- 1. iOS ~ 2d GameDev Alain Hufkens - @hufkens! CocoaHeadsBE - Hasselt - 2014-06-24
- 3. • Geek Dad • 15y programming • Freelance • Wee Taps • CoderDojo Intro
- 5. Agenda • Game Engines • SpriteKit • SpriteBuilder / Cocos2D • Q&A
- 7. Cocos2d • 2008 • Simple 2D game engine • +10k games built with Cocos2D • Bought by Zynga • Spawned into Cocos2D-X • Development stopped for a while
- 8. Cocos2D V1.x
- 9. Cocos2D V2.x
- 10. Sprite Kit • 2013 • 2D Game Framework • iOS7+ only • Provided by Apple (since iOS7) • Improved in iOS8 • Simple to prototype games
- 11. Sprite kit
- 12. Cocos2D V3 • 2014 • Cocos2D v3 • Spritebuilder • Supported by Apportable • 2D Game Development Suite • Cross Platform & Native
- 13. Spritebuilder
- 14. Sprite kit
- 15. Scene graph Scene Background Foreground HUD Hero Score Bg Image Tree Tree
- 16. Game Loop
- 17. Game Loop
- 19. SKNode! The base class! • Used for grouping in node tree @property SKNode *parent; @property SKNode *children; • Used for positioning itself and children @property CGPoint position; // relative to parent @property CGFloat zRotation; // radians @property CGFloat xScale, yScale; // scaling • Can control visibility @property CGFloat alpha; @property BOOL hidden; • Can run actions • Can be a physics body
- 20. Sprite Kit Nodes! Node classes Class Description SKNode Parent class of all nodes SKScene Root of the scene graph SKSpriteNode! Renders a textured sprite SKEmitterNode Generates and renders particles SKLabelNode Renders a text string SKVideoNode Plays video content SKShapeNode Renders a shape SKEffectNode Applies a Core Image filter to its children SKCropNode Crops its children using a mask
- 22. • Draws a Sprite • Can be a: • color • textured image • Has a explicit size SKSpriteNode SKSpriteNode
- 23. SKSpriteNode! Simple creation SKSpriteNode *rocket = [SKSpriteNode spriteNodeWithImageNamed:@"rocket.png"]; ! rocket.position = CGPointMake(50.0, 50.0); ! [self addChild:rocket];
- 24. • Full Featured 2D particle system • Configurable by attributes • Xcode particle editor • easy-to-use • visual preview SKEmitterNode! Particles!
- 25. SKEmitterNode! Particles!! NSString *particlePath = [[NSBundle mainBundle] pathForResource:@"flame" ofType:@“sks"]; ! SKEmitterNode *flames = [NSKeyedUnarchiver unarchiveObjectWithFile:particlePath]; ! flames.particlePosition = CGPointMake(50.0, 50.0); ! [self addChild:flames];
- 26. Demo
- 28. • Fundamental Sprite Kit object ! • Very Flexible [SKTexture textureWithImageNamed:@"rocket.png"]; [SKTexture textureWithCGImage:myCGImageRef]; [SKTexture textureWithData:rgbaNSData size:CGSizeMake(100, 100)]; [SKTexture textureWithImage:myUIImage]; [SKTexture textureWithRect:CGRectMake(100, 100, 80, 80) inTexture:tex1]; SKTexture! Sprite Kit bitmap data
- 29. • Many images combined into a single larger image • Saves memory • Improves drawing efficiency rocket_red.png rocket_green.png rocket_flames.png … cloud.png character_1.png character_2.png character_3.png …. Texture Atlases! Key to performance
- 30. • Load a SKTexture from a stand-alone file • Load a SKTexture from a texture atlas SKTexture *texture = [SKTexture textureWithImageNamed:@“rocket.png"]; SKTexture *texture = [SKTexture textureWithImageNamed:@“rocket.png"]; Texture Atlases! Loading from a Texture Atlas It’s the same! Sprite Kit manages atlases for you
- 31. Demo
- 33. • Root node of the scene graph • Displayed by a SKView • Inherits from SKEffectsNode • Runs per-frame loop -update: -didEvaluateActions -didSimulatePhysics SKScene Background Foreground HUD Hero Score Bg Tree Tree SKScene! Presents the content
- 34. SKScene! Organization • Level 1 ! • Level 2 ! • Level 3 ! • … ! • Level N • Main menu • Game Options • Game • Game Over
- 35. Demo
- 37. • Very simple to use • Single action class - SKAction • One line creation • Chain-able, reusable, readable • Like a scripting language for Sprite Kit • Actions directly affect the node it is run on • Actions run immediately • Removed on completion [node runAction: [SKAction rotateByAngle:M_PI duration:1.0]]; Actions!
