Experience of adopting Kubernetes to run applications. Presented at SD Dev Ops July 2018

1. Chris 'mac' McEniry

2. Agenda
• Some Items about Kubernetes
• Lift and Shift
• Evolving Applications for Kubernetes
• Changing People/Processes for Kubernetes

3. tl;dr
• Be ready for change
• As you evolve your processes/support, you have to provide backwards compatibility for both your infrastructure/applications and your processes
• Really focus on having a stable deployment mechanism
• Sort out your interaction contracts
• Start small and constrained - Realize that you won't do it "right"
• You will have to make application changes
• You will have to change your expectations
• Be ready for cutting edges
• Kubernetes has very simple set of core primitives, and a lot of options to build on top
• CICD
• Authentication and Access Control
• Resource management - forcing to use limits/requests
• Avoiding mixing goals

4. Perspective (Me)
• I'm a platform administration. I make sure the clusters...
• are available,
• have resources,
• connect to the rest of the infrastructure.
• I run applications, but for the most part help app teams use the platform

5. Survey (You)
• Who's familiar with cfengine / puppet / chef / ansible / etc?
• Who's familiar with current containers?
• Who's familiar with Kubernetes? The object / resource model?
• Who's running Kubernetes in Production (even for the smallest workload)?

6. Some items about Kubernetes...

7. Declarative State
• Tell me what you want
• Not how to do it
• How to do it can change in different contexts
• "LoadBalancer" is slightly different in AWS, GCP, Azure
• All state stored in the API Server

8. Reconciliation Loop Driven
• Many specific independent actors
• Controllers
• Operators
• Actors implement declarative state and current state
• Actor can change declarative state for another actor
and trigger its actions
• Main ones
• schduler
• controller-manager
• kubelet

9. Network Focused
• Interact with other applications over network

10. Networking
• Everything in the cluster is reachable to everything else
• (Policy might restrict)
• Magic Mappings.
• L4 Load Balancer
• DNS Mapping
• Map from outside cluster to inside

11. Resources
• What are used to defined declarative state
• Stored in cluster (API Server)
• aka Manifests

12. Container
• Process
• Isolation: Namespaces
• Resource Management: CGroups
• Restriction: Capabilities

13. Pod
• Collection of containers working tightly together
• Unit of Scheduling
• Share network stack
• Can share disk mounts
• Sidecar: a support container running with the application container

14. Service
• Logical construct representing a network resource

15. ConfigMap
• (Static) Configuration data stored inside the cluster
• Can be exposed as environment variable(s) or files place into the
container

16. Higher Level Constructs
• Multiple Pods all the same ==> ReplicaSet
• Multiple ReplicaSets running an application (with canned rolling update
mechanism) ==> Deployment
• Sensitive ConfigMaps ==> Secret
• Different Service Implementations ==> Ingress

17. Controller -> Controller (via API Server)
Kubelet
Endpoint
Controller
RS
Controller
Deploy
Controller
Replica
Set
PodDeployment
Service
App Route

18. Kubernetes is a Distributed System
for Building Distributed Systems
full of Independent Actors.

19. Lift and Shift
(Phase 1)

20. Goals
• Run an application inside of Kubernetes
• Change the code as little as possible
• Hook into the existing infrastructure as much as possible
• Keep it simple - avoid state, storage, etc
• Kick the tires

21. Starting Point
• Application Server based
• Takes requests in
• Talks to a Database in the Back

22. Host
App
Server
CLIENT
DB

23. Starting Point - Control
• Configuration
• Logs

24. Host
App
Server
LOGSCONFIG
CLIENT
DB

25. Host
Tomcat LOGSTASHCHEF
CLIENT
DB

26. App Design for Kubernetes
• Application Pod with Logstash Sidecar Pod
• ConfigMap holding prerendered output from Chef. Mounted under conf dir
• Shared mount (emptydir) for log output
• Written by app
• Read by logstash
• Service definition to map from outside to inside

27. C
TomcatConfig
CLIENT
DB
LOG
STASH
Pod

28. C
TomcatConfig
CLIENT
DB
LOG
STASH
App
Container
Logstash
Sidecar
Container

29. C
TomcatConfig
CLIENT
DB
LOG
STASH
Prerendered
Conf
stored in
ConfigMap
Mounted
into app
container for
conf dir

30. C
TomcatConfig
CLIENT
DB
LOG
STASH
Shared
mount for
logs

31. C
TomcatConfig
CLIENT
DB
LOG
STASH
Service
Definition

32. Team Processes for Kubernetes
• kubectl is the hammer
• Deploy using manifests (from source control) with kubectl apply -f
• Troubleshooting
• kubectl logs ...
• kubectl exec ...

