The Product

Interoperability
Mobility
Portability
Open and Flexible Architecture
Productivity Reliability Security

Value Proposition
InTouch Edge HMI is an easy-to-use, powerful, and affordable
HMI/SCADA software and IoT/Industry 4.0 solutions for PCs,
industrial panels, embedded & mobile devices
Develop your project once  Deploy and run it anywhere
Linux, Windows CE/Mobile, Windows Embedded, Windows Desktop and Server Editions, among others.

Comprehensive set of tools for
SCADA, HMI, and IoT solutions

Layer of abstraction
for Communication
for Databases/ERP
for Hardware/OS
Platforms
for proprietary
systems
Modular Architecture

Customization
(User, Project, Deployment Specific)
Template
(Industry Specific)
Data Center Template
Product
(General Market)
InduSoft Web Studio
OEM focused template architecture
Solution in Layers

Templates
PackML
“PackML, which stands for
Packaging Machine Language,
defines a common approach, or
machine language, for automated
machines. The primary goals are to
encourage a common "look and
feel" across a plant floor and to
enable and encourage industry
innovation.”
-OMAC
“Overall equipment effectiveness
(OEE) is a concept utilized in a lean
manufacturing implementation. OEE
is becoming a commonly utilized
maintenance metric within lean
organizations. The high-level
formula for the lean manufacturing
OEE is:
OEE = Availability X Productivity X
Quality.”
-Reliable Plant Web Site
“Andon (Japanese: アンドン or あん
どん or 行灯) is a manufacturing
term referring to a system to notify
management, maintenance, and
other workers of a quality or process
problem. The center piece is a
signboard incorporating signal lights
to indicate which workstation has
the problem.”
-Wikipedia
OEE ANDON

100% Compatibility with applications designed in previous versions
Evolve protecting your investment!
1997
InduSoft v1.0
Windows NT
Windows 95
Windows CE v1.0
2019
InduSoft Web Studio v8.1
Windows 10 / 8 / 7
Windows Server 2016 / 2012
Windows 10 IoT Enterprise
Windows Embedded Standard 7 /8
Windows Embedded Compact 7 / 6 / 5
Linux
Investment Protection

Full Featured HMI: EmbeddedView
SCADA: Full Runtime
Compact HMI: CEView
InduSoft Web Studio
Development Station
Develop once,
Deploy anywhere
Single, integrated
development
environment
IoT Edge Solution: IoTView
Portability

SCADA
OEE / MES
HMI
Embedded/M
obile
Seamless deployment across
multiple operating systems
Hardware manufacturer
independency!
Platform Agnostic

Platforms: Windows
Host: Secure Viewer (executable)
Technology: ActiveX
Platforms: Windows
Host: Web Browser (Internet Explorer)
Technology: ActiveX
Web Thin Clients
Secure Viewer Thin Clients
Platforms: Agnostic
Host: Web Browser agnostic / apps
Technology: HTML5
Studio Mobile Access (SMA) Thin Clients
Mobility

Deployment

Interoperability
InduSoft
Web
StudioOver 250
Protocols
(Drivers)
TCP/IP
OPC Server
Gateway
XML
ODBC/ADO
DDE
OPC UA,
DA, XML,
.NET
Web
(HTML &
XML)
Driver &
Database
API
Open Architecture
System Integration
Product Customization
Enterprise
Excel, Access , Oracle , MySQL, Sybase
SQL Server, SQL Azure, Wonderware Historian
and many others...
Client Stations
Redundancy
Data Exchange in Real-Time
Third-Party Systems
Thin Clients
Web Solution
Access to the system from
anywhere using a single browser
Mobile Access
Email, data, and page interface
from mobile devices
Plant Floor Integration
OMRON, Beckhoff,
Schneider-Electric,
AllenBradley ,GE FANUC,
Siemens, Modbus, Profibus,
DeviceNet, ControlNet,
Interbus, and many others...

Easy-to-configure interface to
any SQL Relational Database:
SQL Server, Oracle, MySQL,
Sybase, OSI PI, MS Access,
Excel, and others…
Interface via standard
technologies: ADO.NET, ADO,
OLE-DB, and ODBC
Redundancy and
Store-and-forward built-in
features
Alarm history, Event history,
Trend history, Process data,
OEE dashboards, and more.
Database Interface

“HMI software is being increasingly used as a digital dashboard to show key performance
indicators (KPIs) such as overall equipment effectiveness (OEE) for the entire enterprise, and to
generate reports of actual performance versus targets.”
ARC Advisory Group
ERP Integration

Solutions for Windows
Server/Desktop
Control Room Lite 32K
Operator Workstation Plus 16K
Advanced Server 512K
Advanced Server Plus 10M
Control Room 64K
Tags
EmbeddedView for Windows Embedded
CEView for Windows Embedded CE
IoTView for Linux
Develop/RunRuntime Only
Lite Interface Plus 300Lite Plus
Lite Interface 150Lite
Operator Workstation 4,000Professional
Local Interface 1,500Standard
The Power of Choice: Support for all features in any product type always meets your needs.
Different product types to fit your budget.
Licensing

Competitiveness
•Support for manufacturer-independent platforms provides unique flexibility.
•Remote diagnosis with built-in security features allows efficient data analysis.
•Open architecture empowers the integration to different systems, devices, or
databases.
Productivity
•Mobile solution provides online data anywhere.
•Database integration allied to web thin client charts provide meaningful
information in reports, such as OEE, which drive actions to optimize the process.
•Alarm management system reduces the time to fix abnormal conditions.
Cost Management
•Most cost-efficient tool in the market.
•Intuitive single development interface reduces the development, deployment, and
maintenance cost.
•Thin client solution provides significant savings.
Main Benefits
