Some 30 years ago software engineers began to incorporate some of the architect Christoper Alexander's design patterns work into their own, with the crecendo being the Gang of Four's "Design Patterns: Elements Of Reusable Object-Oriented Software" written in 1995. Understanding these common proven methodologies for solving problems can accelerate development, improve maintainability, and conjure better software almost magically. Being classless, it's often difficult to directly see how classical design patterns can map to more fluid languages like JavaScript--but the language has taken quite nicely to both classical patterns and even supported the invention of some novel, never seen before patterns.

1. JavaScript Design Patterns

3. Itinerary
1. What are patterns?
2. Why should we use them?
3. Prerequisites
4. Modules
5. Facades
6. Mediators

4. What is a Pattern?
• A reusable solution that can be applied to commonly
occurring problems in software design.
Patterns are proven solutions.
Patterns are reusable.
Patterns are expressive.
• Socialized in our industry by the legendary GoF tome of
software patterns. But from whence did they originally
come?

5. • Christopher Alexander (born
October 4, 1936 in Vienna)
• Cambridge University, BA in
Architecture, MS in
Mathematics. PhD from Harvard
in Architecture.
• “Notes on the Synthesis of Form”
was required reading in CS
throughout the 60’s.
• “A Pattern Language” greatly
influenced the design patterns
movement.

6. Three Kinds
• Creational: Methodologies for controlling the creation
process of objects. In classical languages these are
prolific.
• Structural: Methodologies for organizing code into
minimally coupled functional units and realize
relationships between different objects.
• Behavioral: Methodologies that focus on streamlining
communication between disparate objects.

7. Why Patterns?
• Patterns can encourage us to code in a more structured
and organized fashion.
• Patterns can provide generalized solutions which are not
tied to a specific problem, and some facilitate DRY
principles.
• Patterns are supported by a larger force than the individual
developer.
• Patterns create a language by which developers may
quickly communicate.

8. A Quick Experiment
• Internal sensors are detecting a lifesign on deck 16,
section 3, Jeffries tube junction 16C4-5. It appears
to be a cat.
• What the strag will think is that any man that can hitch
the length and breadth of the Galaxy, rough it, slum it,
struggle against terrible odds, win through and still know
where his towel is, is clearly a man to be reckoned with.
• Patterns build a vocabulary between developers and
facilitate better communication. Writing code is an
exercise in communication.

9. Prerequisites
• JavaScript is classless; everything is an object. Many
“classical” design patterns do not apply or need be
modified to map appropriately.
! var myObjectLiteral = { !
!! variableKey: variableValue,!
!! functionKey: function () {!
! // ...!
!! }!
! };
<= Scoping and Closures
Object literal notation =>
!
function makeAdder(x) {!
var numAddersMade = 0;!
return function(y) {!
numAddersMade++;!
return x + y;!
};!
}! !

10. Three Interoperating Patterns
Modules
Facades
Mediators

11. The Module Pattern
• Ubiquitous—you’ve likely already seen and/or used them.
Almost every major framework uses some flavor of
modules.
• There are many different flavors. We’ll go through only a
couple of them.
• In all versions the central idea remains constant: group
related functionality. This is the separation of concerns
ideology.
• Let’s take a look at a simple implementation.

12. !
var myNamespace = (function () {!
!
var myPrivateVar, myPrivateMethod;!
!
// A private counter variable!
myPrivateVar = 0;!
!
// A private function which logs any arguments!
myPrivateMethod = function( foo ) {!
console.log( foo );!
};!
!
return {!
!
// A public variable!
myPublicVar: "foo",!
!
// A public function utilizing privates!
myPublicFunction: function( bar ) {!
!
// Increment our private counter!
myPrivateVar++;!
!
// Call our private method using bar!
myPrivateMethod( bar );!
!
}!
};!
!
})();!

13. !
var basketModule = (function() {!
var basket = []; //private!
return { //exposed to public!
addItem: function(values) {!
basket.push(values);!
},!
getItemCount: function() {!
return basket.length;!
},!
getTotal: function(){!
var q = this.getItemCount(),p=0;!
while(q--){!
p+= basket[q].price; !
}!
return p;!
}!
}!
}());!
!
public class Basket {!
! private List<Product> products;!
! public void addItem(Product p) { //... }!
! public int getItemCount() { //... }!
! public double getTotal() { //... }!
}!
!!
If you’re familiar with
classical compiled
languages: the two
pieces of code to the left
are functionally equivalent.
Modules allow hiding—
that is keeping your
internals private.

14. Handling Dependencies
!
(function ($) {!
// Module impl goes here!
return {!
// Return module interface here!
}!
}(jQuery));!
!
!
// myModule is now in global scope!
var myModule = (function($) {!
// Module impl goes here!
return {!
// Return module interface here!
}!
}(jQuery));!
!
Importing other modules
is quite simple.
As is exporting your
existing module.

15. CommonJS
• There exists a standard definition for modules called
Asynchronous Module Definition (AMD) built by the
original CommonJS mailing list participants.
• AMD is a maintained standard that has a good
following: https://github.com/amdjs/amdjs-api/wiki/
AMD
• Key dependency: no modules may be synchronously
loaded. The order should not be significant.

