Mendix and OutSystems are leaders in the Gartner Magic Quadrant for enterprise low-code application platforms, but they differ significantly in application access controls. Mendix offers extensive, centralized tools for configuring access permissions across modules, pages, and entities, which streamlines development and maintenance. In contrast, OutSystems provides limited capabilities that require more manual intervention and can lead to increased security risks and longer development times.

1. Mendix vs.
OutSystems
Application Access Controls

2. Low-Code Application Platforms (LCAPs) ?
Gartner Magic Quadrant for Enterprise Low-Code
Application Platforms Oct. 2023
Gartner defines low-code application platforms
(LCAPs) as application platforms that are used to
rapidly develop and run custom applications by
abstracting and minimizing the use of programming
lanquages.
Both Mendix and OutSystems have been leaders in
the Gartner Magic Quadrant for Enterprise Low-Code
Application Platforms for several years.
But how do these two platforms
stack up with regards to Application
Access Controls?

3. Application Access Controls
• Role Based Access Controls
• User Roles
• Module Roles
• Page Access
• Flow Access
• Entity Access
• Role Based Access Controls
• User Roles
• Page Access
Application Access Controls is a key capability for Enterprise Low-Code Platforms, i.e. ability to configure
rules to determine user access to applications, privileges within applications and access to data.
What platform tools do Mendix and OutSystems provide to ‘configure’ Application Access Controls?

4. Let’s have a quick look at the access control
capabilities in the Mendix and OutSystems IDEs…

5. Platform Tools
Create User Roles
In Mendix, User Roles
are created at
Application level and
are accessible by
default in all modules.
BTW… in Mendix
all modules live
in the same App!

6. Platform Tools
Configure Module Roles
The Mendix module role is a
specific role created within a
module to define a set of
access permissions. One or
more module roles can be
assigned to a user role.
This concept is not available
in OutSystems

7. Platform Tools
Configure Page Access
With Mendix you can configure
role access to all pages in one
place.
With OutSystems you have to
manually add references to roles
if these are defined in another
module. There is no central place
to configure page access – each
page needs to be opened
individually to configure page
access.

8. Platform Tools
Configure Entity Access
With Mendix you can configure
Entity access in one place. Entity
CRUD privileges are defined for
each module role, as well as
access rights for each field in an
entity. These Entity Access Rules
automatically determines what a
user can see or do in the UI
depending on their roles.
Platform tools to configure Entity
Access does not exist in
OutSystems – it is up to
developers to include access rules
as part of the CRUD actions and
apply conditional access/visibility
logic in the UI.

9. Platform Tools
Create
User Roles
In OutSystems, Roles
are normally created in
a producer module, so
that roles could be
consumed by other
modules.
However, for any other
module to have access
to the roles, these need
to be added manually as
dependencies in the
consumer module.
In OutSystems an ‘App’ can
have dependencies to
modules in other Apps, and
dependencies must be
manually refreshed when
changes occur in these other
modules…

10. Platform Tools
Configure Page Access
In OutSystems you have
to open each page
individually to configure
role access.

11. Platform Tools
Apart from providing the ability to create Roles and assigning Page Access,
all other access control logic must be created manually by developers in
OutSystems.
Example Entity CRUD Action
Example UI visibility condition

12. Conclusion
• Mendix provides extensive, centralised
platform tools to configure Application
Access Controls for Pages, Flows and
Entities.
• Provides a standardised approach
across all Apps.
• Speeds up development and easy to
maintain.
• OutSystemsprovides rudimentary platform tools which are
limited to creating roles and assigning page access to roles.
• Additional access control logic needs to be created manually
by developers, e.g. CRUD actions and conditional access and
visibility of UI components.
• Longer development time.
• Maintenance overhead.
• Non-standard approach used by different developers.
• Increased risk of security breach.
