DRILLING MAST VISUAL INSPECTION (API RP 4G ANNEX A)
Company / Client :
Rig No :
Date of Inspection :
Manufacture Rig :
Mast Manufacture :
Year of Manufacture :
Manufacture is Drawing available for use in inspection
Manufacture Rating :
Mast Serial Number :
Mast Type :
Mast Position
Mast Name Plate on structurE :
3

4. 1. MAST
DRILLING MAST VISUAL INSPECTION UPPER MAST SECTION
Operation Side Front Leg :
Operation Side Rear Leg :
Off side Front Leg :
Off side Rear Leg :
Joint Section :
Diagonal Bracing :
Back Bracing :
Rod Basket Mount :
Tubing Board Mount :
Upper Latch assembly (Lock) :
Cotter Keys in place :
Mast Ligthing Mount
4

5. 1. MAST
LOWER MAST SECTION
Operation Side Front Leg :
Operation Side Rear Leg :
Off side Front Leg :
Off side Rear Leg :
Joint Section :
Diagonal Bracing :
Back Bracing :
Lower Latch Assembly :
Cotter Keys in Place :
5

6. 1. MAST
LOWER MAST SECTION
Cotter Keys in Place :
Mast Hinge Point :
Stand Pipe Mount :
Block Hanging assembly
Leg Adjustment screw/Bolt :
Telescoping Cylinder
Stabilizer :
6

7. 1. MAST
TUBING BOARD (IN MONKEY BOARD)
Tubing Board Frame :
Frame Hinge Points :
Tail Gate Hinge Points :
Left Support Line Anchor :
Right Support Line Anchore :
Diving Board :
Hand Rail :
Fingers :
Safety Cable on Fingers :
Support Cable
7

8. 1. MAST
BASE MAST SECTION
Base Section Structur :
Diagonal Support :
Mast Locking Device :
Support Beam :
Pin Pivot Mast :
8

9. 1. MAST
BASE MAST SECTION
Base Section Structur :
Diagonal Support :
Mast Locking Device :
Support Beam :
Pin Pivot Mast :
9

10. 2. SUBSTRUCTURE
SUBSTRUCTURE VISUAL INSPECTION (API RP 4 G ANNEX D)
SHOE, PEDESTAL/ BEAM /PIPE
Pin Connection :
Pin Holes :
Connection system :
Pin , Bolts :
Safety Pin :
Support Beam :
Welds :
10

11. 2. SUBSTRUCTURE
SUBSTRUCTURE VISUAL INSPECTION (API RP 4 G ANNEX D)
FLOOR AREA
Floor Plates :
Handrail and Toe Board :
Handrail connection :
Setback material :
Floor Bracing :
Welds
11

12. 2. SUBSTRUCTURE
SUBSTRUCTURE VISUAL INSPECTION (API RP 4 G ANNEX D)
SUB SPREADER AND ROTARY BEAM
Rotary Beam :
Spreaders / Support floor :
Pin Connection :
Pin Holes :
Pins :
Pads Eyes :
Welds
12

13. 2. SUBSTRUCTURE
SUBSTRUCTURE VISUAL INSPECTION (API RP 4 G ANNEX D)
DEADLINE ANCHOR MOUNTING
Support :
Bolts and Nut :
Flooring :
Breakover assembly :
13

14. 2. SUBSTRUCTURE
SUBSTRUCTURE VISUAL INSPECTION (API RP 4 G ANNEX D)
SUBSTRUCTUR COMPONEN
Beam Straight :
Cross Brace :
Pin / Bolt / Hole :
Safety Pins :
Pull Back Posts :
Drawworks Tiedowns :
Welds :
BOP Anchore Pads eyes :
Pads eyes
14

15. 2. SUBSTRUCTURE
SUBSTRUCTURE VISUAL INSPECTION (API RP 4 G ANNEX D)
STARS / LANDING / FLOORING / HANDLAIR
Welds :
Pin / Bolt Holes :
Pin / Bolt :
Floor Plating :
Star Tread Spacing :
Handrails
15