16. //Calling define with module ID, dependency array, !
//and factory function!
define('myModule', ['dep1', 'dep2'], function (dep1, dep2) {!
!
//Define the module value by returning a value.!
return function () {};!
});
• Reserves the word “define” for creating modules and
describing relationships between them.
• Supported by major frameworks such as Angular.js (look
familiar?).
angular.module("myModule").factory("myNamespace.myModule", MyModule);!
MyModule.$inject = [ "$http", "$cookies" ];!
function MyModule($http, $cookies) { //... !
}

17. Augmentation
• Allows for implementations of a single
module to exist in multiple files.
• Loose augmentation: modules can be
loaded in any order. Overriding methods is
not possible.
module.base.js
module.f1.js
module.f2.js
module.patch1.js
!
var myModule = (function(module) {!
var privateMethod = function() { //... }!
return {!
publicApi : privateMethod!
}!
}(myModule || {}));!
!!
Advanced Topics

18. var myModule = (function (me) {!
! var old_moduleMethod = me.moduleMethod;!
!
! me.moduleMethod = function () {!
! ! // method override!
! };!
!
! return me;!
}(myModule || {}));
Tight augmentation
enables method
overrides.
• There are novel uses for both tight and loose augmentation.
We could push a hot-patch without breaking existing code.
• Tight augmentation requires an order to loading. This breaks
the AMD spec, but buys you a lot of power.
• Super advanced topic: it’s also possible to share state across
files: http://bit.ly/18byc2Q
Advanced Topics

19. Hotfixes
• Tight augmentation can be used to efficiently hot fix
bugs so long as the affected module supports it.
Implement fix as a
module override
Apply fix through
HTML script
imports
var myModule = (function (me) {!
! var broken = me.foo;!
!
! me.foo = function () {!
! ! // patch the issue here!
! };!
!
! return me;!
}(myModule || {}));
<script src="myApp.js" />!
<!-- Temporary fix! -->!
<script src="myPatch.js" />
Save as a patch file. Order matters!
Deploy, but now
fix the issue for
real :D.

20. Revealing Module
• Simply a way of organizing
your code so it looks nicer.
• Easy to read and understand
the interface provided by the
module.
• Watch out: if a private
function refers to a public
function, you possibly cannot
override the public function if
a patch is necessary.
!
var basketModule = (function() {!
var basket = []; //private!
!
var _addItem = function(values) {!
basket.push(values);!
}!
!
var _getItemCount = function() {!
return basket.length;!
}!
!
var _getTotal = function() {!
var q = this.getItemCount(),p=0;!
while(q--){!
p+= basket[q].price; !
}!
return p;!
}!
!
// Nice, clean interface!
return { !
addItem: _addItem,!
getItemCount: _getItemCount,!
getTotal: _getTotal!
}!
}());!

21. Facades
• A facade is a limited abstraction on top of a more
complex body of code.
• Consumers interacting with the facade often interact
with a very simple API hiding a complex sub-system.
• A facade also decouples interfaces from
implementation—allowing for hot-swappable sub-systems.
• Only expose existing behavior.

22. var ecommerceFacade = (function (basketModule, promoModule) {!
return {!
getTotal : function () {!
return basketModule.getTotal() * (1 - promoModule.getPercentDiscount());!
},!
listPromoCodes : promoModule.listPromoCodes,!
getPercentDiscount : promoModule.getPercentDiscount,!
getItemCount : basketModule.getItemCount,!
addItem : basketModule.addItem,!
addPromoCode : basketModule.addPromoCode!
}!
}(basketModule, promoModule));!
Facades should be used to further decouple business logic by
supplying a common, well known interface on existing components.
var addMyEvent = function( el,ev,fn ){!
!
if( el.addEventListener ){!
el.addEventListener( ev,fn, false );!
}else if(el.attachEvent){!
el.attachEvent( "on" + ev, fn );!
} else{!
el["on" + ev] = fn;!
}!
};!
They are often useful for
hiding ugly browser-based
logic switches.

23. Mediators
• Mediators encapsulate how a set of objects interact.
• This promotes loose coupling by keeping objects from
referring to each other explicitly and allows you to vary
their interaction independently.
• Mediators promote high cohesion by keeping code for
interaction between modules encapsulated.
• Think of them as “workflow” facilitators.

24. Example Flow
Mediators encapsulate complex interactions between actors
(modules) in the system. The facilitate communication without the
need for directly referencing the desired component.
Order Mediator
E-Commerce
Facade
Basket Module Promo Module Order Service
getTotal()
submitOrder()

25. Pub/Sub Subtleties
• Mediators often look like event aggregators. They can
be confused with other similar patterns such as
Observer.
• The difference between mediators and other pub/sub
paradigms is simply this: where is the application logic
coded?
• Mediators are “white gloved” business logic, while
event aggregators are “fire and forget.”

26. Which Pattern(s)?
• Build a component that handles interaction with a user
profile service. Actions include logging in via token based
authentication and performing CRUD on user data.
• Build a payment processing component that supports
multiple payment types like PayPal, credit card, or credit
card reward points from your partner systems.
• Build a component that drives an interactive car designer.
Note that some accessories and features may only be
available at specific trim levels and geographical locations.

27. Parting Words
• Pick the right tool for the job in your circumstances.
• Know modules inside and out. Settle on one paradigm
and don’t deviate.
• Mediators are very slick—consider them when the
relationships between objects becomes complex.
• These patterns can be used inside frameworks too
(Angular, Backbone, etcetera).

28. Questions?
Next time: Promises!
