3. Introduction
• Fluid, electrolyte , and acid base balances within
the body are necessary to maintain health and
function in all body systems. These balances are
maintained by the intake and output of water and
electrolytes and regulation by the Renal and
pulmonary systems. Imbalances may result from
factors like altered fluid intake, or prolonged
episodes of vomiting or diarrhea.
2/28/2021
JONES
H.M
-MBA/DMS
3
4. TERMINOLOGIES RELATED
TO BODY FLUIDS AND
ELECTROLYTES
• Solvent-substance capable of dissolving a solute.
• Solute-Substance that dissolves in a solvent
• Electrolyte-substance whose molecules dissociate
or split into ions when placed in water.
• Osmolarity-measure of total solute concentration
per liter of solution
2/28/2021
JONES
H.M
-MBA/DMS
4
5. • Isotonic solution-fluid with the same osmolarity as
the interior of the cell
• Hypotonic -solutions where solutes are less
concentrated than the cells
• Hypertonic -solutions where solutes are more
concentrated than the cells
2/28/2021
JONES
H.M
-MBA/DMS
5
6. DISTRIBUTION OF BODY
FLUIDS
• Water is a major component of our
body’s make up. 60% of an adult
male’s body weight is water while
50% of an adult female weight is
water. 80% of a baby’s weight is
water.
2/28/2021
JONES
H.M
-MBA/DMS
6
7. DISTRIBUTION OF BODY FLUIDS
Body fluids are distributed into two
distinct compartments, that is
intracellular fluids and extracellular
fluids.
Intracellular fluid comprises of fluid
within body cells. In adults approx.
40% of body weight is ICF.
2/28/2021
JONES
H.M
-MBA/DMS
7
8. Extracellular fluid is all the fluid outside
a cell. It is divided into smaller
compartments : interstitial fluid( lymph),
intravascular fluid( blood plasma) and
transcellular fluids( CSF, pleural,
peritoneal, and synovial fluids.
Extracellular fluid makes up 20% of the
body weight.
2/28/2021
JONES
H.M
-MBA/DMS
8
9. Functions of body water
• Transport of nutrients and
electrolytes to cells
• Dissolving and carrying waste
products away from the cell
• Regulation of body temperature
• Acts as a medium for food digestion
2/28/2021
JONES
H.M
-MBA/DMS
9
10. IONIC COMPOSITION OF
BODY COMPARTMENTS
Plasma
(mmol/L)
Interstitial
fluid
(mmol/L)
Intracellul
ar fluid
(mmol/L)
Na+ 142 144 10
K+ 4 4 160
Ca2+ 2.5 2.5 1.5
Mg2+ 1.0 0.5 13
2/28/2021
JONES
H.M
-MBA/DMS
10
12. REGULATION OF BODY
FLUIDS
Body fluids are regulated by fluid
intake, hormonal control and fluid
output.
Fluid intake is regulated primarily
through thirst mechanism. The thirst
control center is located in the
hypothalamus in the brain.
2/28/2021
JONES
H.M
-MBA/DMS
12
13. • Fluid intake regulated by the
thirst control center in the
hypothalamus.
• Average intake for an
adult=2200-2700mls per day
2/28/2021
JONES
H.M
-MBA/DMS
13
14. Hormonal regulation
Antidiuretic hormone (ADH) is released in
response to blood osmolarity. It works directly on
the renal tubules making them more permeable to
water thereby causing more water to return to the
systemic circulation.
2/28/2021
JONES
H.M
-MBA/DMS
14
15. • Aldosterone is released by the Adrenal
cortex. in response increases plasma
potassium levels . it acts on the distal
portion of the renal tubule to increase
the reabsorption of Na and the
secretion and excretion of potassium
and hydrogen.
2/28/2021
JONES
H.M
-MBA/DMS
15
16. FLUID OUTPUT REGULATION
• Output occurs through four organs of water loss,
kidneys, skin , lungs and gastrointestinal tract.
• Kidneys produces and excretes between 1200-
1500mls of urine per day
• Skin loses water through sweat.
On average 500-600mls of fluids is lost through
the skin.
• Lungs expires on average 400mls of water per day
2/28/2021
JONES
H.M
-MBA/DMS
16
17. ASSESSMENT OF FLUID
REQUIREMENTS.