33. Lift and Shift: Success!
• It worked!

34. Lessons Learned
• Startup time takes its time (tomcat startup)
• Debugging (kube exec)
• ConfigMap/Deployments only worked for one environment
• Healthchecks didn't fit well in the model and worked counter to
debugging steps

35. Next Goals
• Determine how to sustainable run applications inside of Kubernetes

36. Evolving Applications for Kubernetes
(Phase 2,3,4,5,6,7,8,9....)

37. https://www.redhat.com/cms/managed-files/cl-cloud-native-container-design-whitepaper-f8808kc-201710-v3-en.pdf

38. 1. Single Concern Principle
• Do one thing (and do it well)
• Separation of Concerns
• Target updates
• Minimize (vertical) image sprawl

39. 2. Image Immutability Principle
• Image is a delivery artifact with all of
the properties that that should have
• "Build once, deploy everywhere"
• Don't layer configuration on as part of
image (unless you're putting *all*
foreseeable configuration possibilities
in there)

40. 3. Self-Containment Principle
• Extension of Image Immutability
• On deployment, layer in instance
unique items (config, data)
• This uniqueness layer should be
specific to this instance

41. 4. Runtime Confinement Principle
• Get an understanding of your
resource requirements
• And use them! (helps with scheduling)
• Without them ==>
• Unintentional, uninformed
oversubscription
• Roving micro-oversubscription
hotspots

42. 5. Process Disposability Principle
• Processes are ephemeral
• Before ready for them to not be there
• This will happen often (every change)

43. Containers (by themselves) are half suited for
Kubernetes
• Kubernetes builds on containers
• If you have been following container
modeling, that translates directly

44. Kubernetes Cluster Ecosystem
• Application process interacts with
the cluster

45. 6. Life-Cycle Conformance Principle
• Figure out your timings (shutdown cleanly, startup)

46. 7. High Observability Principle
• Change in behaviors
• Biggest change in thinking
• Forced thinking of items like health checks and monit et al
• Add to Disposability Principle - have to be able to debug quickly, over the network, and with remaining forensics

47. Changing People/Process for Kubernetes

48. Be Ready for Change
• Changed Deployment Strategy
• Single manifests -> Helm Charts
• Changed Helm Chart Structure 5 Times
• Changed Logging Infrastructure 3 Times
• BE VERY CAREFUL IN WHAT YOU STOP SUPPORTING

49. Contracts
• Describe what each side/component of processes will provide and accept
• Helps to define
• What can be changed without impacting others
• What needs to be talked about before changing

50. Kubernetes Cluster Kubernetes Team App Team / User
-Receives App Definition
+Define App Definition
(name, resource count, users)
-Receives namespace, RBAC +Defines namespace, RBAC
-Trusts central auth +Logs in via central auth
-Allows access to granted resources +Accesses namespace
App Team Onboarding to Cluster

51. App (Pod) Kubernetes Cluster Monitoring App Team / User
+Logs to STDOUT -Receives from STDOUT
+Transmits to Logging Bus -Receives on Logging Bus
+JSON Structured Log
Format
-Handles JSON Format
+Indexes in Search Tool -Search in Search Tool
+Infrastructure enrichments:
pod, cluster, container host,
environment, datacenter
-Search by infrastructure
information
Logging Contract

52. Be Comfortable with Being Uncomfortable
• A lot of this technology is new/recent
• A lot of simple implementations (first pass)
• A lot of undiscovered bugs
• "Best practices" are highly localized

53. Simplified Primitives
• Deployments
• All at once (destroy + build)
• Rolling
• Load Balancing
• Only equal weight round robin (be it via L4 forwarding, or DNS)
• What's Layer7?

54. Common App Team Concerns
• How do I get onboarded?
• How does my application have to interact with the system?
• How do I run my application?
• How do I troubleshoot my application?
• How does it all work?!!?!?!

55. How do I run my application?
• Build an Application Template
• Dockerfile
• Helm Chart
• Jenkinsfile
• Extend with organizational specific functions
• Partial Deploy functions
• Incorporate environment values

56. Debugging
• kubectl exec ...

57. How does it all work?!?!?!?!
• Boot camps

58. Current

59. C
Jar
App
Config
Map
CLIENT
DB
Secret
Management
Config
Map

60. New Application Model
• Jar App (faster start up)
• zmetrics port (separate from client interface)
• Prometheus scrapes metrics
• Readiness/liveness probes
• Logs to STDOUT

61. New Deployment Model
• CICD Driven
• Standard format for repository
• Dockerfile, Chart --> artifacts
• Environment specific values
• Multiproject pipeline pushes to multiple environments with approval gates
• Automatic canary deploy, sanity check, then full deploy

62. Lessons Learned

63. • If you change too quickly, you will be in for a world of hurt
• Different ways to deploy
• Different Kubernetes versions (v1alpha1, v1beta1, v1)
• You can't please everyone
• Tradeoffs
• Training - bootcamps and walking people through...
• Examples examples examples - easy to copy (cargo culting)

64. Health Checks
• Liveliness probe: If this fails, Kubernetes will restart the
container.
• Readiness probe: If this fails, Kubernetes will take the
pod out of the service pool.
• If an app is bad, I should stop sending traffic to it and
recover it, right? ==> Ok to set these to the same
thing.
https://cloud.google.com/kubernetes-engine/kubernetes-comic/

65. "We DDOSed Ourselves!!!"
• On startup, application can be ready
• Gets flooded with traffic
• Kube restarts because liveness failed as well
• Quick fix: Removed liveness
• Real fix:
• Run liveness and readiness on a different port/
connection threadpool/etc
• Know they mean different items

66. • Prometheusbeat has limited support
• Security scanning checkbox
• Type:LoadBalancer Services (and anything built off them) get a permit *
ICMP Destination Unreachable (Type 3) - runs afoul of security policies
• Provide helper tools to setup configuration
• Login ==> can also gather cluster information like certificates and
endpoints

67. Q?
Obligatory - we're hiring...
Maybe Answers...
