First half of a two-part talk. I'll show how the Lexer, Parser and AST work in PHP, introducing a little bit of compiler theory that helps explain.

1. @asgrim
Interpret this…
James Titcumb
PHPem Unconference 2016

2. Who is this guy?
James Titcumb
www.jamestitcumb.com
www.roave.com
www.phphants.co.uk
www.phpsouthcoast.co.uk
@asgrim

3. @asgrim
How PHP works
PHP code
OpCache
Execute (VM)
Lexer + Parser
Compiler

4. @asgrim
The PHP Lexer
zend_language_scanner.l

5. @asgrim
zend_language_scanner.l
<ST_IN_SCRIPTING>"exit" {
RETURN_TOKEN(T_EXIT);
}
<ST_IN_SCRIPTING>"die" {
RETURN_TOKEN(T_EXIT);
}
<ST_IN_SCRIPTING>"function" {
RETURN_TOKEN(T_FUNCTION);
}

6. @asgrim
zend_language_scanner.l
<ST_IN_SCRIPTING>"exit" {
RETURN_TOKEN(T_EXIT);
}
<ST_IN_SCRIPTING>"die" {
RETURN_TOKEN(T_EXIT);
}
<ST_IN_SCRIPTING>"function" {
RETURN_TOKEN(T_FUNCTION);
}

7. @asgrim
zend_language_scanner.l
<ST_IN_SCRIPTING>"exit" {
RETURN_TOKEN(T_EXIT);
}
<ST_IN_SCRIPTING>"die" {
RETURN_TOKEN(T_EXIT);
}
<ST_IN_SCRIPTING>"function" {
RETURN_TOKEN(T_FUNCTION);
}

8. @asgrim
zend_language_scanner.l
<ST_IN_SCRIPTING>"exit" {
RETURN_TOKEN(T_EXIT);
}
<ST_IN_SCRIPTING>"die" {
RETURN_TOKEN(T_EXIT);
}
<ST_IN_SCRIPTING>"function" {
RETURN_TOKEN(T_FUNCTION);
}

9. @asgrim
zend_language_scanner.l
<ST_DOUBLE_QUOTES,ST_BACKQUOTE,ST_HEREDOC>"${" {
yy_push_state(ST_LOOKING_FOR_VARNAME);
RETURN_TOKEN(T_DOLLAR_OPEN_CURLY_BRACES);
}
<ST_LOOKING_FOR_VARNAME>{LABEL}[[}] {
yyless(yyleng - 1);
zend_copy_value(zendlval, yytext, yyleng);
yy_pop_state();
yy_push_state(ST_IN_SCRIPTING);
RETURN_TOKEN(T_STRING_VARNAME);
}

10. @asgrim
zend_language_scanner.l
<ST_DOUBLE_QUOTES,ST_BACKQUOTE,ST_HEREDOC>"${" {
yy_push_state(ST_LOOKING_FOR_VARNAME);
RETURN_TOKEN(T_DOLLAR_OPEN_CURLY_BRACES);
}
<ST_LOOKING_FOR_VARNAME>{LABEL}[[}] {
yyless(yyleng - 1);
zend_copy_value(zendlval, yytext, yyleng);
yy_pop_state();
yy_push_state(ST_IN_SCRIPTING);
RETURN_TOKEN(T_STRING_VARNAME);
}

11. @asgrim
zend_language_scanner.l
<ST_DOUBLE_QUOTES,ST_BACKQUOTE,ST_HEREDOC>"${" {
yy_push_state(ST_LOOKING_FOR_VARNAME);
RETURN_TOKEN(T_DOLLAR_OPEN_CURLY_BRACES);
}
<ST_LOOKING_FOR_VARNAME>{LABEL}[[}] {
yyless(yyleng - 1);
zend_copy_value(zendlval, yytext, yyleng);
yy_pop_state();
yy_push_state(ST_IN_SCRIPTING);
RETURN_TOKEN(T_STRING_VARNAME);
}

