This document provides an overview of Eclipse Libra, a set of tools for OSGi enterprise application development in Eclipse. It describes Libra's scope, the tools included in the initial Juno release such as bundle projects, framework adapters, and the bundle overview. It also briefly demonstrates the bundle dependency view and server console.

1. OSGi for the earthlings:
meet eclipse libra
Naci Dai (@nacidai)
eteration

2. Human OSGi?
nature? Rounded
Pointed
Ears Ears
Fully supported by
USS Enterprise Eclipse PDE / WTP
http://xeobits.com/internet/humor-internet/2-cents-for-
programmers-funny-one/
eteration

3. Five Levels of OSGi (Alex Blewit)
Can’t possibly work Cannot see my class why this uses constraint How do I load a JDBC driver? Bundle Enlightenment
OSGi is written by IBM? ClassNotFoundException? It fails How can I map JNDI Declarative services
I don’t use Eclipse is there Can’t we start the services references to data sources? Remote Services
These classes are the same in order My custom Log4J logger
OSGi is too complex Dynamically update code on
but aren’t? Works on Equinox but not does not work? servers
javax.swing is not there Felix Write a Manifest manually? Tweets about OSGi
Denial
Acceptance
Anger
Bargaining
Depression
hibernate is not working? Let there be a Stack Is there a bundle for Apache
Overflow answer for Beanutils
NoClassDefFoundError ...
•
resolution:=optional, please
just start
eteration

4. JavaEE: If the shoe does not fit
 Tightly coupled
 hardwired
 Not Dynamic
 Restarts with every deploy
 Isolation
 No sharing
 Common libraries etc. xflickrx, Flickr Creative Commons
 Version conflicts
 Hierarchical class-loading
eteration

5. OSGi The New Java Enterprise
The fictional version
Web
JPA Modules
Subsystems, WABs, JPA, Blueprint, Na
ming, …
Transa JNDI
Dynamic Services
ctions
Java EE
Goodies
+ OSGi
= OSGi
Enterprise
Goodies
eteration

6. OSGi Enterprise Applications
 OSGi programming model
 Proven, standards-based
 Dynamic
 Modular
 Manageable
 Ubiquitous
 Evolvable
 Enterprise Infrastructure
 Persistence, Transactions, Distributed, Management, Namin
g, …
A whole new generation of Enterprise Applications
eteration

7. Enterprise OSGi
Hello Client App Hello Server App
Subsystems bundle
& Services dynamic
(.ssa archives)
subsystems
Target Gemini
Frameworks
Eclipse Equinox Apache Felix
eteration

8. OSGi Tools • Too many/Not enough tools
• Different Philosophies
• OSGi Transparent
 Development Tools • Generate Manifests
• OSGi Frameworks are tricky
 Eclipse Libra
• Launching
 Eclipse PDE • Installing
 Eclipse WTP • Etc.
 Eclipse Virgo Tools
 BndTools
 IBM Rational Development Tools
for OSGi Applications
 Silent, still alive???
 Builds
 Maven Tycho
 PDE Builds
eteration

9. Meet Eclipse Libra
 Tools for OSGi Enterprise Development
WTP
PDE
Tools
eteration

10. Libra Tools Scope
Frameworks Standards & Technologies
Aries Blueprint
Virgo
OSGi JPA
EclipseLink Jetty Subsystems
OBR
JavaEE
IN
Gemini Felix Web
Equinox Tomcat Declarative Services
WebSphere(Liberty) PARs
EABs
OUT
uJOnAS
WebLogic
eteration

11. What is in the Juno Release
 OSGi Bundle Facet  Framework Editor
 Refactoring from Virgo Tools
 WAR Products  Server Console
 OSGi Framework Adapters  Bundle Overview
 Adapted from WTP servers  Dependency Graphs
 Launch configurations  PROVISIONAL
 Support for Apache  Bundle Projects
Felix, Eclipse Equinox and
Knopflerfish  Manifest Editor
 Gemini / Apache Aries
 Virgo tools not yet ported!
 Manifest Editor / OBR /
Adapter / Blueprint Editor
eteration

12. Bundle Projects
 OSGi Bundle Facet
 PDE / WTP project types
 Versioned
 Tools can add more
behavior
eteration

13. Framework Adapters
 Vanilla OSGi Frameworks
 Eclipse Equinox, Apache
Felix, Knopflerfish
 Eclipse RT (with above)
 Gemini
 Virgo
 EclipseLink
 Jetty
 …
 Apache Aries (with above)
eteration

14. BundleOverview
 Part of framework Editor
 List and control all bundles
eteration

15. Bundle Dependency View
 Graphical representation of bundle dependencies
 Drill-downs
eteration

16. Server Console
 Similar to console shells
eteration

17. Bundle Repository Browser
 (Virgo) Resolves bundles from OBRs
 Spring Enterprise Bundle Repository
eteration

18. War Products
• Equinox running in a JavaEE server in bridged mode
• Add your plugins to a Product Definition that exports a
WAR file
• Includes all necessary plugins and deployment files (web.xml)
eteration

19. demo(s)
You can watch the Video tutorials online...
http://www.eclipse.org/libra/documentation/video/
Launchers and Declerative Services
Gemini Web
Http Service and WAR Products
eteration

20. Resources
 http://eclipse.org/libra
 Contact
Twitter: @nacidai
Email: naci@eteration.com
eteration
