1. NORMALIZATION
Prof. Sridhar Vaithianathan

2. Entities, Attributes and Relationship
 Strong Entity Vs Weak entity ( EMPLOYEE &
DEPENDENT)
 Simple Vs Composite Attributes
 Single Valued Vs Multi Valued Attributes
 Stored Vs Derived Attributes
 Identifier Attribute – Primary Key
 Composite Identifier
 Foreign Key
 Sub-Type Vs Super Type Relationship

3. Properties of Relations
1. Each relation (or table) in a database has a unique name.
2. An entry at the intersection of each row and column is
atomic (single valued).there can be no multivalued
attributes in a relation.
3. Each row (record) is unique; no two rows in a relation
are identical.
4. Each attribute(or column) within a table has a unique
name.
5. The sequence of columns/rows (left to right/top to
bottom) is insignificant.

5. Integrity Constraints
 Domain Constraints: All of the values that appear in a column of
a relation must be taken from the same domain.
– A domain is the set of values that may be assigned to an attribute. [Domain
definition usually consists of: domain name, meaning, data type, size
(length), and allowable values/range.]
 Entity Integrity Constraint: No primary key attribute (or
component of primary key attribute) may be null.
– Null: A value that may be assigned to an attribute when no other value
applies or when the applicable value is unknown.
– Null is neither numeric zero nor string of blanks.
– In reality null is not a value but rather absence of a value
 Referential Integrity Constraint: Either each foreign key value
must match a primary key value in another relation or the foreign
key value must be null. ( Eg : Student who has not been assigned any faculty as mentor)

6. Logical Database Design
1. Top-down approach > E-R modeling
2. Bottom-up approach > Normalization.
Databases : Relational Vs Non-Relational.
What is Normalization?
It is a formal process for deciding which attributes should be
grouped together in relation
It is a step by step decomposition of complex records into simple
records and thereby reducing redundancy
Why Normalize ?
Normalization reduces redundancy. Redundancy is the unnecessary
repetition of data

7. Redundancy can lead to:
1. Inconsistencies – Errors are more likely to occur when facts are
repeated
2. Update Anomalies
- Inserting, modifying and deleting data may cause
inconsistencies
- High likelihood of updating or deleting data in one table while
omitting to make corresponding changes in other relations
A fully normalized record consists of:
1. A primary key that identifies an entity
2. A set of attributes that describe the entity
Normal forms (NF) are table structures with minimum redundancy

8. Functional Dependency
Normalization theory is based on the fundamental notion of functional
dependency.
Given a relation R, attribute B is functionally dependent on A if , for
every valid instance of A, that value of A uniquely determines the
value of B.
The functional dependency of B on A is represented as below
A B
Example: Suppose entity CUSTOMER has the following attributes
Cust_Code, Name, Address and Phone_Number.
Cust_Code Name, Address, Phone_Number
Cust_Code Name Address Phone_Number

9. Boyce -
Codd NF,
4 NF and
5NF
1 NF
2 NF
3 NF
Unnormalized Relation
Steps in Normalization

10. Steps in Normalization
1. 1NF: A relation is in 1NF if multi-valued attributes (also called
repeating groups) have been removed, so there is a single value
(possibly null) at the intersection of each row and column of the
table.
2. 2NF: A relation is in 2NF if it is in 1NF, and contains no partial
dependencies.
A partial functional dependency in a relation is a functional dependency in
which one or more nonkey attributes are functionally dependent on part
(but not all) of the primary key.
3. 3NF:A relation is in 3NF if it is in 2NF and no transitive
dependencies exist.
A transitive dependency in a relation is a functional dependency between
two (or more) nonkey attributes.

11. Pine Valley Furniture Company Database

12. Invoice Data - Pine Valley Furniture Company

13. 1 NF: A relation is in 1NF if multi-valued attributes
(also called repeating groups) have been removed, so
there is a single value (possibly null) at the intersection
of each row and column of the table.

14. Functional Dependency Diagram for Invoice
A partial functional dependency in a relation is a functional
dependency in which one or more nonkey attributes are
functionally dependent on part (but not all) of the primary
key.

