X-Y RECORDER
Submitted To:
●Ranjan Khusi
Department of Information Technology
Everest Engineering College
Submitted By:
● Bikash Sahani
● Dinesh Newar
● Dipendra Raj Bhatt
2.
2
OBJECTIVES
❏ To knowthe basic concept of XY recorder.
❏ Understand working Principle of XY
recorder.
INTRODUCTION
• Devices thatrecord the variation in one
dependent variable with respect to an
independent variable.
• Or An output device that graphically records
the relationship between two variables on a
grid of plane rectangular coordinates.
• X-Y recorders are employed using proper
transducers for recording of physical quantities
as function of other physical quantities.
• In the late 1920s, Francis L. Moseley,
conceived the idea of an X-Y recorder.
5.
5
TYPES
1. Analog XYRecorder
● Old Version
● Gives output as Analog Signal
● The motion of recording pen in
both axes is driven by servo-
system,
Reference to stationary chart
paper
● Less Accurate
6.
6
2. Digital XYRecorder
● Digital XY plotter.
● Uses open loop stepping
motor drive.
● More accurate.
● Provides following feature:
○ Simultaneous sampling
and storage of multiple
data.
○ Multi-pen plotting data
10
APPLICATION FIELDS
● Plottingof different curves
○ Hysteresis curve
○ Stress-Strain Curve
○ Regulation curves
● Pressure Volume Diagram for LC engine
● Pressure Flow Study for Lungs
● Plotting output for electronic computers
● Plotting characteristics of
○ Regulation curves of power supply
○ Vacuum tubes
○ transistors
11.
CONCLUSION
➔ XY Recorderrecords variation in one variable with respect to
another variable.
➔ It is technique to compare two or more variables electronically.
➔ Important tool and technique used in different fields so,
let us thank L.Moseley for such a great contribution.
