Java fx on raspberry pi gerrit grunwald

•

0 likes•4,070 views

JavaFX can be used to create user interfaces for embedded systems like the Raspberry Pi and BeagleBone Black. While Java's "write once, run anywhere" mantra does not directly apply to embedded due to different requirements and constraints, much code can be reused from mobile and desktop applications by focusing on content over elaborate graphics, limiting the number of nodes in the scene graph, and avoiding memory-intensive operations. With optimization, JavaFX applications can run well on embedded devices with as few as 3-60 nodes in the scene graph.

Gerrit
Grunwald
!
!
!
!

canoo
TWITTER: @hansolo_

Engineering AG

WEB: harmonic-code.org

CPU : ARM A9 DualCore
Clock: 1.2 GHz
Ram : 1 GB
GPU : Power VR SGX540

Benefits of Java
Superb developer toolchain
★ Mature, fast, widespread
★ Thousands of libraries
★ Huge community
★ No standard on embedded
★

★ Home

automation
★ Home entertainment
★ Medical devices
★ Information Kiosks
★ Education

Without support for
Swing/SWT
★ System Menu
★ Drag'n Drop
★ WebView
★ Media (e.g. AudioClip)
★

Available JDK's

11/2013

★

JDK 7 (JFX 2)*

★

JDK 8 (JFX 8)
*dev. prev. from 2012

Target* footprint
6
1
~
N

B
M

I
M

*~32 MB today

WHAT ARE THE SUPPORTED

PLATFORMS ?
11/2013

ARM A8, 1 GHz
★ 512 MB RAM
★ 4 x USB
★ ETHERNET RJ45
★ HDMI
★ I2C, JTAG, SPI
★

JDK 7
JavaFX 2

xM
BeagleBoard

dev. preview of 2012
with SoftFloat support

ARM v6, 700 MHz
★ 512 MB RAM
★ 2 x USB
★ ETHERNET RJ45
★ HDMI, COMPOSITE
★ GPIO, I2C, UART, SPI
★

JDK 8
JavaFX 8

Pi
Raspberry

weekly dev. preview
with HardFloat support

Macbook Pro

BeagleBoard xM

Intel i7 Quadcore
2.3 GHz

ARM A8
1 Ghz

16 GB ram

512 MB ram

Nvidia GeForce
GT 650m

Power VR
SGX series 5

Macbook Pro

BeagleBoard xM

Nvidia GeForce
GT 650m

Power VR
SGX series 5

384 Cores
★ ~15 GPixel/s
★ ~600 GFlops
★

1 Core
★ ~500 MPixel/s
★ ~1.6 GFlops
★

Requirements
★

touchable user interface

★

reasonable controls

★

no mouse and keyboard

★

restriced screen estate

60 cm

50 mm

FROM MOBILE

90 mm

34 cm

and learn

The Scene Graph
Root
Node

Branch

Leaf

Branch

Branch

Leaf

Leaf

Leaf

Branch

The Scene Graph
Each node is about 5-7 kb
★ Desktop could handle up to
100000 nodes
★ Embedded devices can
handle up to 1000 nodes !!!
★

CONTENT

COMPROMISE 1

3 Nodes

33 Nodes

CONTENT

COMPROMISE 2

3 Nodes

16 Nodes

Things to avoid
huge amount of nodes
★ intense use of animations
★ intense use of effects
★ many overlapping nodes
★ memory intense operations
★