12. @asgrim
zend_language_scanner.l
<ST_DOUBLE_QUOTES,ST_BACKQUOTE,ST_HEREDOC>"${" {
yy_push_state(ST_LOOKING_FOR_VARNAME);
RETURN_TOKEN(T_DOLLAR_OPEN_CURLY_BRACES);
}
<ST_LOOKING_FOR_VARNAME>{LABEL}[[}] {
yyless(yyleng - 1);
zend_copy_value(zendlval, yytext, yyleng);
yy_pop_state();
yy_push_state(ST_IN_SCRIPTING);
RETURN_TOKEN(T_STRING_VARNAME);
}

13. @asgrim
zend_language_scanner.l
<ST_DOUBLE_QUOTES,ST_BACKQUOTE,ST_HEREDOC>"${" {
yy_push_state(ST_LOOKING_FOR_VARNAME);
RETURN_TOKEN(T_DOLLAR_OPEN_CURLY_BRACES);
}
<ST_LOOKING_FOR_VARNAME>{LABEL}[[}] {
yyless(yyleng - 1);
zend_copy_value(zendlval, yytext, yyleng);
yy_pop_state();
yy_push_state(ST_IN_SCRIPTING);
RETURN_TOKEN(T_STRING_VARNAME);
}

14. @asgrim
zend_language_scanner.l
<ST_DOUBLE_QUOTES,ST_BACKQUOTE,ST_HEREDOC>"${" {
yy_push_state(ST_LOOKING_FOR_VARNAME);
RETURN_TOKEN(T_DOLLAR_OPEN_CURLY_BRACES);
}
<ST_LOOKING_FOR_VARNAME>{LABEL}[[}] {
yyless(yyleng - 1);
zend_copy_value(zendlval, yytext, yyleng);
yy_pop_state();
yy_push_state(ST_IN_SCRIPTING);
RETURN_TOKEN(T_STRING_VARNAME);
}

15. @asgrim
zend_language_scanner.l
<ST_DOUBLE_QUOTES,ST_BACKQUOTE,ST_HEREDOC>"${" {
yy_push_state(ST_LOOKING_FOR_VARNAME);
RETURN_TOKEN(T_DOLLAR_OPEN_CURLY_BRACES);
}
<ST_LOOKING_FOR_VARNAME>{LABEL}[[}] {
yyless(yyleng - 1);
zend_copy_value(zendlval, yytext, yyleng);
yy_pop_state();
yy_push_state(ST_IN_SCRIPTING);
RETURN_TOKEN(T_STRING_VARNAME);
}

16. @asgrim
zend_language_scanner.l
<ST_DOUBLE_QUOTES,ST_BACKQUOTE,ST_HEREDOC>"${" {
yy_push_state(ST_LOOKING_FOR_VARNAME);
RETURN_TOKEN(T_DOLLAR_OPEN_CURLY_BRACES);
}
<ST_LOOKING_FOR_VARNAME>{LABEL}[[}] {
yyless(yyleng - 1);
zend_copy_value(zendlval, yytext, yyleng);
yy_pop_state();
yy_push_state(ST_IN_SCRIPTING);
RETURN_TOKEN(T_STRING_VARNAME);
}

17. @asgrim
zend_language_scanner.l
<ST_DOUBLE_QUOTES,ST_BACKQUOTE,ST_HEREDOC>"${" {
yy_push_state(ST_LOOKING_FOR_VARNAME);
RETURN_TOKEN(T_DOLLAR_OPEN_CURLY_BRACES);
}
<ST_LOOKING_FOR_VARNAME>{LABEL}[[}] {
yyless(yyleng - 1);
zend_copy_value(zendlval, yytext, yyleng);
yy_pop_state();
yy_push_state(ST_IN_SCRIPTING);
RETURN_TOKEN(T_STRING_VARNAME);
}

