The document provides an agenda for a workshop on how to create a LINE chatbot. It includes setting up a LINE developer account, learning about LINE@ and chatbots, creating a chatbot using the LINE Messaging API, implementing conversational dialogs, and partnerships with AI companies. The workshop involves hands-on exercises to set up a chatbot, add a rich menu, send messages with the API, create an echo bot, and use bot SDKs to develop features.

2. Agenda: Day2 How to LINE Chatbot
LINE@ vs LINE Chatbot
Workshop
• Setup LINE Developer Account
• LINE@ CMS Overview
• Setup your own LINE Chatbot
• LINE Chatbot RichMenu
• LINE Developer Dashboard
Lauch
Workshop: Developer your LINE Chatbot
• LINE User Profile
• LINE Messaging API v2 & Limitation
• LINE Webhooks (receive)
• LINE Push vs. Reply API (send)
• LINE Bot SDK
Implement Conversational Dialog Chatbot
How to Partnership with AIYA
Conclusion

3. LINE Messaging API
By MR. ATCHARIYA DAROTE
CEO & FOUDER AIYA

4. Messaging API Overview
https://developers.line.me/messaging-api/overview

5. Profile API
Profile Photo
Display Name
Status
Unique ID from LINE SystemU633424687c39c42833ca6f22f0931ca4
https://devdocs.line.me/en/#bot-api-get-profile

6. Push API and Reply API
https://devdocs.line.me/en/#reply-message https://devdocs.line.me/en/#push-message

7. 1-on-1 and Group Chats

8. Messaging Type
Text Video / Audio ImageMap Location

9. Imagemap Message https://devdocs.line.me/en/#imagemap-message

10. Template Message
Buttons Confirm Carousel
https://devdocs.line.me/en/#template-messages

11. Carousel Template Message
Max 5 Columns

12. New! Template Message
Datetime picker
supported later than
LINE 7.9.0 for iOS and
LINE 7.12.0. for Android.
Image carousel

13. Rich Menu

14. Rich Menu Example

15. Rich Menu Example

16. LINE Account Type
LINE@ Free LINE@ Account (Paid) LINE Official Account

17. Pricing

18. LINE@ API BETA
http://api-register.lineapp.me/

19. LINE@ API BETA: Term and Conditions
[Getting API]
Selected account will be contacted by our agency
[Prerequisites]
Eligible account needs to apply for PRO+ package
Valid API license document
Only Approved account is eligible for this campaign
* This is a special campaign provided by LINE
* API will be provided to LINE@ account.
* API will be free of charge and valid up to 1 year.
* LINE will not be responsible to the loss of account.
* API cannot be resold and is solely for the use of the granted party.

20. LINE@ Price Plan

21. Q & A
Contact:
sale.aiya@gmail.com
086-787-8030, 099-463-5924
http://www.aiya.ai

22. LINE Chatbot Getting Started
https://developers.line.me/messaging-api/getting-started

23. Go to
https://business.line.me/en/

28. Enable BOT API

29. Messaging API Settings

30. Add Friend
LINE@ ID

31. Greeting Message

32. Rich Menu

33. Rich Menu

34. Rich Menu

35. Rich Menu

36. ซ่อน Menu

37. URL Tips
line://nv/location
Share Location
tel:0812345678
Make call

38. Setup your BOT Rich Menu
Hand-on Exercise 30 mins

39. LINE Developer

40. Webhook
require HTTPS only

41. Example webhook event object
{
"timestamp": 1504984459576,
"type": "follow",
"source": {
"type": "user",
"userId": "U00f271c222b7351d508c1166ad2761c5"
},
"replyToken": "f8e82cf0c7014437a67f86821b60c971"
}
Follow event example
Event object for when your account is added as a friend (or unblocked).
You can reply to follow events.

42. Example webhook event object
{
"timestamp": 1504984484798,
"message": {
"text": "Hello World",
"type": "text",
"id": "6672977550518"
},
"type": "message",
"source": {
"type": "user",
"userId": "U00f271c222b7351d508c1166ad2761c5"
},
"replyToken": "009918233f36475daa24a1ebc0610804"
}
Message event
Event object which contains the sent message.
The message field contains a message object which corresponds with the message
type. You can reply to message events.

43. Webhook
require HTTPS only

44. Channel Access Token

45. Test sending messages with the Messaging API
Hand-on Exercise 20 mins

46. Hand-on Exercise 20 mins

47. Hand-on Exercise 20 mins
Send mix message
https://devdocs.line.me/en/#send-message-object

48. Hand-on Exercise 40 mins
Echo Bot

49. LINE Bot SDKs
https://github.com/line/line-bot-sdk-python

50. System Requirements
Python: https://www.python.org/
PIP: https://pip.pypa.io
VirtualEnv: https://virtualenv.pypa.io

51. LINE Bot SDKs
https://github.com/line/line-bot-sdk-python
git clone git@github.com:line/line-bot-sdk-python.git
cd line-bot-sdk-python
virtualenv env
(osx) source env/bin/activate
(win) env/Scripts/activate.bat
pip install -r examples/flask-echo/requirements.txt
python setup.py install

52. Change channel_secret & channel_access_token
Modify examples/flask-echo/app.py
python examples/flask-echo/app.py
channel_secret = ‘e2f5aba3da22c686c27ea1a…’
channel_access_token = ‘kl9CWhZVT+RtOsGobPwh1zblCp4BgW…’

53. NGROK: Secure tunnels to localhost
Download and Installation
ngrok.com
Run in command line:
ngrok http 8000
Noted by Sahit’s A.I. Club Member: https://blog.sathit.me/ทำให้-localhost-ของเรา-online-ได้ง่ายๆ-ด้วย-ngrok-51d364564214

54. Setup Webhook URL
https://XXXXXX.ngrok.io/callback

55. NGROK: Inspecting your traffic
http://localhost:4040

56. Hand-on Exercise 20 mins
Kitchensink Bot
python examples/flask-echo/app.py

57. Hand-on Exercise 20 mins
http://chatterbot.readthedocs.io/

58. Q & A

59. Contact:
atchariya@gmail.com
(+66) 093-519-9696
http://www.aiya.ai
