4. TECHNOLOGY
Average pedal fore F1=156.5N
Also, for 1.5 kg of cloths,F2=1.5*g =1.5*10N =150
Total pedal force, F=F1+F2 = 156.5+150 =306.5 =300N (approx.)
Torque T=F*r = 300*0.25 =75N-m
Power ,P =300 …………(power during cycling is between 250 to 500 W)
P =2*Pi*Np*T/60
or, 300=2*pi*Np*75/60
or, Np=38.197rpm=38rpm (actual rpm produced by pedaling)
In our demonstrative model , we have
number of teeth on pedal gear,Tp=60
number of teeth on sprocket,Ts=30
Gear Ratio=Tp/Ts=60/30=2
Also,we know that Np*Tp = Ns*Ts
or, 38*60=Ns*30
or,Ns=76 rpm
12/14/2017
4
5. TECHNOLOGY…
The same rpm is transmitted to the compound gear G1,N1=76rpm
Also, teeth on compound gear G1, T1=120
teeth on intermediate gear G2, T2 =90
teeth on small gear G3, T3=30
rpm of intermediate gear G2,
N2*T2=N1*T1
or, N2*90=76*120
or, N2=101.33rpm
rpm of small gear G3,
N3*T3=N2*T2
or, N3*30=101.33*90
or, N3=304 rpm
Hence , we get 304 rpm on the small gear shaft on which drum is
mounted.
N3/Ns=304/38 =8 times
So , we get 8 times of input rpm on the output shaft.
12/14/2017
5
6. SOCIAL IMPACT
A pedal-powered washing machine would allow
women to wash clothes faster and with less strain
It also emphasize on physical exercise of human
body
The target population for the innovation will be
the villagers of India because 35.5% of the
population still live without access to electricity
Lesser maintenance required
Zero operating cost
Very effective in protecting the hands of washer
men
12/14/2017
6
7. UNIQUENESS
The horizontal axis pedal powered washing machine has
following uniqueness like-
1.Minimized human effort in pedaling by applying gear and
pinion arrangement.
2. Works without electricity so it can be an ideal machine for the
people in the electricity deficient Indian villages.
3. Horizontal axis pedal washing machine consumes less
power as compared to vertical axis washing machine.
4. It encourages pedaling which is a good physical exercise
and keeps oneself fit.
12/14/2017
7
8. S. No. Items Likely Expenditure
(Rs. in lakhs)
1 Technology development fee 2.00
2 Telephone, Fax, Computer facility, etc. 0.25
3 Machinery hiring or leasing from outside 1.00
4 Guidance fee for mentors/ handholding persons, etc. 2.00
5 Electricity, accommodation charges, etc. 1.00
Total 6.25
Funding Required from MSME 6.00
12/14/2017
8
Activity wise break-up of Project costing
9. Technology Development and Leasing Fee Details
S.No. Items Quantity Approximate Cost
in Lacs
Total Cost in
Lacs
1 Redesigning of commercially viable structure using
AutoCAD and CATIA
1 0.5 0.5
2 Llight-weighted plastic and steel parts 1 0.2 0.2
3 Design of gear box system and shaft
AutoCAD and SolidWorks
1 0.5 0.5
4 Gear box and shaft material 1 0.1 0.1
5 Fabrication and assembling
N-x Unigraphics and CATIA
1 0.3 0.3
6 Analysis and testing
ANSYS,PROE and lab testing
1 0.4 0.4
Total 2.00
12/14/2017
9
10. MACHINERY HIRING
S.NUMBE
R
PARTICULARS APPROX.
COST
1. Gear cutting machine 30,000
2. Casting and moulding equipments 30,000
3. Plastic processing machine(to make it
leakage proof)
20,000
4. Shaping and planning machine for base
development and finishing
20,000
TOTAL 1 lakh
12/14/2017
10