18. @asgrim
The PHP Lexer
zend_language_scanner.l

19. @asgrim
The PHP Lexer
zend_language_scanner.l
re2c

20. @asgrim
The PHP Lexer
zend_language_scanner.l
re2c
zend_language_scanner.c

21. @asgrim
The PHP Parser
zend_language_parser.y

22. @asgrim
zend_language_parser.y
if_stmt:
if_stmt_without_else %prec T_NOELSE { $$ = $1; }
| if_stmt_without_else T_ELSE statement
{ $$ = zend_ast_list_add($1, zend_ast_create(ZEND_AST_IF_ELEM, NULL, $3)); }
;
if_stmt_without_else:
T_IF '(' expr ')' statement
{ $$ = zend_ast_create_list(1, ZEND_AST_IF,
zend_ast_create(ZEND_AST_IF_ELEM, $3, $5)); }
| if_stmt_without_else T_ELSEIF '(' expr ')' statement
{ $$ = zend_ast_list_add($1,
zend_ast_create(ZEND_AST_IF_ELEM, $4, $6)); }
;

23. @asgrim
if_stmt:
if_stmt_without_else %prec T_NOELSE { $$ = $1; }
| if_stmt_without_else T_ELSE statement
{ $$ = zend_ast_list_add($1, zend_ast_create(ZEND_AST_IF_ELEM, NULL, $3)); }
;
if_stmt_without_else:
T_IF '(' expr ')' statement
{ $$ = zend_ast_create_list(1, ZEND_AST_IF,
zend_ast_create(ZEND_AST_IF_ELEM, $3, $5)); }
| if_stmt_without_else T_ELSEIF '(' expr ')' statement
{ $$ = zend_ast_list_add($1,
zend_ast_create(ZEND_AST_IF_ELEM, $4, $6)); }
;
zend_language_parser.y

24. @asgrim
if_stmt:
if_stmt_without_else %prec T_NOELSE { $$ = $1; }
| if_stmt_without_else T_ELSE statement
{ $$ = zend_ast_list_add($1, zend_ast_create(ZEND_AST_IF_ELEM, NULL, $3)); }
;
if_stmt_without_else:
T_IF '(' expr ')' statement
{ $$ = zend_ast_create_list(1, ZEND_AST_IF,
zend_ast_create(ZEND_AST_IF_ELEM, $3, $5)); }
| if_stmt_without_else T_ELSEIF '(' expr ')' statement
{ $$ = zend_ast_list_add($1,
zend_ast_create(ZEND_AST_IF_ELEM, $4, $6)); }
;
zend_language_parser.y

25. @asgrim
if_stmt:
if_stmt_without_else %prec T_NOELSE { $$ = $1; }
| if_stmt_without_else T_ELSE statement
{ $$ = zend_ast_list_add($1, zend_ast_create(ZEND_AST_IF_ELEM, NULL, $3)); }
;
if_stmt_without_else:
T_IF '(' expr ')' statement
{ $$ = zend_ast_create_list(1, ZEND_AST_IF,
zend_ast_create(ZEND_AST_IF_ELEM, $3, $5)); }
| if_stmt_without_else T_ELSEIF '(' expr ')' statement
{ $$ = zend_ast_list_add($1,
zend_ast_create(ZEND_AST_IF_ELEM, $4, $6)); }
;
zend_language_parser.y

26. @asgrim
if_stmt:
if_stmt_without_else %prec T_NOELSE { $$ = $1; }
| if_stmt_without_else T_ELSE statement
{ $$ = zend_ast_list_add($1, zend_ast_create(ZEND_AST_IF_ELEM, NULL, $3)); }
;
if_stmt_without_else:
T_IF '(' expr ')' statement
{ $$ = zend_ast_create_list(1, ZEND_AST_IF,
zend_ast_create(ZEND_AST_IF_ELEM, $3, $5)); }
| if_stmt_without_else T_ELSEIF '(' expr ')' statement
{ $$ = zend_ast_list_add($1,
zend_ast_create(ZEND_AST_IF_ELEM, $4, $6)); }
;
zend_language_parser.y

