Titan @ Gitpro Conference 2014
- 1. AURELIUS THINKAURELIUS.COM TITAN Scalable Graph Database Matthias Broecheler @mbroecheler April 12th, MMXIV
- 5. name: Newton type: user name: Hercules type: user title: “How to deal with Father issues” type: book title: “Muscle building for beginners” type: book title: “Dancing with the Stars” type: DVD title: “Friends forever bracelet” type: Accessory
- 6. name: Newton type: user name: Hercules type: user bought bought bought viewed in-Cart title: “How to deal with Father issues” type: book title: “Muscle building for beginners” type: book title: “Dancing with the Stars” type: DVD title: “Friends forever bracelet” type: Accessory
- 7. name: Newton type: user name: Hercules type: user bought time:24 bought bought time:22 time:20 viewed in-Cart time:05 time:09 title: “How to deal with Father issues” type: book title: “Muscle building for beginners” type: book title: “Dancing with the Stars” type: DVD title: “Friends forever bracelet” type: Accessory
- 8. name: Newton type: user name: Hercules type: user bought time:24 bought bought time:22 time:20 viewed in-Cart time:05 time:09 title: “How to deal with Father issues” type: book title: “Muscle building for beginners” type: book title: “Dancing with the Stars” type: DVD title: “Friends forever bracelet” type: Accessory
- 10. Home-grown Solution ! Start with your favorite NoSQL database ! Cassandra, MongoDB, HBase, etc 1. Error-prone 2. Data model moves into application code 3. Maintainability hazard 4. No query language support 5. No performance optimization
- 11. Relational Database ! Relationship tables, SQL and joins 1. Join processing is expensive 2. Join processing on large tables does not scale 3. Cumbersome query language 4. Inflexible data model
- 12. SELECT P.title FROM User U1 JOIN Purchase P1 ON P1.buyerid = U1.userid JOIN Purchase P2 ON P1.productid=P2.productid JOIN Purchase P3 ON P2.buyerid=P3.buyerid JOIN Product P ON P3.productid = P.productid WHERE U1.name=“xyz” AND P1.time>T1 AND P2.time>T1
- 13. Relational Database ! Relationship tables, joins, and SQL 1. Join processing is expensive 2. Join processing on large tables does not scale 3. Cumbersome query language 4. Inflexible data model
- 14. name: Newton type: user name: Hercules type: user bought friends time:24 bought bought time:22 time:20 viewed in-Cart time:05 duration: 60 time:09 name: Saturn type: author author author title: “How to deal with Father issues” type: book title: “Muscle building for beginners” type: book title: “Dancing with the Stars” type: DVD title: “Friends forever bracelet” type: Accessory
- 17. name: Hercules type: user bought time:24 6?LN?R %>A? ,;<?F %>A? 0LIJ?LNS t E?S q P;FO? title: “Muscle building for beginners” type: book
- 18. name: Newton type: user name: Hercules type: user bought friends time:24 bought bought time:22 time:20 viewed in-Cart time:05 duration: 60 time:09 name: Saturn type: author author author title: “How to deal with Father issues” type: book title: “Muscle building for beginners” type: book title: “Dancing with the Stars” type: DVD title: “Friends forever bracelet” type: Accessory
- 22. Vertex-Centric Indices ! Sort and index edges per vertex by sor tkey ! Sort key can be composite ! Enables efficient focused traversals ! Only retrieve edges that matter ! Uses push down predicates for quick, index-driven retrieval
- 23. Token Ring Graph Partitioning ;MMCAHM C>M NI G;J P?LNC=?M CHNI “IJNCG;F” NIE?H L;HA? ,INM I@ CHN?L?MNCHA KO?MNCIHM @IL@ONOL? QILE OM?M "/0
- 27. 121 Billion Edges 6.2 Billion Vertices U -CFFCIH 5HCP?LMCNC?M W . Y "CFFCIH 3NO>?HNM
- 29. 1.1 million edges / sec OMCHA <;N=B GI>? Data Ingestion
- 30. ^ GU .G?>COG
- 31. 10,200 transactions / sec UZ L;H>IGFS =BIM?H =IGJF?R NL;P?LM;F N?GJF;N?M Throughput
- 32. Transaction Description Avg (ms) Stdev (ms) Student retrieves all content for a single course in their course list 279.32 81.83 Student follows another student 193.72 22.77 Student is recommended people to follow 241.33 256.48 Student reads their stream and shares an item with followers 284.07 68.20 Student retrieves their profile 53.740 22.61 Student reads the most recent comments for their courses 211.07 45.56
- 33. x = [] as Set; m = [:]! m = user.out('follows').aggregate(x)[0..(num*2)]! !.out('follows').except(x)[0..limit]! !.groupCount(m);! ! m.sort{-it.value}[0..num]._()! !.transform{ [userid: it.key.id, ! ! ! ! ! ! ! points: it.value]};! &IFFIQ 2?=IGG?H>;NCIH
- 35. ! Hadoop-based Graph Computing Framework ! Graph Analytics ! Breadth-first Traversals ! Global Graph Computations ! Batch Big Graph Data Faunus Features
- 37. Faunus Work Flow hdfs://user/ubuntu/ output/job-0/ output/job-1/ output/job-2/ { graph* sideeffect* g.V.out .out .count() Compressed HDFS Graphs ! stored in sequence files ! variable length encoding ! prefix compression
- 38. Degree Distribution GitHub Network g.V.sideEffect{ it.degree = it.out(‘follows’).count() }.degree.groupCount
- 39. Degree Distribution P(k) ~ k-γ γ = 2.2
- 40. Global Recommendations gremlin> g.E.has('label','pushed','to').keep.! ! ! !V.out('pushed').out('to').! ! ! !in('to').in('pushed').! ! ! !sideEffect('{it.score =it.pathCounter}').! ! ! !score.order(F.decr,'name')! ! # Top 5:! Jippi ! ! ! !60892182927! garbear ! ! !30095282886! FakeHeal ! ! !30038040349! brianchandotcom !24684133382! nyarla! ! !15230275746!
- 41. Aurelius Graph Cluster OLTP OLAP Hadoop MapReduce Analysis results back into Titan Apache 2 g.V.label.groupCountg.v(101).out titan.thinkaurelius.com faunus.thinkaurelius.com aureliusgraphs@googlegroups.com