15. Removing Partial Dependencies
2NF: A relation is in 2NF if it is in 1NF, and contains no
partial dependencies.
A transitive dependency in a relation is a functional
dependency between two (or more) nonkey attributes.

16. Removing Transitive Dependencies
3NF:A relation is in 3NF if it is in 2NF and no transitive
dependencies exist.

17. Note to Students: For drawing ER diagram of your project , Try MS Visio, an
easy to use tool to draw the ER Diagram as one shown above
Relational Scheme for INVOICE data
(MS Visio)

18. SQL – Structured Query Language
SQL Statements
SELECT (select list)
FROM (table List)
WHERE (condition for
retrieval)
ORDER BY (sort criteria)
Example:
SELECT Empno, Ename,
Job, Sal
FROM EMP
WHERE Sal > 2500
ORDER BY Job, Ename
Table : EMP
Empno Ename Job Sal
8756 Dravid President 8000
5348 Raju Manager 5000

19. SQL – Structured Query Language
SQL Statements
SELECT (select list)
FROM (table List)
WHERE (condition for
retrieval)
ORDER BY (sort criteria)
Example:
SELECT Order Number,
Unit Price *Quantity AS
Total
FROM Order

20. Normalization - Recap

21. 1. 1NF: A relation is in 1NF if multi-valued attributes (also
called repeating groups) have been removed, so there is a
single value (possibly null) at the intersection of each row and
column of the table.
2. 2NF: A relation is in 2NF if it is in 1NF, and contains no
partial dependencies.
A partial functional dependency in a relation is a functional dependency
in which one or more nonkey attributes are functionally dependent
on part (but not all) of the primary key.
3. 3NF:A relation is in 3NF if it is in 2NF and no transitive
dependencies exist.
A transitive dependency in a relation is a functional dependency
between two (or more) nonkey attributes.
SUMMARY - Normalization – Rules – 1NF TO 3NF

22. First Normal Form (1NF)
 First normal form (1NF) sets
the very basic rules for an
organized database:
 Eliminate duplicative columns
from the same table.
 Create separate tables for each
group of related data and
identify each row with a unique
column or set of columns (the
primary key).
Second Normal Form (2NF)
 Second normal form (2NF)
further addresses the concept of
removing duplicative data:
 Meet all the requirements of the
first normal form.
 Remove subsets of data that
apply to multiple rows of a
table and place them in separate
tables.
 Create relationships between
these new tables and their
predecessors through the use of
foreign keys.
Third Normal Form (3NF)
•Third normal form (3NF) goes one large step further:
•Meet all the requirements of the second normal form.
•Remove columns that are not dependent upon the primary key.
SUMMARY - Normalization – Rules – 1NF TO 3NF

23. 1NF
 Eliminate Repeating Groups - Make a separate table for
each set of related attributes, and give each table a primary
key.
2NF
 Eliminate Redundant Data - If an attribute depends on only
part of a multi-valued key, remove it to a separate table.
3NF
 Eliminate Columns Not Dependent On Key - If attributes
do not contribute to a description of the key, remove them
to a separate table.
SUMMARY - Normalization – Rules – 1NF TO 3NF

24. Normalization - Exercises

26. Normalize
Exercise 1
 Emp _No
 Prof_Designation
 Emp_Name
 Dept_Code
 Dept_Name
 Prof_Office
 Student_Name
 Student_Id
 Student DOB
 Student Age
Exercise 2
 Prod No
 Prod Desc
 Item No
 Salesperson Name
 Customer Name
 Quantity
 Price

27. Normalize
 Emp No
 Emp Name
 Dept No
 Dept Name
 Mgr No
 Proj No
 Proj Name
 Start Date
 Billing Rate

28. Normalize
Title Author1 Author
2
ISBN Subject Pages Publisher
Database
System
Concepts
Abraham
Silberschatz
Henry F.
Korth
0072958863 MySQL,
Computers
1168 McGraw-Hill
Operating
System
Concepts
Abraham
Silberschatz
Henry F.
Korth
0471694665 Computers 944 McGraw-Hill