27. @asgrim
if_stmt:
if_stmt_without_else %prec T_NOELSE { $$ = $1; }
| if_stmt_without_else T_ELSE statement
{ $$ = zend_ast_list_add($1, zend_ast_create(ZEND_AST_IF_ELEM, NULL, $3)); }
;
if_stmt_without_else:
T_IF '(' expr ')' statement
{ $$ = zend_ast_create_list(1, ZEND_AST_IF,
zend_ast_create(ZEND_AST_IF_ELEM, $3, $5)); }
| if_stmt_without_else T_ELSEIF '(' expr ')' statement
{ $$ = zend_ast_list_add($1,
zend_ast_create(ZEND_AST_IF_ELEM, $4, $6)); }
;
zend_language_parser.y

28. @asgrim
if_stmt:
if_stmt_without_else %prec T_NOELSE { $$ = $1; }
| if_stmt_without_else T_ELSE statement
{ $$ = zend_ast_list_add($1, zend_ast_create(ZEND_AST_IF_ELEM, NULL, $3)); }
;
if_stmt_without_else:
T_IF '(' expr ')' statement
{ $$ = zend_ast_create_list(1, ZEND_AST_IF,
zend_ast_create(ZEND_AST_IF_ELEM, $3, $5)); }
| if_stmt_without_else T_ELSEIF '(' expr ')' statement
{ $$ = zend_ast_list_add($1,
zend_ast_create(ZEND_AST_IF_ELEM, $4, $6)); }
;
zend_language_parser.y

29. @asgrim
if_stmt:
if_stmt_without_else %prec T_NOELSE { $$ = $1; }
| if_stmt_without_else T_ELSE statement
{ $$ = zend_ast_list_add($1, zend_ast_create(ZEND_AST_IF_ELEM, NULL, $3)); }
;
if_stmt_without_else:
T_IF '(' expr ')' statement
{ $$ = zend_ast_create_list(1, ZEND_AST_IF,
zend_ast_create(ZEND_AST_IF_ELEM, $3, $5)); }
| if_stmt_without_else T_ELSEIF '(' expr ')' statement
{ $$ = zend_ast_list_add($1,
zend_ast_create(ZEND_AST_IF_ELEM, $4, $6)); }
;
zend_language_parser.y

30. @asgrim
if ($a == 1)
{
a();
}
else if ($b == 1)
{
b();
}
else
{
c();
}
Using the rules to parse

31. @asgrim
if ($a == 1)
{
a();
}
else if ($b == 1)
{
b();
}
else
{
c();
}
Using the rules to parse
if_stmt_without_else (A)

32. @asgrim
if ($a == 1)
{
a();
}
else if ($b == 1)
{
b();
}
else
{
c();
}
Using the rules to parse
if_stmt_without_else (A)
if_stmt_without_else (B)

33. @asgrim
if ($a == 1)
{
a();
}
else if ($b == 1)
{
b();
}
else
{
c();
}
Using the rules to parse
if_stmt_without_else (A)
if_stmt_without_else (B)
if_stmt

34. @asgrim
Zend_language_parser.y (PHP 7.0.10)
if_stmt:
if_stmt_without_else %prec T_NOELSE { $$ = $1; }
| if_stmt_without_else T_ELSE statement
{ $$ = zend_ast_list_add($1, zend_ast_create(ZEND_AST_IF_ELEM, NULL, $3)); }
;
if_stmt_without_else:
T_IF '(' expr ')' statement
{ $$ = zend_ast_create_list(1, ZEND_AST_IF,
zend_ast_create(ZEND_AST_IF_ELEM, $3, $5)); }
| if_stmt_without_else T_ELSEIF '(' expr ')' statement
{ $$ = zend_ast_list_add($1,
zend_ast_create(ZEND_AST_IF_ELEM, $4, $6)); }
;

35. @asgrim
zend_language_parser.y (PHP 5.6.26)
T_IF parenthesis_expr { zend_do_if_cond(&$2, &$1 TSRMLS_CC); }
statement { zend_do_if_after_statement(&$1, 1 TSRMLS_CC); }
void zend_do_if_cond(const znode *cond, znode *closing_bracket_token TSRMLS_DC)
{
int if_cond_op_number = get_next_op_number(CG(active_op_array));
zend_op *opline = get_next_op(CG(active_op_array) TSRMLS_CC);
opline->opcode = ZEND_JMPZ;
SET_NODE(opline->op1, cond);
closing_bracket_token->u.op.opline_num = if_cond_op_number;
SET_UNUSED(opline->op2);
INC_BPC(CG(active_op_array));
}

36. @asgrim
AST is new in PHP 7+

37. @asgrim
How PHP works
PHP code
OpCache
Execute (VM)
Lexer + Parser
Compiler

38. @asgrim
Let’s simplify!