- 38. Basic Actions! ! ! [SKAction rotateByAngle:M_PI duration:1.0]; ! [SKAction moveTo:aCGPoint duration:1.0]; ! [SKAction fadeAlphaTo:0.8 duration:1.0]; ! [SKAction scaleBy:2.0 duration:1.0]; ! [SKAction scaleXBy:1.5 y:0.5 duration:1.0];
- 39. Compound Actions! Sequences! [node runAction: [SKAction sequence:@[action1, action2, action3]]]; action1 1.0 sec action2 2.0 sec action3 0.5 sec SKAction Sequence 3.5 sec
- 40. Compound Actions! Groups! [node runAction: [SKAction group:@[action1, action2, action3]]]; action1 1.0 sec action2 2.0 sec action3 0.5 sec SKAction Group 2.0 sec
- 41. Specialty SKActions! Animate! [SKAction animateWithTextures:@[tex0, tex1, tex2, …] timePerFrame:0.1];
- 42. Specialty SKActions! Follow path! [SKAction followPath:myPath duration:2.5]; ! [SKAction followPath:myPath asOffset:YES orientToPath:NO duration:5.0];
- 43. • Zero duration, fires once • Show the Game Over menu after character death animation [SKAction runBlock:^{ doSomething(); }]; SKAction *fade = [SKAction fadeOutWithDuration:1.0]; SKAction *remove = [SKAction removeFromParent]; SKAction *showMenu = [SKAction runBlock:^{ [self showGameOverMenu]; }]; [heroSprite runAction: [SKAction sequence:@[fade, showMenu, remove]] ]; Specialty SKActions! Run block
- 44. • moveByX:y:duration: • moveTo:duration: • moveToX:duration: • moveToY:duration: • rotateByAngle:duration: • rotateToAngle:duration: • scaleXTo:duration: • scaleYTo:duration: • speedBy:duration: • speedTo:duration: • scaleBy:duration: • scaleXBy:y:duration: • scaleTo:duration: • scaleXTo:y:duration: • sequence: group: • setTexture: runBlock: • runBlock:queue: • removeFromParent • performSelector:onTarget: • resizeByWidth:height:duration: • resizeToWidth:height:duration: • resizeToWidth:duration: • resizeToHeight:duration: • repeatAction:count: • repeatActionForever: • fadeInWithDuration: • fadeOutWithDuration: • fadeAlphaBy:duration: • fadeAlphaTo:duration: • animateWithTextures:timePerFrame: • animateWithTextures:timePerFrame:resize: • playSoundFileNamed:waitForCompletion: • colorizeWithColor:colorBlendFactor: • colorizeWithColorBlendFactor:duration: • followPath:duration: • followPath:asOffset:orientToPath: • waitForDuration: • waitForDuration:withRange: • runAction:onChildWithName: • customActionWithDuration:actionBlock: SKActions! Huge list
- 45. Demo
- 46. physics
- 47. • Uses Box2D under the hood • open source physics engine • C++ • Objective-C API • Fully integrated into Sprite Kit Box2D SpriteKit Your code Sprite Kit Physics
- 48. • Set the physics body of your Sprite + = Physics Body
- 49. • Shape bodies • Circle • Rectangle • Custom shaped • Pixel (iOS8) • Edge loop bodies edge Physics Bodies
- 50. • Restitution • Density • Friction ! • Dynamic • usesPreciseCollisionDetection • allowsRotation • affectedByGravity • node • … Physics Properties!
- 51. Demo
- 53. • SpriteBuilder Tool • Scenes designer • Animation timeline • Less code to write ! • Open Source • Faster releases ! • With Apportable also native Android Features!
- 54. Demo
- 55. Thanks
- 56. • www.hufkens.net • alain@hufkens.net • @hufkens ! • www.weetaps.com • @weetaps COntact
