This document discusses microservices with Docker, Kubernetes and Jenkins. It provides an overview of Kubernetes concepts like pods, replication controllers, services and labels. It also discusses how Kubernetes can help manage containers across multiple hosts and address challenges of scaling, avoiding port conflicts and keeping containers running. The document promotes using Jenkins and Kubernetes for continuous integration and delivery of containerized microservices applications. It recommends Fabric8 as a tool that can help create and deploy microservices on Kubernetes.

1. 1
Microservices with Docker,
Kubernetes and Jenkins
Rafael Benevides & Christian Posta
@rafabene / @christianposta
http://bit.ly/kb8s-intro

2. Christian Posta
Principal Middleware Architect at Red Hat
christian@redhat.com
@christianposta
● Author “Microservices for Java Developers”
● Committer Apache Camel, ActiveMQ,
ActiveMQ PMC, Fabric8.io
● Worked with large Microservices, web-scale
companies
● Blogger, speaker about microservices,
DevOps, cloud, distributed systems,
messaging

3. Rafael Benevides
Director of Developer Experience at Red Hat
Apache DeltaSpike P.M.C
benevides@redhat.com
@rafabene
Java Certifications:
SCJA / SCJP / SCWCD / SCBCD / SCEA
JBoss Certifications:
JBCD / JBCAA
Red Hat Certifications:
OpenShift / Containers / Ansible
Other Certifications:
SAP Netweaver / ITIL / IBM Software Quality

4. developers.redhat.com
http://developers.redhat.comhttp://developers.redhat.com

5. @rafabene and @christianposta
Why do you want to run your application inside containers?

6. @rafabene and @christianposta
● Lightweight footprint and minimal overhead,
● Portability across machines,
● Simplify DevOps practices,
● Speeds up Continuous Integration,
● Empower Microservices Architectures.
● Isolation
Container
Advantages
Container Engine

7. @rafabene and @christianposta
A way to run a Linux container:
$ docker run -d <image-name>
A single and isolated Linux process
running in a single machine

8. @rafabene and @christianposta
DevOps challenges for multiple containers
● How to scale?
● How to avoid port conflicts?
● How to manage them in multiple
hosts?
● What happens if a host has a
trouble?
● How to keep them running?
● How to update them?
● Where are my containers?
Node Node
Logger
Node
Node Node Node

9. @rafabene and @christianposta
Greek for “Helmsman”; also the root of the word
“Governor” (from latin: gubernator)
● Container orchestrator
● Supports multiple cloud and bare-metal environments
● Inspired by Google’s experience with containers
● Open source, written in Go
Manage applications, not machines
Meet Kubernetes

10. @rafabene and @christianposta
Version 1.3
Hosted on GitHub
800+ contributors
34,000+ commits
16,000+ GitHub stars
Red Hat
HP
IBM
Mesosphere
Microsoft
Project Partners
CoreOS
Pivotal
SaltStack
VMWare
http://kubernetes.io/
https://github.com/kubernetes/kubernetes
Open Source community

11. Master
API Server
Service Layer
VirtualPhysical Private Public
Persistent
Storage
Node Node
Logger
Node
Node Node Node
Dev
Ops
SCM
(Git/Svn)
CI/CD
Automation
Routing Layer
Registry
SDN Overlay Network
Controllers
- Scheduler
- Replication
- Services
- Builds
- Routes
- Deployment
Kubernetes
OpenShift
- Deployments
- Builds
- ImageStreams

12. @rafabene developers.redhat.com
Kubernetes Concepts
Pod Replication
Controller
Service Label
One or More Containers
Shared IP
Shared Storage Volume
Shared Resources
Shared Lifecycle
Ensures that a specified
number of pod replicas are
running at any one time
Grouping of pods, act as
one, has stable virtual IP
and DNS name
Key/Value pairs associated
with Kubernetes objects
(e.g. env=production)

13. @rafabene and @christianposta
Concept: Pod
● Group of containers
● Live and die together
● Share:
○ IP
○ Secrets
○ Volumes
○ Labels *
* we will talk about labels later
Labels
Application
Administrative
console
Log collector
IP: 10.x.x.x
Volume

14. SCM
(Git/Svn)
Master
API Server
Service Layer
VirtualPhysical Private Public
Persistent
Storage
Node Node
Logger
Node
Node Node Node
Dev
Ops
CI/CD
Automation
Routing Layer
Registry
SDN Overlay Network
Controllers
- Scheduler
- Replication
- Services
- Builds
- Routes
- Deployment
Kubernetes
OpenShift
- Deployments
- Builds
- ImageStreams

15. SCM
(Git/Svn)
Master
API Server
Service Layer
VirtualPhysical Private Public
Persistent
Storage
Node Node
Logger
Node
Node Node Node
Dev
Ops
CI/CD
Automation
Routing Layer
Registry
SDN Overlay Network
Controllers
- Scheduler
- Replication
- Services
- Builds
- Routes
- Deployment
Kubernetes
OpenShift
- Deployments
- Builds
- ImageStreams