39. @asgrim
First… WTF is AST?

40. @asgrim
AST is just a data structure

41. @asgrim
PHP code
<?php
echo "Hello world";

42. @asgrim
An AST representation
Echo statement
`-- String, value "Hello world"

43. @asgrim
PHP code
<?php
echo "Hello " . "world";

44. @asgrim
An AST representation
Echo statement
`-- Concat
|-- Left
| `-- String, value "Hello "
`-- Right
`-- String, value "world"

45. @asgrim
PHP code
<?php
$a = 5;
$b = 3;
echo $a + ($b * 2);

46. @asgrim
An AST representation
Assign statement
|-- Variable $a
`-- Integer, value 5
Assign statement
|-- Variable $b
`-- Integer, value 3
Echo statement
`-- Add operation
|-- Left
| `-- Variable $a
`-- Right
`-- Multiply operation
|-- Left
| `-- Variable $b
`-- Right
`-- Integer, value 2

47. @asgrim
AST compilation
Statements
EchoAssign
Scalar
value: (int)5
Variable
name: $a
Assign
Scalar
value: (int)3
Variable
name: $b
Add op
Right operandLeft operand
Variable
name: $a
Multiply op
Right operandLeft operand
Variable
name: $b
Scalar
value: (int)2

48. @asgrim
AST compilation: pre-order traversal
Statements
EchoAssign
Scalar
value: (int)5
Variable
name: $a
Assign
Scalar
value: (int)3
Variable
name: $b
Add op
Right operandLeft operand
Variable
name: $a
Multiply op
Right operandLeft operand
Variable
name: $b
Scalar
value: (int)2

49. @asgrim
Pre-order traversal: Polish notation
Assign(Variable $a, Scalar 5)
Assign(Variable $b, Scalar 3)
Echo (
Add(
Variable $a,
Multiply( $b, 2 )
)
)

50. @asgrim
Order of precedence
1 + 2 * 3
= 1 + (2 * 3) = 7?
= (1 + 2) * 3 = 9?

51. @asgrim
Order of precedence
1 + 2 * 3
= 1 + (2 * 3) = 7?
= (1 + 2) * 3 = 9?
+ 1 * 2 3

52. @asgrim
Order of precedence
1 + 2 * 3
= 1 + (2 * 3) = 7?
= (1 + 2) * 3 = 9?
+ 1 * 2 3
Operator Left operand Right operand

53. @asgrim
Order of precedence
1 + 2 * 3
= 1 + (2 * 3) = 7?
= (1 + 2) * 3 = 9?
+ 1 * 2 3
Operator Left operand Right operand
Operator Left operand Right operand

54. @asgrim
Reverse Polish Notation
1 2 3 * +

55. @asgrim
Reverse Polish Notation
1 2 3 * + The stack

56. @asgrim
Reverse Polish Notation
1 2 3 * + The stack
1

57. @asgrim
Reverse Polish Notation
1 2 3 * + The stack
1
2

58. @asgrim
Reverse Polish Notation
1 2 3 * + The stack
1
2
3

59. @asgrim
Reverse Polish Notation
1 2 3 * + The stack
1
2
3

60. @asgrim
Reverse Polish Notation
1 2 3 * + The stack
1
2
3

61. @asgrim
Reverse Polish Notation
1 2 3 * + The stack
1
6

62. @asgrim
Reverse Polish Notation
1 2 3 * + The stack
1
6

63. @asgrim
Reverse Polish Notation
1 2 3 * + The stack
7

64. Any questions?
James Titcumb @asgrim
