATION (PING-PONG)
 PING-PONG Communication is also called as non-blocking
communication
 Involves sending and receiving between two process back-and-
forth MPI Communication
 Ping pong communication starts by using mpiexec command