• History taking. The history will
reveal any risk factor that may cause
disturbance of fluid and electrolyte
balance.
• Physical assessment . You look out for
signs of fluid deficit and fluid excess .
2/28/2021
JONES
H.M
-MBA/DMS
17
18. Fluid volume Deficit:
• Sunken eyes.
• Cold clummy skin.
• Loss of skin turgor.
• Dry mucus membranes.
• Weak pulse.
• Low Blood pressure.
• Oliguria or anuria.
• Decreased body temperature.
2/28/2021
JONES
H.M
-MBA/DMS
18
20. TYPES OF FLUIDS
• The types of fluids used in fluid
therapy are oral fluids and
intravenous fluids. If the loss is mild,
oral rehydration is recommended and
if fluid loss is severe intravenous
therapy is administered.
2/28/2021
JONES
H.M
-MBA/DMS
20
21. • IV solutions available for use fall into
the following categories: isotonic,
hypotonic and hypertonic
• The decision as to which solution to
use depends on the specific fluid and
electrolyte imbalance.
2/28/2021
JONES
H.M
-MBA/DMS
21
22. Dextrose in water solutions
• Dextrose 5% isotonic
( dextrose is quickly metabolized,
leaving free water to be distributed
evenly in all fluid compartments)
• Dextrose 10% Hypertonic.
2/28/2021
JONES
H.M
-MBA/DMS
22
26. FLUID BALANCE CHART
• Fluid balance is an essential tool in
determining hydration
• A fluid balance chart is tool devised to monitor
fluid balance .
2/28/2021
JONES
H.M
-MBA/DMS
26
27. When to start fluid balance?
• Actual or potential dehydration
• Commencing IV fluid
• Routine post op management
• Acutely ill patients.
• Fluid restriction
• Cardiac failure
• Liver failure
• Acute renal failure
2/28/2021
JONES
H.M
-MBA/DMS
27
28. CALCULATION OF RATE OF FLUIDS
FLOW AND ADMINISTRATION OF
INTRAVENOUS INFUSION.
• Drops /minute= Total volume to be infused X drops per/min on a
giving set over the Total time for infusion in minute.
2/28/2021
JONES
H.M
-MBA/DMS
28
29. Drops /minute= Total volume to be infused X drop
factor
Total time for infusion in minutes
2/28/2021
JONES
H.M
-MBA/DMS
29
31. • After the IV infusion is secured and IV
line is patent the nurse must regulate
the rate of infusion according to
physicians orders. There is need to
observe client hourly to determine IV
therapy and restoration of fluid and
electrolyte balance.
2/28/2021
JONES
H.M
-MBA/DMS
31
32. RECORDING AND
MAINTAINING FLUID
BALANCE CHART.
• In maintaining of a fluid balance chart
you record all fluid intake and output in a
period of 24hours.
• Intake includes all liquids taken by mouth
(e.g. ice cream, soup, juice, and water),
through NG tube, and , IV fluids.
2/28/2021
JONES
H.M
-MBA/DMS
32
33. • Output includes fluid loss
through urine, diarrhoea,
vomitus, gastric suction, and
drainage from postsurgical
wounds (for surgical patients).
2/28/2021
JONES
H.M
-MBA/DMS
33
34. Insensible Loss
• The process whereby fluids are lost
through sweating, breathing and so on
• New fluid balance charts will have an
averaged amount stencilled into the
output
• Insensible loss is added to the patients
output
2/28/2021
JONES
H.M
-MBA/DMS
34
35. Completing fluid balance
• The nurse must sign to say he/she
has started the chart
• You record the amount of fluid
ordered, the period of time it is
supposed to run and the Rate of flow
calculated.
2/28/2021
JONES
H.M
-MBA/DMS
35
36. • Complete the total intake
• Complete the output
• Add in the insensible loss
• Add the output & insensible loss together
• Subtract the output from the intake to enable the
final amount in the balance box
2/28/2021
JONES
H.M
-MBA/DMS
36
37. • The nurse completing the chart and
working out the balance has to sign
for completion at the end of the 24
hour period.
2/28/2021
JONES
H.M
-MBA/DMS
37