16. SCM
(Git/Svn)
Master
API Server
Service Layer
VirtualPhysical Private Public
Persistent
Storage
Node Node
Logger
Node
Node Node Node
Dev
Ops
CI/CD
Automation
Routing Layer
Registry
SDN Overlay Network
Controllers
- Scheduler
- Replication
- Services
- Builds
- Routes
- Deployment
Kubernetes
OpenShift
- Deployments
- Builds
- ImageStreams

17. @rafabene and @christianposta
Concept: Labels
App: Cool
Env: Dev
Version: 1.0
App: Cool
Env: Prod
Version: 1.0
App: Cool
Env: Dev
Version: 2.0
App: Cool
Env: Prod
Version: 2.0
Everything in Kubernetes can
have a label
Node
Logger
Node
NodeNode

18. @rafabene and @christianposta
Concept: Labels
App: Cool
Env: Dev
Version: 1.0
App: Cool
Env: Prod
Version: 1.0
App: Cool
Env: Dev
Version: 2.0
App: Cool
Env: Prod
Version: 2.0
Logger
Node
NodeNode
Node

19. @rafabene and @christianposta
Concept: Labels
App: Cool
Env: Dev
Version: 1.0
App: Cool
Env: Prod
Version: 1.0
App: Cool
Env: Dev
Version: 2.0
App: Cool
Env: Prod
Version: 2.0
Logger
Node
Node
Node
Node

20. @rafabene and @christianposta
Node 2
POD
App: Cool
Env: Prod
Version: 1.0
POD
Service
Labels selector:
● App=Cool
● Env=Prod
IP: 172.x.x.x
App: Nice
Env: Prod
Version: 1.0
Concept: Services
Node 1
POD

21. @rafabene and @christianposta
Using Environment variables:
Using internal DNS: $ ping mysql
Service discovery

22. @rafabene and @christianposta
Deployment Concept: Rolling Updates
Pod
Replication
Controller
Pod Pod Pod
App: Cool
Version: 1.0
Version: 1.0
Replicas: 4
Backend
Replication
Controller
Version: 2.0
Replicas: 1
PodPod Pod Pod
App: Cool
Version: 2.0
Version: 1.0
Replicas: 3
Version: 2.0
Replicas: 2
Version: 1.0
Replicas: 2
Version: 2.0
Replicas: 3
Version: 1.0
Replicas: 1
Version: 2.0
Replicas: 4

23. @rafabene and @christianposta
If you want to now more about Kubernetes, join
The "Kubernertes for Java Developers" lab
Wednesday, Sep 21, 12:30 p.m. - 2:30 p.m.
Hilton - Franciscan Room C/D

24. @rafabene and @christianposta

25. @rafabene and @christianposta
Hello World Service
- Greet
Guestbook Service
- Create
Guestbook Service -
Retrieve

26. @rafabene and @christianposta
Creating business value through software is
about speed, safety, iteration, and continuous
improvement

27. @rafabene and @christianposta

28. @rafabene and @christianposta
How do we deliver value fast (and safely)?
ANSWER:
Continuous delivery of containerized microservices

29. @rafabene and @christianposta
Challenges of microservices CI/CD
● Lots of independent teams want their own
○ flexible pipelines
○ Environments (Dev/IST/UAT/Prod)
○ Resources (compute, network, storage)
● Automation because we have lots of microservices
○ Creation of projects, CD pipelines, environments,
releases, etc.

30. @rafabene and @christianposta
Jenkins and Kubernetes is kinda groovy!
Jenkins Pipeline + Jenkins Kubernetes Plugin Rocks!

31. @rafabene and @christianposta
Fabric8 all the things!
● Built on top of Kubernetes
● Wizards to create microservices
● Package as immutable containers
● Rolling upgrade across environments
● 1-Click install of fully configured CI/CD
(Jenkins Pipeline, Nexus, Git)
● Feedback loops
● Lots of developer tooling
http://fabric8.io

32. @rafabene and @christianposta
Fabric8 stands on the shoulder of giants

33. @rafabene and @christianposta
And more giants...

34. @rafabene and @christianposta
And more giants...

35. @rafabene and @christianposta
Did I mention giants...

36. @rafabene and @christianposta
Getting started with Fabric8 on Kubernetes
● Kubernetes
○ Google Container Engine (GKE)
http://cloud.google.com/container-engine
○ Amazon, Azure, Digital Ocean, et.al.
https://stackpoint.io
○ On premise:
http://kubernetes.io
● OpenShift (Enterprise Kubernetes)
○ https://openshift.com
● Then deploy fabric8 with gofabric8 deploy
○ https://github.com/fabric8io/gofabric8
http://fabric8.io

37. @rafabene and @christianposta
Demo Time!! Please reach out with questions!
Rafael Benevides
@rafabene
benevides@redhat.com
Christian Posta
@christianposta
christian@redhat.com
